Motor Model / KV X4110S/ KV340 X4110S/ KV400 X4110S/ KV460 X4110S/ KV580 X4110S/ KV680
Stator/Rotor Poles 12N14P 12N14P 12N14P 12N14P 12N14P
Internal resistance 119mΩ 78mΩ 62mΩ 42mΩ 34mΩ
Motor size φ47.5*37.5mm
φ47.5*37.5mm
φ47.5*37.5mm
φ47.5*37.5mm
φ47.5*37.5mm
Shaft diameter 4.0mm 4.0mm 4.0mm 4.0mm 4.0mm
AWG 20AWG 600mm 20AWG 600mm 20AWG 600mm 20AWG 600mm 20AWG 600mm
Motor weight(wire included) 149g 149g 150g 148g 150g
Motor weight(wire excluded) 暂无数据 No data No data No data No data
Rated operational voltage 6S 6S 6S 6S 45
No-load current 0.5A/10V 0.5A/10V 0.6A/10V 0.8A/10V 1A/10V
Maximum continuous power 675W 1125W 1075W 1113W 856.8W
Maximum continuous current 27A/30s 45A/30s 43A/30s 53A/30s 51A/30s
ESC recommended use 40 40A 40A 50A 50A
Propeller size recommended use EOLO CN13*5 15*5.5 16*6 EOLO CN13*5 15*5.5 16*6 EOLO CN12*5 13*5 15*5.5 EOLO 13*5 15*5.5 EOLO CN13*5 15*5.5

Specifications

X4110S

Max Continuous Current

27A/30s

Stator Diameter

41mm

Max Continuous Power

675W

Stator Thickness

10mm

Weight

149g

No.of Stator Slots

12

Rotor Diameter

47.5mm

No.of Rotor Poles

14

Body Length

37.5mm

Motor Kv

340

Max Lipo Cell

6S

NO-Load Current(A/10V)

0.5A

ESC

40A

Motor Resistance

119mΩ

Recommend Prop(inch)

EOLO CN13*5 15*5.5 16*6





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency

(g/W)

RPM

Load temperature in 100% throttle

EOLO CN13*5

22.2

0.7

200

15.54

12.87

2525



1.6

400

35.52

11.26

3492

2.7

600

59.94

10.01

4266

4

800

88.8

9.01

4867

5.5

1000

122.1

8.19

5371

7.2

1200

159.84

7.51

5913

9.5

1450

210.9

6.88

6432

25

0.6

200

15

13.33

2530

1.4

400

35

11.43

3488

2.4

600

60

10.00

4272

3.6

800

90

8.89

4855

4.9

1000

122.5

8.16

5383

6.4

1200

160

7.50

5920

8.1

1400

202.5

6.91

6332

9.8

1600

245

6.53

6734

11.8

1800

295

6.10

7103

44℃

EOLO CN15*5.5

22.2

0.6

200

13.32

15.02

1943



1.4

400

31.08

12.87

2754

2.4

600

53.28

11.26

3367

3.5

800

77.7

10.30

3838

4.9

1000

108.78

9.19

4272

6.4

1200

142.08

8.45

4642

8

1400

177.6

7.88

4981

9.8

1600

217.56

7.35

5338

11.8

1800

261.96

6.87

5614

14.9

2100

330.78

6.35

6015

25

0.5

200

12.5

16.00

1952

1.2

400

30

13.33

2733

2.1

600

52.5

11.43

3351

3.2

800

80

10.00

3854

4.4

1000

110

9.09

4285

5.7

1200

142.5

8.42

4672

7.2

1400

180

7.78

4995

8.8

1600

220

7.27

5321

10.5

1800

262.5

6.86

5620

12.5

2000

312.5

6.40

5911

15.1

2250

377.5

5.96

6208

18.5

2580

462.5

5.58

6574

80℃

EOLO CN16*6

22.2

0.5

200

11.1

18.02

1651



1.3

400

28.86

13.86

2271

2.2

600

48.84

12.29

2698

3.3

800

73.26

10.92

3094

4.6

1000

102.12

9.79

3466

6

1200

133.2

9.01

3738

7.6

1400

168.72

8.30

4027

9.3

1600

206.46

7.75

4315

11.2

1800

248.64

7.24

4556

13.3

2000

295.26

6.77

4817

16.3

2250

361.86

6.22

5098

19.6

2500

435.12

5.75

5360

22.1

2700

490.62

5.50

5502

25

0.5

200

12.5

16.00

1665

1.2

400

30

13.33

2264

2

600

50

12.00

2695

3

800

75

10.67

3086

4.1

1000

102.5

9.76

3472

5.4

1200

135

8.89

3745

6.8

1400

170

8.24

4030

8.3

1600

207.5

7.71

4311

10.1

1800

252.5

7.13

4564

11.9

2000

297.5

6.72

4825

14.3

2250

357.5

6.29

5088

17.3

2500

432.5

5.78

5374

20.6

2750

515

5.34

5614

25.1

3000

627.5

4.78

5864

26.7

3160

667.5

4.73

5985

1min30s 85℃







4110 kv340.jpg

Specifications

X4110S

Max Continuous Current

45A/30s

Stator Diameter

41mm

Max Continuous Power

1125W

Stator Thickness

10mm

Weight

149g

No.of Stator Slots

12

Rotor Diameter

47.5mm

No.of Rotor Poles

14

Body Length

37.5mm

Motor Kv

400

Max Lipo Cell

6S

NO-Load Current(A/10V)

0.5A

ESC

40A

Motor Resistance

78mΩ

Recommend Prop(inch)

EOLO CN13*5 15*5.5 16*6





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency

(g/W)

RPM

Load temperature in 100% throttle

EOLO CN13*5

22.2

0.7

200

15.54

12.87

2457



1.6

400

35.52

11.26

3454

2.7

600

59.94

10.01

4233

4.1

800

91.02

8.79

4848

5.6

1000

124.32

8.04

5352

7.3

1200

162.06

7.40

5884

9.1

1400

202.02

6.93

6296

11.1

1600

246.42

6.49

6734

13.4

1800

297.48

6.05

7114

15.8

2000

350.76

5.70

7435

17.3

2150

384.06

5.60

7681

25

0.6

200

15

13.33

2466

1.5

400

37.5

10.67

3445

2.5

600

62.5

9.60

4251

3.6

800

90

8.89

4862

5

1000

125

8.00

5371

6.5

1200

162.5

7.38

5895

8.2

1400

205

6.83

6310

10

1600

250

6.40

6744

12

1800

300

6.00

7105

14.3

2000

357.5

5.59

7450

17

2250

425

5.29

7985

20.2

2500

505

4.95

8217

21.6

2650

540

4.91

8442

70℃

EOLO CN15*5.5

22.2

0.6

200

13.32

15.02

1980



1.4

400

31.08

12.87

2768

2.4

600

53.28

11.26

3381

3.6

800

79.92

10.01

3895

5.1

1000

113.22

8.83

4310

6.6

1200

146.52

8.19

4675

8.3

1400

184.26

7.60

4952

10.1

1600

224.22

7.14

5388

12.1

1800

268.62

6.70

5631

14.2

2000

315.24

6.34

5942

17.2

2250

381.84

5.89

6315

20.7

2500

459.54

5.44

6632

24.1

2750

535.02

5.14

6928

26

2940

577.2

5.09

7057

25

0.5

200

12.5

16.00

1988

1.3

400

32.5

12.31

2775

2.3

600

57.5

10.43

3377

3.4

800

85

9.41

3891

4.6

1000

115

8.70

4302

5.9

1200

147.5

8.14

4672

7.4

1400

185

7.57

4948

9

1600

225

7.11

5371

10.8

1800

270

6.67

5633

12.8

2000

320

6.25

5955

15.4

2250

385

5.84

6320

18.5

2500

462.5

5.41

6597

21.1

2750

527.5

5.21

6921

24.7

3000

617.5

4.86

7226

32.8

3550

820

4.33

7638

4min 145℃

EOLO CN16*6

22.2

0.6

200

13.32

15.02

1675



1.4

400

31.08

12.87

2284

2.4

600

53.28

11.26

2705

3.6

800

79.92

10.01

3112

5

1000

111

9.01

3485

6.4

1200

142.08

8.45

3760

8

1400

177.6

7.88

4052

9.8

1600

217.56

7.35

4377

11.8

1800

261.96

6.87

4592

13.9

2000

308.58

6.48

4850

16.9

2250

375.18

6.00

5122

20.1

2500

446.22

5.60

5375

24.2

2750

537.24

5.12

5682

29.8

3000

661.56

4.53

5909

36.4

3450

808.08

4.27

6289

25

0.5

200

12.5

16.00

1677

1.3

400

32.5

12.31

2295

2.1

600

52.5

11.43

2711

3.2

800

80

10.00

3118

4.3

1000

107.5

9.30

3475

5.6

1200

140

8.57

3789

7.1

1400

177.5

7.89

4066

8.8

1600

220

7.27

4385

10.5

1800

262.5

6.86

4601

12.3

2000

307.5

6.50

4865

15

2250

375

6.00

5114

18.1

2500

452.5

5.52

5374

22.1

2750

552.5

4.98

5671

26.4

3000

660

4.55

5911

35.4

3500

885

3.95

6442

44.3

4000

1107.5

3.61

6667

1min 150℃







4110 kv400.jpg

Specifications

X4110S

Max Continuous Current

43A/30s

Stator Diameter

41mm

Max Continuous Power

1075W

Stator Thickness

10mm

Weight

150g

No.of Stator Slots

12

Rotor Diameter

47.5mm

No.of Rotor Poles

14

Body Length

37.5mm

Motor Kv

460

Max Lipo Cell

6S

NO-Load Current(A/10V)

0.6A

ESC

40A

Motor Resistance

62mΩ

Recommend Prop(inch)

EOLO CN12*5 13*5 15*5.5





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency

(g/W)

RPM

Load temperature in 100% throttle

EOLO CN12*5

22.2

0.8

200

17.76

11.26

3087



1.9

400

42.18

9.48

4128

3.2

600

71.04

8.45

5025

4.7

800

104.34

7.67

5776

6.4

1000

142.08

7.04

6420

8.2

1200

182.04

6.59

6947

10.2

1400

226.44

6.18

7498

12.3

1600

273.06

5.86

7915

14.7

1800

326.34

5.52

8330

16.9

2000

375.18

5.33

8691

25

0.7

200

17.5

11.43

3075

1.7

400

42.5

9.41

4152

2.9

600

72.5

8.28

5015

4.2

800

105

7.62

5792

5.7

1000

142.5

7.02

6445

7.3

1200

182.5

6.58

6953

9.1

1400

227.5

6.15

7502

11

1600

275

5.82

7933

13.1

1800

327.5

5.50

8316

15.3

2000

382.5

5.23

8733

18.2

2250

455

4.95

9284

20.8

2470

520

4.75

9602

53℃

EOLO CN13*5

22.2

0.7

200

15.54

12.87

2557



1.7

400

37.74

10.60

3510

2.9

600

64.38

9.32

4297

4.3

800

95.46

8.38

4936

5.8

1000

128.76

7.77

5476

7.5

1200

166.5

7.21

5961

9.4

1400

208.68

6.71

6420

11.4

1600

253.08

6.32

6835

13.5

1800

299.7

6.01

7177

15.9

2000

352.98

5.67

7548

19.2

2250

426.24

5.28

7995

22.1

2510

490.62

5.12

8330

25

0.7

200

17.5

11.43

2554

1.5

400

37.5

10.67

3526

2.6

600

65

9.23

4302

3.8

800

95

8.42

4987

5.2

1000

130

7.69

5465

6.7

1200

167.5

7.16

5955

8.4

1400

210

6.67

6431

10.2

1600

255

6.27

6852

12.1

1800

302.5

5.95

7185

14.2

2000

355

5.63

7562

17.2

2250

430

5.23

8005

20.3

2500

507.5

4.93

8262

23.5

2750

587.5

4.68

8684

27.6

3070

690

4.45

9127

85℃

EOLO CN15*5.5

22.2

0.6

200

13.32

15.02

1932



1.4

400

31.08

12.87

2788

2.5

600

55.5

10.81

3407

3.7

800

82.14

9.74

3891

5.1

1000

113.22

8.83

4342

6.6

1200

146.52

8.19

4735

8.2

1400

182.04

7.69

5075

10.1

1600

224.22

7.14

5396

12.1

1800

268.62

6.70

5694

14.3

2000

317.46

6.30

5985

17.4

2250

386.28

5.82

6289

21.1

2500

468.42

5.34

6542

24.9

2750

552.78

4.97

6841

28.4

3000

630.48

4.76

7162

34.5

3400

765.9

4.44

7473

25

0.5

200

12.5

16.00

1945

1.3

400

32.5

12.31

2797

2.2

600

55

10.91

3435

3.3

800

82.5

9.70

3879

4.5

1000

112.5

8.89

4356

5.9

1200

147.5

8.14

4785

7.4

1400

185

7.57

5099

9.1

1600

227.5

7.03

5367

10.8

1800

270

6.67

5687

12.8

2000

320

6.25

5994

15.6

2250

390

5.77

6277

18.6

2500

465

5.38

6551

22

2750

550

5.00

6860

25.3

3000

632.5

4.74

7155

34.2

3500

855

4.09

7649

42.1

3950

1052.5

3.75

8057

40s 100℃







4110 kv460.jpg

Specifications

X4110S

Max Continuous Current

53A/30s

Stator Diameter

41mm

Max Continuous Power

1113W

Stator Thickness

10mm

Weight

148g

No.of Stator Slots

12

Rotor Diameter

47.5mm

No.of Rotor Poles

14

Body Length

37.5mm

Motor Kv

580

Max Lipo Cell

5S

NO-Load Current(A/10V)

0.8A

ESC

50A

Motor Resistance

42mΩ

Recommend Prop(inch)

EOLO 13*5 15*5.5





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency

(g/W)

RPM

Load temperature in 100% throttle

EOLO CN13*5

18.5

0.9

200

16.65

12.01

2550



2.1

400

38.85

10.30

3513

3.5

600

64.75

9.27

4273

5.2

800

96.2

8.32

4887

7

1000

129.5

7.72

5466

9.1

1200

168.35

7.13

5891

11.4

1400

210.9

6.64

6368

13.9

1600

257.15

6.22

6765

16.6

1800

307.1

5.86

7165

19.6

2000

362.6

5.52

7482

23.5

2250

434.75

5.18

7954

28.7

2580

530.95

4.86

8427

21

0.8

200

16.8

11.90

2557

1.9

400

39.9

10.03

3520

3.1

600

65.1

9.22

4266

4.6

800

96.6

8.28

4890

6.3

1000

132.3

7.56

5471

8.1

1200

170.1

7.05

5866

10.1

1400

212.1

6.60

6325

12.3

1600

258.3

6.19

6780

14.7

1800

308.7

5.83

7182

17.3

2000

363.3

5.51

7462

20.7

2250

434.7

5.18

7933

24.5

2500

514.5

4.86

8336

28.7

2750

602.7

4.56

8681

36

3180

756

4.21

9314

95℃

EOLO CN15*5.5

18.5

0.8

200

14.8

13.51

2053























1.8

400

33.3

12.01

2787

3.1

600

57.35

10.46

3454

4.7

800

86.95

9.20

3948

6.4

1000

118.4

8.45

4365

8.4

1200

155.4

7.72

4783

10.5

1400

194.25

7.21

5131

12.8

1600

236.8

6.76

5441

15.2

1800

281.2

6.40

5706

18.1

2000

334.85

5.97

6002

21.8

2250

403.3

5.58

6317

26

2500

481

5.20

6636

30.6

2750

566.1

4.86

6896

36.4

3000

673.4

4.46

7179

40.9

3270

756.65

4.32

7363

21

0.7

200

14.7

13.61

2074

1.6

400

33.6

11.90

2765

2.8

600

58.8

10.20

3461

4.1

800

86.1

9.29

3966

5.6

1000

117.6

8.50

4325

7.4

1200

155.4

7.72

4764

9.3

1400

195.3

7.17

5169

11.4

1600

239.4

6.68

5484

13.6

1800

285.6

6.30

5714

16.1

2000

338.1

5.92

6020

19.4

2250

407.4

5.52

6342

22.9

2500

480.9

5.20

6654

27

2750

567

4.85

6901

32.4

3000

680.4

4.41

7165

44

3500

924

3.79

7645

52.6

3920

1104.6

3.55

8021

1min 100℃







4110 kv580.jpg

Specifications

X4110S

Max Continuous Current

51A/30s

Stator Diameter

41mm

Max Continuous Power

856.8W

Stator Thickness

10mm

Weight

150g

No.of Stator Slots

12

Rotor Diameter

47.5mm

No.of Rotor Poles

14

Body Length

37.5mm

Motor Kv

680

Max Lipo Cell

4S

NO-Load Current(A/10V)

1A

ESC

50A

Motor Resistance

34mΩ

Recommend Prop(inch)

EOLO CN13*5 15*5.5





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency

(g/W)

RPM

Load temperature in 100% throttle

EOLO CN13*5

14.8

1.1

200

16.28

12.29

2517



2.6

400

38.48

10.40

3496

4.4

600

65.12

9.21

4265

6.6

800

97.68

8.19

4869

9

1000

133.2

7.51

5420

11.7

1200

173.16

6.93

5917

14.7

1400

217.56

6.44

6315

18

1600

266.4

6.01

6781

21.5

1800

318.2

5.66

7118

25.4

2000

375.92

5.32

7495

29.4

2250

435.12

5.17

7865

16.8

1

200

16.8

11.90

2521

2.4

400

40.32

9.92

3502

3.9

600

65.52

9.16

4255

5.8

800

97.44

8.21

4875

7.9

1000

132.72

7.53

5436

10.3

1200

173.04

6.93

5933

12.9

1400

216.72

6.46

6305

15.8

1600

265.44

6.03

6774

19

1800

319.2

5.64

7142

22.3

2000

374.64

5.34

7483

26.7

2250

448.56

5.02

7948

31.4

2500

527.52

4.74

8268

36.6

2770

614.88

4.50

8644

75℃

EOLO CN15*5.5

14.8

0.9

200

13.32

15.02

2024



2.2

400

32.56

12.29

2803

3.8

600

56.24

10.67

3395

5.8

800

85.84

9.32

3869

7.9

1000

116.92

8.55

4302

10.4

1200

153.92

7.80

4692

13.1

1400

193.88

7.22

4977

16

1600

236.8

6.76

5311

19.1

1800

282.68

6.37

5584

22.5

2000

333

6.01

5876

27.5

2250

407

5.53

6185

33.4

2500

494.32

5.06

6491

40.1

2800

593.48

4.72

6809

16.8

0.8

200

13.44

14.88

2030

2

400

33.6

11.90

2810

3.4

600

57.12

10.50

3406

5.1

800

85.68

9.34

3854

7

1000

117.6

8.50

4315

9.2

1200

154.56

7.76

4684

11.7

1400

196.56

7.12

4952

14.3

1600

240.24

6.66

5321

17.1

1800

287.28

6.27

5591

20.1

2000

337.68

5.92

5894

24.2

2250

406.56

5.53

6164

29.3

2500

492.24

5.08

6493

35.6

2750

598.08

4.60

6746

43.7

3000

734.16

4.09

7085

50.4

3350

846.72

3.96

7460

2min 90℃







图片 1.jpg
