Motor Model / KV X8318S/ KV100 X8318S/ KV120
Stator/Rotor Poles 36N42P 36N42P
Internal resistance 54mΩ 37mΩ
Motor size φ91.6*41.0mm
φ91.6*41.0mm
Shaft diameter 15.0mm 15.0mm
AWG 20AWG 100mm 20AWG 100mm
Motor weight(wire included) 635g 635g
Motor weight(wire excluded) No data No data
Rated operational voltage 12S 12S
No-load current 1.1A/10V 1.3A/10V
Maximum continuous power 2500W 3200W
Maximum continuous current 50A/30s 64A/30s
ESC recommended use 80A 80A
Propeller size recommended use 30*10.5 30*10.5

X8318S

Stator Diameter 83mm Rotor Diameter 91.6mm
Stator Thickness 18mm Shaft Diameter 15mm
No.of Stator Slots 36 Body Length(without shaft) 41mm
No.of Rotor Poles 42 Body Length 46.5mm
Motor Kv 100 Max Lipo Cell 12S
No-load current 1.1A/10V ESC 80A
Motor Resistance 54mΩ Recommended Prop(inch) 30*10.5
Max Continuous Current 50A/30s Recommended single take-off Weight ≤6000g
Max Continuous Power 2500W
Weight

635g

Prop(inch) Voltage(V) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
30*10.5 44.4 0.6 500 27 18.77 95℃
1.4 1000 62 16.09
2.3 1500 102 14.69
3.4 2000 151 13.25
4.6 2500 204 12.24
5.8 3000 258 11.65
7.2 3500 320 10.95
8.8 4000 391 10.24
10.2 4500 453 9.94
12 5000 533 9.38
13.7 5500 608 9.04
15.6 6000 693 8.66
17.6 6500 781 8.32
19.6 7000 870 8.04
21.7 7500 963 7.78
23.7 8000 1052 7.60
26.1 8500 1159 7.33
28.2 9000 1252 7.19
31.2 9500 1385 6.86
33.2 10000 1474 6.78
42.3 11840 1878 6.30







Stator Diameter 83mm Rotor Diameter 91.6mm
Stator Thickness 18mm Shaft Diameter 15mm
No.of Stator Slots 36 Body Length(without shaft) 41mm
No.of Rotor Poles 42 Body Length 46.5mm
Motor Kv 120 Max Lipo Cell 12S
No-load current 1.3A/10V ESC 80A
Motor Resistance 37mΩ Recommended Prop(inch) 30*10.5
Max Continuous Current 64A/30s Recommended single take-off Weight ≤6000g
Max Continuous Power 3200W
Weight

635g

Prop(inch) Voltage(V) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
30*10.5 44.4 0.7 500 31 16.09 3 min 120℃
1.5 1000 67 15.02
2.4 1500 107 14.08
3.5 2000 155 12.87
4.7 2500 209 11.98
5.9 3000 262 11.45
7.3 3500 324 10.80
8.7 4000 386 10.36
10.2 4500 453 9.94
11.9 5000 528 9.46
13.9 5500 617 8.91
15.8 6000 702 8.55
17.4 6500 773 8.41
19.5 7000 866 8.09
21.7 7500 963 7.78
24 8000 1066 7.51
25.9 8500 1150 7.39
28.5 9000 1265 7.11
30.8 9500 1368 6.95
33.5 10000 1487 6.72
38.8 11000 1723 6.39
43.7 12000 1940 6.18
50.5 13000 2242 5.80
57.3 14000 2544 5.50
59.8 14500 2655 5.46
