This product is designed solely for use by RC model enthusiasts and for recreational purposes. It is

not intended for professional, military, commercial, or industrial applications.











This product is designed solely for use by RC model enthusiasts and for recreational purposes. It isnot intended for professional, military, commercial, or industrial applications.


Motor Model / KV X6215S/ KV170 X6215S/ KV195 X6215S/ KV220 X6215S/ KV350 X6215S/ KV275
Stator/Rotor Poles 24N28P 24N28P 24N28P 24N28P 24N28P
Internal resistance 53mΩ 45mΩ 45mΩ 15mΩ 22mΩ
Motor size φ69.3*43.0mm
 φ69.3*43.0mm
 φ69.3*43.0mm
 φ69.3*43.0mm
 φ69.3*43.0mm
Shaft diameter 4.0mm 4.0mm 4.0mm 4.0mm 4.0mm
AWG 20AWG 100mm 20AWG 100mm 20AWG 100mm 20AWG 100mm 20AWG 100mm
Motor weight(wire included) 363g 361g 361g 363g 372g
Motor weight(wire excluded) —— —— —— —— ——
Rated operational voltage 12S 12S 12S 6S 8S
No-load current 0.7A/10V 0.9A 0.9A 1.5A/10V 1.2A
Maximum continuous power 2780W 3648W 3648W 1925W 2990W
Maximum continuous current 58A/30s 76A/30s 76A/30s 77A/30s 89A/30s
ESC recommended use 80A 80A 80A 80A 80-100A
Propeller size recommended use EOLO C20*6.2 CN24*7.5 EOLO C20*6.2 CN22*6.5 EOLO C20*6.2 CN22*6.5 EOLOC20*6.2 CN22*6.5 EOLOC20*6.2 CN22*6.5

X6215S

KV170 KV195 KV220 KV350 KV275

Specifications

X6215S

Max Continuous Current

58A/30s

Stator Diameter

62mm

Max Continuous Power

2780W

Stator Thickness

15mm

Weight

363g

No.of Stator Slots

24

Rotor Diameter

69.3mm

No.of Rotor Poles

28

Body Length

43mm

Motor Kv

170

Max Lipo Cell

12S

NO-Load Current(A/10V)

0.7A

ESC

80A

Motor Resistance

53mΩ

Recommend Prop(inch)

EOLO C20*6.2 CN24*7.5





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency

(g/W)

RPM

Load temperature in 100% throttle

EOLO C20*6.2

44.4

2.1

1000

93.24

10.73

2570



5.2

2000

230.88

8.66

3634

7

2500

310.8

8.04

4021

8.9

3000

395.16

7.59

4420

11

3500

488.4

7.17

4730

13.3

4000

590.52

6.77

5072

18.4

5000

816.96

6.12

5606

24.1

6300

1070.04

5.89

6259

48

2

1000

96

10.42

2571

4.8

2000

230.4

8.68

3628

6.5

2500

312

8.01

4011

8.3

3000

398.4

7.53

4425

10.2

3500

489.6

7.15

4732

12.3

4000

590.4

6.78

5067

16.8

5000

806.4

6.20

5610

22.1

6000

1060.8

5.66

6163

27.2

6950

1305.6

5.32

6684

76℃

EOLO CN22*6.5

44.4

1.7

1000

75.48

13.25

2169



4.4

2000

195.36

10.24

2980

6

2500

266.4

9.38

3322

7.7

3000

341.88

8.78

3621

9.6

3500

426.24

8.21

3904

11.6

4000

515.04

7.77

4178

16.2

5000

719.28

6.95

4674

21.3

6000

945.72

6.34

5120

26.8

7000

1189.92

5.88

5443

32.5

8000

1443

5.54

5760

35.9

8600

1593.96

5.40

5994

48

1.6

1000

76.8

13.02

2156

4.1

2000

196.8

10.16

2954

5.5

2500

264

9.47

3310

7.1

3000

340.8

8.80

3651

8.9

3500

427.2

8.19

3911

10.7

4000

513.6

7.79

4156

14.9

5000

715.2

6.99

4663

19.5

6000

936

6.41

5112

24.6

7000

1180.8

5.93

5425

30.2

8000

1449.6

5.52

5834

36.5

9000

1752

5.14

6156

40.9

9800

1963.2

4.99

6373

3min 101℃

EOLO CN24*7.5

44.4

1.6

1000

71.04

14.08

1665



4

2000

177.6

11.26

2314

5.6

2500

248.64

10.05

2598

7.3

3000

324.12

9.26

2873

9.1

3500

404.04

8.66

3077

10.9

4000

483.96

8.27

3288

15.4

5000

683.76

7.31

3634

20.1

6000

892.44

6.72

3977

25.2

7000

1118.88

6.26

4316

30.8

8000

1367.52

5.85

4610

36.9

9000

1638.36

5.49

4903

44.2

10000

1962.48

5.10

5171

52.1

11400

2313.24

4.93

5604

48

1.5

1000

72

13.89

1662

3.8

2000

182.4

10.96

2311

5.1

2500

244.8

10.21

2595

6.6

3000

316.8

9.47

2876

8.3

3500

398.4

8.79

3078

10

4000

480

8.33

3285

14

5000

672

7.44

3630

18.3

6000

878.4

6.83

3972

23.3

7000

1118.4

6.26

4320

28.6

8000

1372.8

5.83

4611

34.3

9000

1646.4

5.47

4908

40.4

10000

1939.2

5.16

5174

48.2

11000

2313.6

4.75

5654

59.2

12700

2841.6

4.47

5938

30s 110℃







图片 1.jpg

Specifications

X6215S

Max Continuous Current

76A/30s

Stator Diameter

62mm

Max Continuous Power

3648W

Stator Thickness

15mm

Weight

361g

No.of Stator Slots

24

Rotor Diameter

69.3mm

No.of Rotor Poles

28

Body Length

43mm

Motor Kv

195

Max Lipo Cell

12S

NO-Load Current(A/10V)

0.9A

ESC

80A

Motor Resistance

34mΩ

Recommend Prop(inch)

EOLO C20*6.2 CN22*6.5





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in100%6 throttle

EOLO C20*6.2

44.4

2.2

1000

97.68

10.24

2570

　

5.2

2000

230.88

8.66

3576

7.1

2500

315.24

7.93

3979

9

3000

399.6

7.51

4373

11.1

3500

492.84

7.10

4682

13.6

4000

603.84

6.62

5023

18.6

5000

825.84

6.05

5602

24.1

6000

1070.04

5.61

6072

30.2

7000

1340.88

5.22

6540

37

8000

1642.8

4.87

6920

43.9

9200

1949.16

4.72

7552

48

2

1000

96

10.42

2571

4.9

2000

235.2

8.50

3574

6.6

2500

316.8

7.89

3980

8.5

3000

408

7.35

4370

10.4

3500

499.2

7.01

4685

12.6

4000

604.8

6.61

5021

17.3

5000

830.4

6.02

5603

22.6

6000

1084.8

5.53

6068

28.2

7000

1353.6

5.17

6542

34.3

8000

1646.4

4.86

6925

40.8

9000

1958.4

4.60

7418

49.7

10400

2385.6

4.36

8034

1min30s 101 ℃

EOLO CN22*6.5

44.4

1.8

1000

79.92

12.51

2078

　

4.6

2000

204.24

9.79

2873

6.2

2500

275.28

9.08

3211

8

3000

355.2

8.45

3484

9.9

3500

439.56

7.96

3762

12

4000

532.8

7.51

4048

16.7

5000

741.48

6.74

4498

21.9

6000

972.36

6.17

4914

27.6

7000

1225.44

5.71

5260

33.9

8000

1505.16

5.32

5635

40.8

9000

1811.52

4.97

5931

48.3

10000

2144.52

4.66

6273

67

12400

2974.8

4.17

6979

48

1.7

1000

81.6

12.25

2076

4.3

2000

206.4

9.69

2870

5.9

2500

283.2

8.83

3214

7.5

3000

360

8.33

3480

9.3

3500

446.4

7.84

3758

11.2

4000

537.6

7.44

4052

15.6

5000

748.8

6.68

4497

20.3

6000

974.4

6.16

4915

25.7

7000

1233.6

5.67

5267

31.8

8000

1526.4

5.24

5638

38.1

9000

1828.8

4.92

5937

45.3

10000

2174.4

4.60

6270

60.9

12000

2923.2

4.11

6795

77.4

14000

3715.2

3.77

7350

30s 125 ℃







图片 1.jpg

Specifications

X6215-S

Weight

69.3mm

No.of Stator Slots

24

Rotor Diameter

37.5mm

No.of Rotor Poles

28

Body Length

12S

Motor Kv

220

Max Lipo Cell

80A

NO-Load Current(A/10V)

1.1A

ESC

EOLO C18*6.5

Motor Resistance

28mΩ

Recommend Prop(inch)



Max Continuous Current

53A/30s





Max Continuous Power

2500W









EOLO C18*6.5

Throttle

Voltage (V)

Amps(A)

Input power （ W ）

RPM

Torque (N.m)

Output power (W)

Thrust (g)

Efficiency (g/W)

Load temperature in

100%6 throttle

30

44.74

3.019

135.07

2934.6

0.53

162.86

927.13

6.86

　

40

44.7

5.813

259.84

3996.26

0.86

359.87

1749.33

6.73

50

44.6

9.371

417.95

4982.16

1.31

683.41

2743.44

6.56

52

44.62

10.24

456.91

5164.08

1.39

751.63

2941.12

6.44

54

44.54

11.299

503.26

5348.78

1.55

868.12

3224.53

6.41

56

44.56

12.124

540.25

5484.64

1.59

913.14

3384.73

6.27

58

44.55

13.334

594.03

5679.71

1.77

1052.67

3644.15

6.13

60

44.47

14.526

645.97

5853.5

1.85

1133.92

3944.26

6.11

62

44.46

15.503

689.26

6001.57

1.94

1219.16

4139.15

6.01

64

44.47

16.629

739.49

6186.6

2.05

1328.01

4316

5.84

66

44.44

18.116

805.08

6364.32

2.2

1466.12

4585.29

5.70

68

44.4

19.376

860.29

6531.97

2.26

1545.78

4878.06

5.67

70

44.39

20.964

930.59

6697.16

2.45

1718.11

5168.61

5.55

72

44.35

22.214

985.19

6871.53

2.51

1806.02

5408.49

5.49

74

44.27

23.507

1040.65

7038.71

2.56

1886.81

5632.66

5.41

76

44.27

25.899

1146.55

7223.19

2.79

2110.23

6058.97

5.28

78

44.23

27.31

1207.92

7390.2

2.92

2259.62

6276.54

5.20

80

44.2

29.592

1307.97

7554.49

3.09

2444.33

6633.44

5.07

82

44.15

31.211

1377.97

7718.17

3.16

2553.86

6836.16

4.96

84

44.11

33.581

1481.26

7871.87

3.34

2753.09

7180.87

4.85

86

44

35.53

1563.32

8042.69

3.45

2905.47

7524.17

4.81

88

43.98

38.255

1682.45

8213.33

3.63

3121.92

7899.02

4.69

90

43.94

40.531

1780.93

8370.29

3.79

3321.82

8168.62

4.59

100

43.88

46.216

2027.96

8732.33

4.13

3776.38

8931.16

4.40







　









　

30

48.06

3.254

156.39

3098.86

0.48

155.75

1073.7

6.87

40

47.98

6.355

304.91

4259.32

0.94

419.24

2033.76

6.67

50

47.9

10.403

498.30

5273.47

1.43

789.64

3136.03

6.29

52

47.88

11.286

540.37

5435.93

1.55

882.27

3380.76

6.26

54

47.85

12.169

582.29

5615.99

1.6

940.89

3566.65

6.13

56

47.82

13.394

640.50

5821.46

1.79

1091.14

3848.01

6.01

58

47.8

14.597

697.74

5985.25

1.89

1184.51

4166.35

5.97

60

47.82

16.061

768.04

6175.39

2.07

1338.54

4448.27

5.79

62

47.76

17.207

821.81

6360.58

2.13

1418.64

4701.29

5.72

64

47.68

18.359

875.36

6545.38

2.21

1514.69

4929.84

5.63

66

47.69

19.596

934.53

6714.98

2.36

1659.4

5177.41

5.54

68

47.66

21.313

1015.78

6899.36

2.49

1798.89

5451.9

5.37

70

47.63

22.906

1091.01

7077.69

2.62

1941.73

5753.98

5.27

72

47.58

24.707

1175.56

7259.23

2.77

2105.55

6115.37

5.20

74

47.54

26.442

1257.05

7436.98

2.91

2266.13

6441.13

5.12

76

47.5

28.309

1344.68

7617.15

3.04

2424.72

6735.25

5.01

78

47.48

30.529

1449.52

7783.39

3.23

2632.49

7153.38

4.94

80

47.4

32.648

1547.52

7963.9

3.37

2810.29

7505.72

4.85

82

47.38

34.87

1652.14

8139.28

3.53

3008.55

7789.19

4.71

84

47.32

37.377

1768.68

8297.24

3.69

3205.94

8200.96

4.64

86

47.28

39.717

1877.82

8482.99

3.85

3419.84

8456.51

4.50

88

47.2

42.184

1991.08

8656.08

3.97

3598.39

8867.18

4.45

90

47.12

44.705

2106.50

8819.39

4.14

3823.27

9226.92

4.38

100

47.04

51.258

2411.18

9192.48

4.52

4350.78

10027.65

4.16

10min 100 ℃







图片 1.jpg

Specifications

X6215S

Max Continuous Current

77A/30s

Stator Diameter

62mm

Max Continuous Power

1925W

Stator Thickness

15mm

Weight

363g

No.of Stator Slots

24

Rotor Diameter

69.3mm

No.of Rotor Poles

28

Body Length

43mm

Motor Kv

350

Max Lipo Cell

6S

NO-Load Current(A/10V)

1.5A

ESC

80A

Motor Resistance

15mΩ

Recommend Prop(inch)

EOLOC20*6.2 CN22*6.5





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency

(g/W)

RPM

Load temperature in 100% throttle

EOLO C20*6.2

22.2

4.1

1000

91.02

10.99

2571



6.9

1500

153.18

9.79

3146

10.1

2000

224.22

8.92

3639

14

2500

310.8

8.04

4100

18.1

3000

401.82

7.47

4416

22.6

3500

501.72

6.98

4776

27.5

4000

610.5

6.55

5114

38

5000

843.6

5.93

5680

44.8

5600

994.56

5.63

6087

25

3.7

1000

92.5

10.81

2567

6.3

1500

157.5

9.52

3150

9.3

2000

232.5

8.60

3641

12.7

2500

317.5

7.87

4097

16.4

3000

410

7.32

4421

20.3

3500

507.5

6.90

4780

24.4

4000

610

6.56

5117

34.2

5000

855

5.85

5676

44.9

6000

1122.5

5.35

6168

53.7

6850

1342.5

5.10

6649

80℃

EOLO CN22*6.5

22.2

3.5

1000

77.7

12.87

2045



6.2

1500

137.64

10.90

2498

9.3

2000

206.46

9.69

2861

12.7

2500

281.94

8.87

3178

16.5

3000

366.3

8.19

3496

20.6

3500

457.32

7.65

3754

24.9

4000

552.78

7.24

3986

35

5000

777

6.44

4459

46.7

6000

1036.74

5.79

4884

64.4

7550

1429.68

5.28

5223

25

3.2

1000

80

12.50

2044

5.6

1500

140

10.71

2495

8.3

2000

207.5

9.64

2862

11.2

2500

280

8.93

3170

14.6

3000

365

8.22

3488

18.3

3500

457.5

7.65

3759

22.1

4000

552.5

7.24

3987

31.2

5000

780

6.41

4461

40.8

6000

1020

5.88

4880

52.5

7000

1312.5

5.33

5224

64.6

8000

1615

4.95

5593

76.7

9000

1917.5

4.69

6079

1min30s 91℃







图片 1.jpg

Specifications

X6215S

Max Continuous Current

89A/30s

Stator Diameter

62mm

Max Continuous Power

2990W

Stator Thickness

15mm

Weight

372g

No.of Stator Slots

24

Rotor Diameter

69.3mm

No.of Rotor Poles

28

Body Length

43mm

Motor Kv

275

Max Lipo Cell

8S

NO-Load Current(A/10V)

1.2A

ESC

80-100A

Motor Resistance

22mΩ

Recommend Prop(inch)

EOLOC20*6.2 CN22*6.5





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in 100% throttle

EOLO C20*6.2

29.6

3.5

1000

103.6

9.65

2617

　

5.8

1500

171.68

8.74

3225

8.3

2000

245.68

8.14

3674

11.5

2500

340.4

7.34

4119

14.8

3000

438.08

6.85

4522

18.6

3500

550.56

6.36

4895

22.5

4000

666

6.01

5237

31.3

5000

926.48

5.40

5838

40.8

6000

1207.68

4.97

6331

46.5

6500

1376.4

4.72

6564

33.6

3.1

1000

104.16

9.60

2610

5.15

1500

173.04

8.67

3221

7.4

2000

248.64

8.04

3671

10.1

2500

339.36

7.37

4115

13.2

3000

443.52

6.76

4518

16.5

3500

554.4

6.31

4897

20.1

4000

675.36

5.92

5240

27.6

5000

927.36

5.39

5845

36.2

6000

1216.32

4.93

6325

45.1

7000

1515.36

4.62

6850

56.8

8200

1908.48

4.30

7260

1min30s 100℃

EOLO CN22 * 6.5-inch folding paddle

29.6

2.9

1000

85.84

11.65

2149

　

5

1500

148

10.14

2590

7.4

2000

219.04

9.13

3012

9.9

2500

293.04

8.53

3334

12.8

3000

378.88

7.92

3630

16

3500

473.6

7.39

3915

19.6

4000

580.16

6.89

4213

27.5

5000

814

6.14

4659

36.7

6000

1086.32

5.52

5041

47.3

7000

1400.08

5.00

5466

58.5

8000

1731.6

4.62

5824

68.9

9000

2039.44

4.41

6081

33.6

2.6

1000

87.36

11.45

2140

4.4

1500

147.84

10.15

2588

6.6

2000

221.76

9.02

3011

8.9

2500

299.04

8.36

3340

11.5

3000

386.4

7.76

3628

14.4

3500

483.84

7.23

3910

17.4

4000

584.64

6.84

4218

24.5

5000

823.2

6.07

4650

32.4

6000

1088.64

5.51

5043

41.7

7000

1401.12

5.00

5464

51.5

8000

1730.4

4.62

5820

63.1

9000

2120.16

4.24

6181

88.4

11000

2970.24

3.70

6632

30s 105℃
