This product is designed solely for use by RC model enthusiasts and for recreational purposes. It is
not intended for professional, military, commercial, or industrial applications.
This product is designed solely for use by RC model enthusiasts and for recreational purposes. It isnot intended for professional, military, commercial, or industrial applications.
| Motor Model / KV | X8012S/ KV100 | X8012S/ KV120 | X8012S/ KV130 | X8012S/ KV150 |
|---|---|---|---|---|
| Stator/Rotor Poles | 24N28P | 24N28P | 24N28P | 24N28P |
| Internal resistance | 73mΩ | 58mΩ | 48mΩ | 36mΩ |
| Motor size | φ89.3*50.5mm | φ89.3*50.5mm | φ89.3*50.5mm |
φ89.3*50.5mm |
| Shaft diameter | 15.0mm | 15.0mm | 15.0mm | 15.0mm |
| AWG | 20AWG 100mm | 20AWG 100mm | 20AWG 100mm | 20AWG 100mm |
| Motor weight(wire included) | 513g | 518g | 521g | 517g |
| Motor weight(wire excluded) | No data | No data | No data | No data |
| Rated operational voltage | 12S | 12S | 12S | 12S |
| No-load current | 0.5A/10V | 0.6A/10V | 0.7A/10V | 1.3A/10V |
| Maximum continuous power | 1392W | 1920W | 2400W | 3888W |
| Maximum continuous current | 29A/30s | 40A/30s | 50A/30s | 81A/30s |
| ESC recommended use | 40A | 40A | 40-50A | 80A |
| Propeller size recommended use | EOLO CN24*7.5 26*8 | EOLO CN24*7.5 26*8 | EOLO CN24*7.5 26*8 | EOLO CN24*7.5 26*8 |
|
Specifications |
X8012S |
Max Continuous Current |
29A/30s |
|
Stator Diameter |
80mm |
Max Continuous Power |
1392W |
|
Stator Thickness |
12mm |
Weight |
513g |
|
No.of Stator Slots |
24 |
Rotor Diameter |
89.3mm |
|
No.of Rotor Poles |
28 |
Body Length |
50.5mm |
|
Motor Kv |
100 |
Max Lipo Cell |
12S |
|
NO-Load Current(A/10V) |
0.5A |
ESC |
40A |
|
Motor Resistance |
73mΩ |
Recommend Prop(inch) |
EOLO CN24*7.5 26*8 |
|
Propeller (inch) |
Voltage (V) |
Current (A) |
Thrust (g) |
Watts (W) |
Efficiency (g/W) |
RPM |
Load temperature in 100% throttle |
|
EOLO CN24*7.5 |
44.4 |
1.7 |
1000 |
75.48 |
13.25 |
1735 |
|
|
2.8 |
1500 |
124.32 |
12.07 |
2144 |
|||
|
4 |
2000 |
177.6 |
11.26 |
2478 |
|||
|
5.4 |
2500 |
239.76 |
10.43 |
2756 |
|||
|
7 |
3000 |
310.8 |
9.65 |
3030 |
|||
|
8.7 |
3500 |
386.28 |
9.06 |
3244 |
|||
|
10.5 |
4000 |
466.2 |
8.58 |
3461 |
|||
|
15.9 |
5350 |
705.96 |
7.58 |
3875 |
|||
|
48 |
1.6 |
1000 |
76.8 |
13.02 |
1745 |
||
|
2.6 |
1500 |
124.8 |
12.02 |
2122 |
|||
|
3.8 |
2000 |
182.4 |
10.96 |
2488 |
|||
|
5.1 |
2500 |
244.8 |
10.21 |
2763 |
|||
|
6.5 |
3000 |
312 |
9.62 |
3052 |
|||
|
8 |
3500 |
384 |
9.11 |
3267 |
|||
|
9.8 |
4000 |
470.4 |
8.50 |
3474 |
|||
|
13.5 |
5000 |
648 |
7.72 |
3865 |
|||
|
17.8 |
6150 |
854.4 |
7.20 |
4140 |
50℃ |
||
|
EOLO CN26*8 |
44.4 |
1.5 |
1000 |
66.6 |
15.02 |
1414 |
|
|
2.4 |
1500 |
106.56 |
14.08 |
1703 |
|||
|
3.6 |
2000 |
159.84 |
12.51 |
1951 |
|||
|
4.9 |
2500 |
217.56 |
11.49 |
2184 |
|||
|
6.4 |
3000 |
284.16 |
10.56 |
2402 |
|||
|
7.9 |
3500 |
350.76 |
9.98 |
2615 |
|||
|
9.5 |
4000 |
421.8 |
9.48 |
2751 |
|||
|
13.3 |
5000 |
590.52 |
8.47 |
3067 |
|||
|
17.7 |
6000 |
785.88 |
7.63 |
3335 |
|||
|
22.4 |
7000 |
994.56 |
7.04 |
3569 |
|||
|
24.8 |
7500 |
1101.12 |
6.81 |
3670 |
|||
|
48 |
1.4 |
1000 |
67.2 |
14.88 |
1425 |
||
|
2.3 |
1500 |
110.4 |
13.59 |
1695 |
|||
|
3.3 |
2000 |
158.4 |
12.63 |
1967 |
|||
|
4.6 |
2500 |
220.8 |
11.32 |
2177 |
|||
|
5.9 |
3000 |
283.2 |
10.59 |
2416 |
|||
|
7.3 |
3500 |
350.4 |
9.99 |
2631 |
|||
|
8.9 |
4000 |
427.2 |
9.36 |
2764 |
|||
|
12.4 |
5000 |
595.2 |
8.40 |
3055 |
|||
|
16.2 |
6000 |
777.6 |
7.72 |
3327 |
|||
|
20.5 |
7000 |
984 |
7.11 |
3590 |
|||
|
25.4 |
8000 |
1219.2 |
6.56 |
3780 |
|||
|
28.1 |
8300 |
1348.8 |
6.15 |
3896 |
90℃ |
Specifications | X8012S | Max Continuous Current | 40A/30s |
Stator Diameter | 80mm | Max Continuous Power | 1920W |
Stator Thickness | 12mm | Weight | 518g |
No.of Stator Slots | 24 | Rotor Diameter | 89.3mm |
No.of Rotor Poles | 28 | Body Length | 50.5mm |
Motor Kv | 120 | Max Lipo Cell | 12S |
NO-Load Current(A/10V) | 0.6A | ESC | 40A |
Motor Resistance | 58mΩ | Recommend Prop(inch) | EOLO CN24*7.5 26*8 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO CN24*7.5 | 44.4 | 1.8 | 1000 | 79.92 | 12.51 | 1758 |
|
2.9 | 1500 | 128.76 | 11.65 | 2160 | |||
4.2 | 2000 | 186.48 | 10.73 | 2479 | |||
5.7 | 2500 | 253.08 | 9.88 | 2740 | |||
7.2 | 3000 | 319.68 | 9.38 | 3038 | |||
8.9 | 3500 | 395.16 | 8.86 | 3264 | |||
10.7 | 4000 | 475.08 | 8.42 | 3460 | |||
14.9 | 5000 | 661.56 | 7.56 | 3880 | |||
19.3 | 6000 | 856.92 | 7.00 | 4185 | |||
22.5 | 6700 | 999 | 6.71 | 4316 | |||
48 | 1.7 | 1000 | 81.6 | 12.25 | 1748 | ||
2.7 | 1500 | 129.6 | 11.57 | 2154 | |||
3.9 | 2000 | 187.2 | 10.68 | 2489 | |||
5.3 | 2500 | 254.4 | 9.83 | 2751 | |||
6.7 | 3000 | 321.6 | 9.33 | 3045 | |||
8.3 | 3500 | 398.4 | 8.79 | 3275 | |||
10 | 4000 | 480 | 8.33 | 3484 | |||
13.8 | 5000 | 662.4 | 7.55 | 3895 | |||
17.8 | 6000 | 854.4 | 7.02 | 4278 | |||
22.3 | 7000 | 1070.4 | 6.54 | 4598 | |||
25.1 | 7700 | 1204.8 | 6.39 | 4633 | 60℃ | ||
EOLO CN26*8 | 44.4 | 1.6 | 1000 | 71.04 | 14.08 | 1404 |
|
2.6 | 1500 | 115.44 | 12.99 | 1704 | |||
3.9 | 2000 | 173.16 | 11.55 | 1965 | |||
5.2 | 2500 | 230.88 | 10.83 | 2183 | |||
6.6 | 3000 | 293.04 | 10.24 | 2382 | |||
8.3 | 3500 | 368.52 | 9.50 | 2566 | |||
9.9 | 4000 | 439.56 | 9.10 | 2721 | |||
13.8 | 5000 | 612.72 | 8.16 | 3050 | |||
18 | 6000 | 799.2 | 7.51 | 3315 | |||
22.6 | 7000 | 1003.44 | 6.98 | 3583 | |||
27.5 | 8000 | 1221 | 6.55 | 3816 | |||
35 | 9350 | 1554 | 6.02 | 4029 | |||
48 | 1.5 | 1000 | 72 | 13.89 | 1415 | ||
2.4 | 1500 | 115.2 | 13.02 | 1720 | |||
3.5 | 2000 | 168 | 11.90 | 1974 | |||
4.7 | 2500 | 225.6 | 11.08 | 2166 | |||
6.1 | 3000 | 292.8 | 10.25 | 2390 | |||
7.6 | 3500 | 364.8 | 9.59 | 2585 | |||
9.1 | 4000 | 436.8 | 9.16 | 2742 | |||
12.7 | 5000 | 609.6 | 8.20 | 3048 | |||
16.7 | 6000 | 801.6 | 7.49 | 3326 | |||
20.8 | 7000 | 998.4 | 7.01 | 3590 | |||
25.7 | 8000 | 1233.6 | 6.49 | 3837 | |||
30.6 | 9000 | 1468.8 | 6.13 | 4014 | |||
39.7 | 10500 | 1905.6 | 5.51 | 4309 | 130℃ |
|
Specifications |
X8012S |
Max Continuous Current |
50A/30s |
|
Stator Diameter |
80mm |
Max Continuous Power |
2400W |
|
Stator Thickness |
12mm |
Weight |
521g |
|
No.of Stator Slots |
24 |
Rotor Diameter |
89.3mm |
|
No.of Rotor Poles |
28 |
Body Length |
50.5mm |
|
Motor Kv |
130 |
Max Lipo Cell |
12S |
|
NO-Load Current(A/10V) |
0.7A |
ESC |
40-50A |
|
Motor Resistance |
48mΩ |
Recommend Prop(inch) |
EOLO CN24*7.5 26*8 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO CN24*7.5 | 44.4 | 1.8 | 1000 | 79.92 | 12.51 | 1772 |
|
2.9 | 1500 | 128.76 | 11.65 | 2147 | |||
4.2 | 2000 | 186.48 | 10.73 | 2482 | |||
5.7 | 2500 | 253.08 | 9.88 | 2757 | |||
7.3 | 3000 | 324.12 | 9.26 | 3034 | |||
9 | 3500 | 399.6 | 8.76 | 3265 | |||
10.8 | 4000 | 479.52 | 8.34 | 3495 | |||
15 | 5000 | 666 | 7.51 | 3864 | |||
19.5 | 6000 | 865.8 | 6.93 | 4236 | |||
24.3 | 7000 | 1078.92 | 6.49 | 4485 | |||
27.1 | 7800 | 1203.24 | 6.48 | 4640 | |||
48 | 1.7 | 1000 | 81.6 | 12.25 | 1757 | ||
2.7 | 1500 | 129.6 | 11.57 | 2154 | |||
3.9 | 2000 | 187.2 | 10.68 | 2489 | |||
5.3 | 2500 | 254.4 | 9.83 | 2755 | |||
6.7 | 3000 | 321.6 | 9.33 | 3044 | |||
8.4 | 3500 | 403.2 | 8.68 | 3271 | |||
10.1 | 4000 | 484.8 | 8.25 | 3486 | |||
13.9 | 5000 | 667.2 | 7.49 | 3875 | |||
18 | 6000 | 864 | 6.94 | 4263 | |||
22.6 | 7000 | 1084.8 | 6.45 | 4572 | |||
27.4 | 8000 | 1315.2 | 6.08 | 4752 | |||
30.7 | 8900 | 1473.6 | 6.04 | 4925 | 85℃ | ||
EOLO CN26*8 | 44.4 | 1.6 | 1000 | 71.04 | 14.08 | 1390 |
|
2.6 | 1500 | 115.44 | 12.99 | 1696 | |||
3.8 | 2000 | 168.72 | 11.85 | 1984 | |||
5.2 | 2500 | 230.88 | 10.83 | 2189 | |||
6.7 | 3000 | 297.48 | 10.08 | 2386 | |||
8.3 | 3500 | 368.52 | 9.50 | 2581 | |||
10.1 | 4000 | 448.44 | 8.92 | 2759 | |||
13.9 | 5000 | 617.16 | 8.10 | 3063 | |||
18.1 | 6000 | 803.64 | 7.47 | 3322 | |||
23.1 | 7000 | 1025.64 | 6.83 | 3586 | |||
28.2 | 8000 | 1252.08 | 6.39 | 3792 | |||
33.8 | 9000 | 1500.72 | 6.00 | 4006 | |||
42.9 | 10500 | 1904.76 | 5.51 | 4313 | |||
48 | 1.5 | 1000 | 72 | 13.89 | 1385 | ||
2.4 | 1500 | 115.2 | 13.02 | 1702 | |||
3.5 | 2000 | 168 | 11.90 | 1986 | |||
4.8 | 2500 | 230.4 | 10.85 | 2194 | |||
6.2 | 3000 | 297.6 | 10.08 | 2377 | |||
7.7 | 3500 | 369.6 | 9.47 | 2585 | |||
9.2 | 4000 | 441.6 | 9.06 | 2774 | |||
12.8 | 5000 | 614.4 | 8.14 | 3053 | |||
16.9 | 6000 | 811.2 | 7.40 | 3332 | |||
21 | 7000 | 1008 | 6.94 | 3595 | |||
26 | 8000 | 1248 | 6.41 | 3788 | |||
30.8 | 9000 | 1478.4 | 6.09 | 4010 | |||
36.4 | 10000 | 1747.2 | 5.72 | 4219 | |||
49.6 | 12200 | 2380.8 | 5.12 | 4636 | 5min 150℃ |
|
Specifications |
X8012S |
Max Continuous Current |
81A/30s |
|
Stator Diameter |
80mm |
Max Continuous Power |
3888W |
|
Stator Thickness |
12mm |
Weight |
517g |
|
No.of Stator Slots |
24 |
Rotor Diameter |
89.3mm |
|
No.of Rotor Poles |
28 |
Body Length |
50.5mm |
|
Motor Kv |
150 |
Max Lipo Cell |
12S |
|
NO-Load Current(A/10V) |
1.3A |
ESC |
80A |
|
Motor Resistance |
36mΩ |
Recommend Prop(inch) |
EOLO CN24*7.5 26*8 |
|
Propeller (inch) |
Voltage (V) |
Current (A) |
Thrust (g) |
Watts (W) |
Efficiency (g/W) |
RPM |
Load temperature in 100% throttle |
|
EOLO CN24*7.5 |
44.4 |
1.9 |
1000 |
84.36 |
11.85 |
1774 |
|
|
3 |
1500 |
133.2 |
11.26 |
2136 |
|||
|
4.3 |
2000 |
190.92 |
10.48 |
2452 |
|||
|
5.8 |
2500 |
257.52 |
9.71 |
2755 |
|||
|
7.4 |
3000 |
328.56 |
9.13 |
3015 |
|||
|
9.1 |
3500 |
404.04 |
8.66 |
3268 |
|||
|
11 |
4000 |
488.4 |
8.19 |
3494 |
|||
|
15.2 |
5000 |
674.88 |
7.41 |
3896 |
|||
|
19.7 |
6000 |
874.68 |
6.86 |
4226 |
|||
|
24.6 |
7000 |
1092.24 |
6.41 |
4605 |
|||
|
29.9 |
8000 |
1327.56 |
6.03 |
4850 |
|||
|
35.6 |
9000 |
1580.64 |
5.69 |
5140 |
|||
|
43.4 |
10400 |
1926.96 |
5.40 |
5356 |
|||
|
48 |
1.8 |
1000 |
86.4 |
11.57 |
1785 |
||
|
2.9 |
1500 |
139.2 |
10.78 |
2135 |
|||
|
4.1 |
2000 |
196.8 |
10.16 |
2457 |
|||
|
5.5 |
2500 |
264 |
9.47 |
2760 |
|||
|
7 |
3000 |
336 |
8.93 |
3025 |
|||
|
8.6 |
3500 |
412.8 |
8.48 |
3277 |
|||
|
10.4 |
4000 |
499.2 |
8.01 |
3501 |
|||
|
14.2 |
5000 |
681.6 |
7.34 |
3904 |
|||
|
18.6 |
6000 |
892.8 |
6.72 |
4235 |
|||
|
23.1 |
7000 |
1108.8 |
6.31 |
4611 |
|||
|
28 |
8000 |
1344 |
5.95 |
4854 |
|||
|
33.2 |
9000 |
1593.6 |
5.65 |
5158 |
|||
|
39.3 |
10000 |
1886.4 |
5.30 |
5403 |
|||
|
48.7 |
11700 |
2337.6 |
5.01 |
5703 |
135℃ |
||
|
EOLO CN26*8 |
44.4 |
1.7 |
1000 |
75.48 |
13.25 |
1417 |
|
|
2.8 |
1500 |
124.32 |
12.07 |
1705 |
|||
|
4 |
2000 |
177.6 |
11.26 |
1978 |
|||
|
5.4 |
2500 |
239.76 |
10.43 |
2173 |
|||
|
7 |
3000 |
310.8 |
9.65 |
2378 |
|||
|
8.6 |
3500 |
381.84 |
9.17 |
2564 |
|||
|
10.4 |
4000 |
461.76 |
8.66 |
2755 |
|||
|
14.3 |
5000 |
634.92 |
7.88 |
3075 |
|||
|
18.6 |
6000 |
825.84 |
7.27 |
3360 |
|||
|
23.3 |
7000 |
1034.52 |
6.77 |
3590 |
|||
|
28.6 |
8000 |
1269.84 |
6.30 |
3817 |
|||
|
34.3 |
9000 |
1522.92 |
5.91 |
4012 |
|||
|
40.6 |
10000 |
1802.64 |
5.55 |
4247 |
|||
|
55.4 |
12000 |
2459.76 |
4.88 |
4589 |
|||
|
70.6 |
14300 |
3134.64 |
4.56 |
4955 |
|||
|
48 |
1.6 |
1000 |
76.8 |
13.02 |
1420 |
||
|
2.6 |
1500 |
124.8 |
12.02 |
1716 |
|||
|
3.7 |
2000 |
177.6 |
11.26 |
1985 |
|||
|
5 |
2500 |
240 |
10.42 |
2166 |
|||
|
6.4 |
3000 |
307.2 |
9.77 |
2392 |
|||
|
8 |
3500 |
384 |
9.11 |
2545 |
|||
|
9.6 |
4000 |
460.8 |
8.68 |
2770 |
|||
|
13.2 |
5000 |
633.6 |
7.89 |
3062 |
|||
|
17.3 |
6000 |
830.4 |
7.23 |
3371 |
|||
|
21.6 |
7000 |
1036.8 |
6.75 |
3602 |
|||
|
26.4 |
8000 |
1267.2 |
6.31 |
3833 |
|||
|
31.8 |
9000 |
1526.4 |
5.90 |
4025 |
|||
|
37.6 |
10000 |
1804.8 |
5.54 |
4253 |
|||
|
51.3 |
12000 |
2462.4 |
4.87 |
4591 |
|||
|
66.5 |
14000 |
3192 |
4.39 |
4932 |
|||
|
80.2 |
15500 |
3849.6 |
4.03 |
5239 |
3min 150℃ |
