X8020S_SUNNYSKY-The most stable power system

8030-英文_02.jpg 8030-英文_03.jpg 8030-英文_04.jpg 8030-英文_05.jpg 8030-英文_06.jpg 8030-英文_07.jpg 8030-英文_09.jpg


Motor Model / KV	X8020S/ KV100	X8020S/ KV120
Stator/Rotor Poles	24N28P	24N28P
Internal resistance	32mΩ	25mΩ
Motor size	φ89.3*62.5mm	φ89.3*62.5mm
Shaft diameter	29.0mm	29.0mm
AWG	20AWG 100mm	20AWG 100mm
Motor weight(wire included)	768g	780g
Motor weight(wire excluded)	No data	No data
Rated operational voltage	12S	12S
No-load current	1.1A/10V	1.4A/10V
Maximum continuous power	3552W	4944W
Maximum continuous current	74A/30s	103A/30s
ESC recommended use	80A	110A
Propeller size recommended use	EOLO CN309.5 C3010 CN32*11	EOLO CN309.5 C3010 CN32*11

X8020S

KV100 KV120

Specifications	X8020S	Max Continuous Current	74A/30s
Stator Diameter	80mm	Max Continuous Power	3552W
Stator Thickness	20mm	Weight	768g
No.of Stator Slots	24	Rotor Diameter	89.3mm
No.of Rotor Poles	28	Body Length	62.5mm
Motor Kv	100	Max Lipo Cell	12S
NO-Load Current(A/10V)	1.1A	ESC	80A
Motor Resistance	32mΩ	Recommend Prop(inch)	EOLO CN309.5 C3010 CN32*11

Propeller (inch)	Voltage (V)	Current (A)	Thrust (g)	Watts (W)	Efficiency (g/W)	RPM	Load temperature in 100% throttle
EOLO CN30*9.5	44.4	3.7	2000	164.28	12.17	1585
		6.4	3000	284.16	10.56	1934
		9.4	5000	417.36	11.98	2198
		12.8	5000	568.32	8.80	2462
		16.4	6000	728.16	8.24	2658
		20.5	7000	910.2	7.69	2903
		24.8	8000	1101.12	7.27	3071
		29.4	9000	1305.36	6.89	3243
		34.8	10000	1545.12	6.47	3429
		45.5	12000	2020.2	5.94	3767
		55.8	14000	2477.52	5.65	3969
	48	3.5	2000	168	11.90	1577
		6	3000	288	10.42	1922
		8.7	4000	417.6	9.58	2188
		11.8	5000	566.4	8.83	2466
		15.6	6000	748.8	8.01	2660
		19.1	7000	916.8	7.64	2895
		23.1	8000	1108.8	7.22	3080
		27.5	9000	1320	6.82	3250
		31.9	10000	1531.2	6.53	3441
		42.5	12000	2040	5.88	3756
		53.6	14000	2572.8	5.44	4038
		63.2	15900	3033.6	5.24	4220	106℃
EOLO C30*10	44.4	3.8	2000	168.72	11.85	1523
		6.5	3000	288.6	10.40	1828
		9.5	4000	421.8	9.48	2088
		13	5000	577.2	8.66	2369
		16.8	6000	745.92	8.04	2565
		20.8	7000	923.52	7.58	2792
		25.2	8000	1118.88	7.15	2967
		30.2	9000	1340.88	6.71	3129
		35.1	10000	1558.44	6.42	3264
		46.7	12000	2073.48	5.79	3578
		62.2	14600	2761.68	5.29	3901
	48	3.6	2000	172.8	11.57	1521
		6.1	3000	292.8	10.25	1822
		8.8	4000	422.4	9.47	2075
		12.1	5000	580.8	8.61	2366
		15.8	6000	758.4	7.91	2569
		19.5	7000	936	7.48	2798
		23.6	8000	1132.8	7.06	2974
		28.2	9000	1353.6	6.65	3133
		32.9	10000	1579.2	6.33	3281
		43.4	12000	2083.2	5.76	3560
		55.2	14000	2649.6	5.28	3920
		70.1	16600	3364.8	4.93	4109	135℃
EOLO CN32*11	44.4	3.6	2000	159.84	12.51	1413
		6	3000	266.4	11.26	1727
		9	4000	399.6	10.01	1991
		12.3	5000	546.12	9.16	2207
		15.9	6000	705.96	8.50	2409
		19.9	7000	883.56	7.92	2595
		24.3	8000	1078.92	7.41	2792
		29	9000	1287.6	6.99	2936
		33.5	10000	1487.4	6.72	3107
		44.1	12000	1958.04	6.13	3416
		56.3	14000	2499.72	5.60	3690
		67.3	16100	2988.12	5.39	3846
	48	3.3	2000	158.4	12.63	1411
		5.7	3000	273.6	10.96	1732
		8.5	4000	408	9.80	1989
		11.4	5000	547.2	9.14	2210
		14.9	6000	715.2	8.39	2411
		18.4	7000	883.2	7.93	2599
		22.6	8000	1084.8	7.37	2795
		26.5	9000	1272	7.08	2944
		31.1	10000	1492.8	6.70	3115
		40.8	12000	1958.4	6.13	3411
		52.5	14000	2520	5.56	3698
		65.1	16000	3124.8	5.12	3934
		74.2	17400	3561.6	4.89	4059	3min 150℃

图片 1.jpg

Specifications	X8020S	Max Continuous Current	103A/30s
Stator Diameter	80mm	Max Continuous Power	4944W
Stator Thickness	20mm	Weight	780g
No.of Stator Slots	24	Rotor Diameter	89.3mm
No.of Rotor Poles	28	Body Length	62.5mm
Motor Kv	120	Max Lipo Cell	12S
NO-Load Current(A/10V)	1.4A	ESC	110A
Motor Resistance	25mΩ	Recommend Prop(inch)	EOLO CN309.5 C3010 CN32*11

Propeller (inch)	Voltage(V)	Amps(A)	Input power (W)	Speed (rpm)	Torque (N.m ）	Output power (W)	Thrust (g)	Efficiency (%)	Efficiency (g/W)	Load temperature in 100% throttle
EOLO CN30*9.5	44.77	3.793	169.81	1538.36	0.78	125.64	2074.64	73.98	12.21
	44.66	6.323	282.38	1904.46	1.14	227.33	3043.31	80.5	10.77
	44.51	9.01	401.03	2179.48	1.47	335.48	4057.7	83.65	10.11
	44.6	12.332	550	2447.8	1.83	469.05	5023.22	85.28	9.13
	44.28	16.022	709.45	2678.54	2.13	597.41	6019.75	84.2	8.48
	44.43	20.398	906.28	2910.01	2.63	801.39	7065.17	88.42	7.79
	44.35	24.401	1082.18	3104.05	2.86	929.58	8071.11	85.89	7.45
	44.41	28.89	1283	3272.06	3.28	1123.8	9016.27	87.59	7.02
	44.28	34.237	1516.01	3470.73	3.65	1326.5	10076.72	87.49	6.64
	43.84	44.654	1957.63	3797.7	4.31	1713.93	12081.59	87.55	6.17
	43.56	56.737	2471.46	4105.58	4.94	2123.72	14037.74	85.92	5.67
	43.52	70.851	3083.43	4365.28	5.8	2651.16	16000.46	85.98	5.18
	43.33	79.624	3450.1	4540.48	6.13	2914.46	17231.04	84.47	4.99
	47.84	3.618	173.08	1544.74	0.79	127.78	2022.53	73.82	11.68
	47.9	6.189	296.45	1925.71	1.16	233.9	3074.99	78.9	10.37
	48	9.1	436.79	2208.19	1.49	344.52	4020.32	78.87	9.2
	47.79	11.796	563.73	2470.27	1.85	478.53	5083.71	84.88	9.01
	47.72	15.194	725.05	2692.96	2.17	611.9	6066.16	84.39	8.36
	47.67	18.898	900.86	2896.92	2.57	779.58	7054.58	86.53	7.83
	47.65	23.029	1097.33	3111.14	2.91	948	8003.88	86.39	7.29
	47.32	27.187	1286.48	3295.17	3.34	1152.44	9081.35	89.58	7.05
	47.52	31.85	1513.51	3463.54	3.62	1312.88	10032.22	86.74	6.62
	47.26	41.904	1980.38	3797.22	4.26	1693.83	12090.62	85.53	6.1
	46.91	53.828	2525.07	4103.01	5.15	2212.61	14071.38	87.62	5.57
	46.71	67.158	3136.95	4395.17	5.84	2687.72	16167.07	85.67	5.15
	46.57	80.467	3747.34	4659.44	6.57	3205.49	18058.57	85.54	4.81
	46.49	89.646	4167.64	4782.19	7.08	3545.33	19214.63	85.06	4.61	150℃
EOLO C30*10	44.86	3.935	176.52	1467.96	0.72	110.67	1982.31	62.69	11.22
	44.75	6.639	297.09	1840.36	1.11	213.9	3025.78	71.99	10.18
	44.79	9.686	433.83	2123.1	1.5	333.47	4027.73	76.86	9.28
	44.73	13.021	582.42	2348.8	1.83	450.08	5066.08	77.27	8.69
	44.41	16.785	745.42	2573.71	2.17	584.81	6068.5	78.45	8.14
	44.59	20.588	918.01	2767.04	2.56	741.74	7030.78	80.79	7.65
	44.47	25.202	1120.73	2976.44	2.96	922.54	8066.88	82.31	7.19
	44.3	29.643	1313.18	3159.13	3.3	1091.63	9048.54	83.12	6.89
	44.4	30.141	1338.26	3138.89	3.45	1133.94	9183.61	84.73	6.86
	44.36	35.158	1559.6	3312.89	3.79	1314.74	10099.51	84.29	6.47
	44.2	45.653	2017.86	3612.88	4.44	1679.7	12082.1	83.24	5.98
	43.8	57.56	2521.12	3879.29	5.18	2104.15	14035.73	83.46	5.56
	43.86	73.26	3213.18	4143.15	6.03	2616.04	16106.78	81.41	5.01
	42.88	89.437	3835.05	4366.58	6.56	2999.45	18346.67	78.21	4.78
	47.89	3.899	186.72	1485.22	0.73	113.52	2003.49	60.79	10.72
	47.84	6.306	301.67	1821.9	1.12	213.66	3014.91	70.82	9.99
	47.62	9.117	434.15	2082.57	1.44	314.02	4028.33	72.32	9.27
	47.99	12.516	600.64	2346.71	1.9	466.88	5009.54	77.73	8.34
	47.77	15.769	753.28	2565.1	2.21	593.59	6050.36	78.8	8.03
	47.55	19.502	927.32	2758.24	2.57	742.26	7021.38	80.04	7.57
	47.43	23.394	1109.57	2952.59	2.94	908.96	8024.14	81.92	7.23
	47.52	27.709	1316.73	3114.63	3.32	1082.78	9032.3	82.23	6.85
	47.53	32.503	1544.86	3285.77	3.67	1262.69	10010.4	81.73	6.47
	47.2	42.937	2026.62	3576.19	4.49	1681.37	12037.29	82.96	5.93
	47.03	55.091	2590.92	3877.63	5.24	2127.62	14019.18	82.11	5.41
	46.58	67.736	3155.14	4138.49	5.87	2543.76	16089.09	80.62	5.09
	46.36	82.604	3829.52	4373.49	6.72	3077.47	18076.1	80.36	4.72
	46.02	98.839	4548.57	4587.31	7.44	3573.77	20211.37	78.56	4.44	5min 150℃
EOLO CN32*11	44.89	3.705	166.31	1365.95	0.73	104.41	2016.74	62.78	12.12
	44.7	6.044	270.16	1679.26	1.12	196.93	3005.13	72.89	11.12
	44.94	9.086	408.32	1945.61	1.48	301.51	4005.03	73.84	9.8
	44.8	12.5	560	2198.85	1.87	430.56	5068.26	76.88	9.05
	44.76	15.759	705.37	2397.84	2.17	544.84	6016.97	77.24	8.53
	44.8	20.002	896.08	2607.18	2.6	709.8	7084.74	79.21	7.9
	44.41	24.093	1069.97	2802.02	3.01	883.14	8080.9	82.53	7.55
	44.5	28.226	1256.05	2945.03	3.34	1029.98	9043.89	82	7.2
	44.45	32.905	1462.62	3087.52	3.68	1189.74	10001.26	81.34	6.83
	44.23	44.037	1947.75	3399.85	4.49	1598.46	12066.62	82.06	6.19
	43.84	55.79	2445.83	3664.74	5.16	1980.11	14092.63	80.95	5.76
	43.74	70.26	3073.17	3943.65	6.04	2494.2	16084.41	81.16	5.23
	43.26	84.916	3673.46	4196.56	6.68	2935.39	18078.68	79.9	4.92
	43.22	93.177	4027.1	4343.98	6.95	3161.32	19236.51	78.5	4.77
	48.21	3.394	163.62	1349.38	0.72	101.73	2071.86	62.17	12.66
	48.23	5.872	283.2	1677.55	1.08	189.71	3068.72	66.98	10.83
	48.2	8.367	403.28	1910.77	1.47	294.11	4059.77	72.92	10.06
	48.01	11.263	540.73	2161.03	1.81	409.57	5042.82	75.74	9.32
	47.85	14.732	704.92	2357.54	2.17	535.69	6027.45	75.99	8.55
	47.82	18.219	871.23	2557.91	2.6	696.39	7050.64	79.93	8.09
	47.63	21.981	1046.95	2747.04	2.98	857.19	8070.22	81.87	7.7
	47.6	26.645	1268.3	2938.76	3.29	1012.41	9037.02	79.82	7.12
	47.12	30.575	1440.69	3103.21	3.62	1176.29	10064.29	81.64	6.98
	47.4	40.542	1921.69	3381.29	4.44	1572.03	12001.58	81.8	6.24
	47.5	52.229	2480.87	3659.21	5.28	2023.1	14015.99	81.54	5.64
	47	65.389	3073.28	3958.32	5.93	2457.88	16085.98	79.97	5.23
	46.51	77.725	3614.98	4175.49	6.54	2859.44	18015.83	79.09	4.98
	46.29	94.587	4378.43	4417	7.5	3468.84	20012.52	79.22	4.57
	46.07	102.513	4722.77	4599.25	7.77	3742	21374.06	79.23	4.52	2min 150℃

图片 1.jpg
