| Motor Model / KV | X3120-III/ KV585 | X3120-III/ KV760 | X3120-III/ KV880 | X3120-III/ KV1025 | X3120-V2/KV800 | X3120-V2/KV950 | X3120-V2/KV1100 |
|---|---|---|---|---|---|---|---|
| Stator/Rotor Poles | 12N14P | 12N14P | 12N14P | 12N14P | 12N14P | 12N14P | 12N14P |
| Internal resistance | 43.5mΩ | 27.5mΩ | 20mΩ | 16mΩ | 30mΩ | 19mΩ | 16mΩ |
| Motor size | Motor length：42mm | Motor length：42mm | Motor length：42mm | Motor length：42mm |
Motor length: 39.5mm | Motor length: 39.5mm | Motor length: 39.5mm |
| Shaft diameter | 5.0mm | 5.0mm | 5.0mm | 5.0mm | 37.7mm | 37.7mm | 37.7mm |
| AWG | 20AWG 110mm | 20AWG 110mm | 20AWG 110mm | 20AWG 110mm | 20AWG 100mm | 20AWG 100mm | 20AWG 110mm |
| Motor weight(wire included) | 159g | 157g | 157g | 158g | 152g | 157g | 152g |
| Motor weight(wire excluded) | No data | No data | No data | No data | No data | No data | No data |
| Rated operational voltage | 6S | 3-5S | 3-4S | 3-4S | 3-4s | 3-4s | 3s |
| No-load current | 1.0A/10V | 1.3A/10V | 1.6A/10V | 2.1A/10V | 1.2A | 1.5A | 2.2A |
| Maximum continuous power | 1625W | 1370W | 1250W | 1300W | 1243w | 1562.4w | 1075w |
| Maximum continuous current | 65A/30s | 65A/30s | 70A/30s | 77A/30s | 74A/30s | 93A/30s | 86A/30s |
| ESC recommended use | 60A | 60-80A | 60-80A | 60-80A | 130A | 130A | 130A |
| Propeller size recommended use | 6S(EOLO12*6.5/EOLO13*7) | 4-5S(EOLO12*6.5 APC12*8 APC12*6) 4S(EOLO13*7 APC13*6.5 APC13*8) 3S(EOLO14*7 APC14*7) | EOLO12*6.5 EOLO13*7 EOLO14*7 APC12*8 APC12*6 APC13*6.5 APC14*7 | EOLO12*6.5 EOLO13*7 APC12*8 APC12*6 APC13*6.5 APC13*8 | EOLO12*6.5 13*7 14*7 14*8 | EOLO12*6.5 13*7/14*7 | EOLO12*6.5 13*7 |
Specifications | X3120 | Max Continuous Current | 65A/30s |
Stator Diameter | 31mm | Max Continuous Power | 1625W |
Stator Thickness | 20mm | Weight | 159g |
No.of Stator Slots | 12 | Rotor Diameter | 37.7mm |
No.of Rotor Poles | 14 | Body Length | 42mm |
Motor Kv | 585 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 1.0A | ESC | 60A |
Motor Resistance | 43.5mΩ | Recommend Prop(inch) | 6S EOLO12*6.5 EOLO13*7 |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 22.2 | 2.6 | 500 | 57.72 | 8.66 | 4215 |
|
4.3 | 750 | 95.46 | 7.86 | 5130 | |||
6.2 | 1000 | 137.64 | 7.27 | 5844 | |||
8.4 | 1250 | 186.48 | 6.70 | 6476 | |||
11 | 1500 | 244.2 | 6.14 | 7137 | |||
13.5 | 1750 | 299.7 | 5.84 | 7709 | |||
16.55 | 2000 | 367.41 | 5.44 | 8130 | |||
19.9 | 2250 | 441.78 | 5.09 | 8699 | |||
23.3 | 2500 | 517.26 | 4.83 | 9050 | |||
27.2 | 2750 | 603.84 | 4.55 | 9500 | |||
31.7 | 3000 | 703.74 | 4.26 | 9870 | |||
41.6 | 3560 | 923.52 | 3.85 | 10620 | |||
25 | 2.3 | 500 | 57.5 | 8.70 | 4225 | ||
3.8 | 750 | 95 | 7.89 | 5150 | |||
5.6 | 1000 | 140 | 7.14 | 5860 | |||
7.6 | 1250 | 190 | 6.58 | 6500 | |||
9.8 | 1500 | 245 | 6.12 | 7086 | |||
12.2 | 1750 | 305 | 5.74 | 7669 | |||
14.9 | 2000 | 372.5 | 5.37 | 8298 | |||
17.8 | 2250 | 445 | 5.06 | 8680 | |||
21.1 | 2500 | 527.5 | 4.74 | 9060 | |||
24.9 | 2750 | 622.5 | 4.42 | 9500 | |||
28.5 | 3000 | 712.5 | 4.21 | 9763 | |||
36.1 | 3500 | 902.5 | 3.88 | 10680 | |||
50.5 | 4320 | 1262.5 | 3.42 | 11465 | 130℃ 3min | ||
EOLO 13*7 | 22.2 | 2.5 | 500 | 55.5 | 9.01 | 3640 |
|
4 | 750 | 88.8 | 8.45 | 4308 | |||
5.9 | 1000 | 130.98 | 7.63 | 4947 | |||
8.1 | 1250 | 179.82 | 6.95 | 5524 | |||
10.45 | 1500 | 231.99 | 6.47 | 6080 | |||
12.9 | 1750 | 286.38 | 6.11 | 6522 | |||
15.8 | 2000 | 350.76 | 5.70 | 6922 | |||
18.9 | 2250 | 419.58 | 5.36 | 7352 | |||
22.1 | 2500 | 490.62 | 5.10 | 7758 | |||
26.2 | 2750 | 581.64 | 4.73 | 8121 | |||
30.3 | 3000 | 672.66 | 4.46 | 8408 | |||
40.1 | 3500 | 890.22 | 3.93 | 9070 | |||
53.7 | 4250 | 1192.14 | 3.57 | 9683 | |||
25 | 2.3 | 500 | 57.5 | 8.70 | 3650 | ||
3.7 | 750 | 92.5 | 8.11 | 4310 | |||
5.3 | 1000 | 132.5 | 7.55 | 5000 | |||
7.3 | 1250 | 182.5 | 6.85 | 5525 | |||
9.4 | 1500 | 235 | 6.38 | 6064 | |||
11.7 | 1750 | 292.5 | 5.98 | 6565 | |||
14.3 | 2000 | 357.5 | 5.59 | 6965 | |||
17 | 2250 | 425 | 5.29 | 7400 | |||
20.1 | 2500 | 502.5 | 4.98 | 7740 | |||
23.5 | 2750 | 587.5 | 4.68 | 8060 | |||
27.2 | 3000 | 680 | 4.41 | 8450 | |||
36.2 | 3500 | 905 | 3.87 | 9050 | |||
45.7 | 4000 | 1142.5 | 3.50 | 9560 | |||
65 | 5040 | 1625 | 3.10 | 10500 | 130℃ 1min |
Specifications | X3120 | Max Continuous Current | 65A/30s |
Stator Diameter | 31mm | Max Continuous Power | 1370W |
Stator Thickness | 20mm | Weight | 157g |
No.of Stator Slots | 12 | Rotor Diameter | 37.7mm |
No.of Rotor Poles | 14 | Body Length | 42mm |
Motor Kv | 760 | Max Lipo Cell | 3-5S |
NO-Load Current(A/10V) | 1.3A | ESC | 60-80A |
Motor Resistance | 27.5mΩ | Recommend Prop(inch) | 4-5S(EOLO12*6.5 APC12*8 APC12*6) 4S(EOLO13*7 APC13*6.5 APC13*8) 3S(EOLO14*7 APC14*7) |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 14.8 | 3.8 | 500 | 56.24 | 8.89 | 4269 |
|
6.5 | 750 | 96.2 | 7.80 | 5190 | |||
9.5 | 1000 | 140.6 | 7.11 | 5865 | |||
13 | 1250 | 192.4 | 6.50 | 6530 | |||
16.8 | 1500 | 248.64 | 6.03 | 7127 | |||
21.3 | 1750 | 315.24 | 5.55 | 7757 | |||
25.9 | 2000 | 383.32 | 5.22 | 8240 | |||
31.5 | 2250 | 466.2 | 4.83 | 8600 | |||
40.4 | 2670 | 597.92 | 4.47 | 9333 | |||
16.8 | 3.5 | 500 | 58.8 | 8.50 | 4250 | ||
5.8 | 750 | 97.44 | 7.70 | 5232 | |||
8.5 | 1000 | 142.8 | 7.00 | 5780 | |||
11.5 | 1250 | 193.2 | 6.47 | 6527 | |||
15 | 1500 | 252 | 5.95 | 7130 | |||
18.8 | 1750 | 315.84 | 5.54 | 7620 | |||
22.9 | 2000 | 384.72 | 5.20 | 8182 | |||
27.9 | 2250 | 468.72 | 4.80 | 8640 | |||
33 | 2500 | 554.4 | 4.51 | 9085 | |||
45 | 3040 | 756 | 4.02 | 9937 | |||
18.5 | 3.1 | 500 | 57.35 | 8.72 | 4160 | ||
5.2 | 750 | 96.2 | 7.80 | 5114 | |||
7.7 | 1000 | 142.45 | 7.02 | 5750 | |||
10.4 | 1250 | 192.4 | 6.50 | 6517 | |||
13.6 | 1500 | 251.6 | 5.96 | 7190 | |||
17 | 1750 | 314.5 | 5.56 | 7539 | |||
20.9 | 2000 | 386.65 | 5.17 | 8170 | |||
24.9 | 2250 | 460.65 | 4.88 | 8501 | |||
29.5 | 2500 | 545.75 | 4.58 | 9003 | |||
34.9 | 2750 | 645.65 | 4.26 | 9356 | |||
39.8 | 3000 | 736.3 | 4.07 | 9745 | |||
55 | 3700 | 1017.5 | 3.64 | 10197 | |||
21 | 2.8 | 500 | 58.8 | 8.50 | 4160 | ||
4.6 | 750 | 96.6 | 7.76 | 5214 | |||
6.9 | 1000 | 144.9 | 6.90 | 5758 | |||
9.3 | 1250 | 195.3 | 6.40 | 6527 | |||
12 | 1500 | 252 | 5.95 | 7200 | |||
14.9 | 1750 | 312.9 | 5.59 | 7550 | |||
18.3 | 2000 | 384.3 | 5.20 | 8123 | |||
22.3 | 2250 | 468.3 | 4.80 | 8660 | |||
26.3 | 2500 | 552.3 | 4.53 | 9002 | |||
30.8 | 2750 | 646.8 | 4.25 | 9438 | |||
35.4 | 3000 | 743.4 | 4.04 | 9894 | |||
45.7 | 3500 | 959.7 | 3.65 | 10470 | |||
68 | 4500 | 1428 | 3.15 | 11643 | 127℃ 1min | ||
EOLO 13*7 | 14.8 | 3.9 | 500 | 57.72 | 8.66 | 3620 |
|
6.5 | 750 | 96.2 | 7.80 | 4456 | |||
9.2 | 1000 | 136.16 | 7.34 | 5080 | |||
12.7 | 1250 | 187.96 | 6.65 | 5560 | |||
16.5 | 1500 | 244.2 | 6.14 | 6050 | |||
20.8 | 1750 | 307.84 | 5.68 | 6544 | |||
25.3 | 2000 | 374.44 | 5.34 | 7028 | |||
30.5 | 2250 | 451.4 | 4.98 | 7405 | |||
35.5 | 2500 | 525.4 | 4.76 | 7830 | |||
41.6 | 2750 | 615.68 | 4.47 | 8130 | |||
50.7 | 3160 | 750.36 | 4.21 | 8498 | |||
16.8 | 3.4 | 500 | 57.12 | 8.75 | 3620 | ||
5.6 | 750 | 94.08 | 7.97 | 4390 | |||
8.3 | 1000 | 139.44 | 7.17 | 5049 | |||
11.2 | 1250 | 188.16 | 6.64 | 5518 | |||
14.6 | 1500 | 245.28 | 6.12 | 5981 | |||
18.5 | 1750 | 310.8 | 5.63 | 6540 | |||
22.5 | 2000 | 378 | 5.29 | 6913 | |||
26.8 | 2250 | 450.24 | 5.00 | 7265 | |||
31.7 | 2500 | 532.56 | 4.69 | 7733 | |||
37 | 2750 | 621.6 | 4.42 | 8016 | |||
45 | 3000 | 756 | 3.97 | 8439 | |||
63.5 | 3830 | 1066.8 | 3.59 | 9500 | 123℃ 2min20S | ||
EOLO14*7 | 14.8 | 3.5 | 500 | 51.8 | 9.65 | 3303 |
|
5.8 | 750 | 85.84 | 8.74 | 3967 | |||
8.4 | 1000 | 124.32 | 8.04 | 4546 | |||
11.5 | 1250 | 170.2 | 7.34 | 5098 | |||
15.2 | 1500 | 224.96 | 6.67 | 5580 | |||
18.9 | 1750 | 279.72 | 6.26 | 5898 | |||
22.9 | 2000 | 338.92 | 5.90 | 6343 | |||
27.8 | 2250 | 411.44 | 5.47 | 6658 | |||
32.8 | 2500 | 485.44 | 5.15 | 7029 | |||
38.5 | 2750 | 569.8 | 4.83 | 7390 | |||
45.3 | 3000 | 670.44 | 4.47 | 7710 | |||
58.8 | 3560 | 870.24 | 4.09 | 8200 | |||
16.8 | 3.1 | 500 | 52.08 | 9.60 | 3201 | ||
5.2 | 750 | 87.36 | 8.59 | 3899 | |||
7.7 | 1000 | 129.36 | 7.73 | 4530 | |||
10.6 | 1250 | 178.08 | 7.02 | 5050 | |||
13.6 | 1500 | 228.48 | 6.57 | 5490 | |||
17 | 1750 | 285.6 | 6.13 | 5920 | |||
20.9 | 2000 | 351.12 | 5.70 | 6300 | |||
25.2 | 2250 | 423.36 | 5.31 | 6700 | |||
29.6 | 2500 | 497.28 | 5.03 | 6956 | |||
34.6 | 2750 | 581.28 | 4.73 | 7300 | |||
44.6 | 3000 | 749.28 | 4.00 | 7600 | |||
55.3 | 3500 | 929.04 | 3.77 | 8246 | |||
71.5 | 4289 | 1201.2 | 3.57 | 8937 | 135℃ 1min | ||
APC12*8 | 14.8 | 4.1 | 500 | 60.68 | 8.24 | 4210 |
|
7 | 750 | 103.6 | 7.24 | 5176 | |||
10.5 | 1000 | 155.4 | 6.44 | 5918 | |||
14.4 | 1250 | 213.12 | 5.87 | 6520 | |||
18.7 | 1500 | 276.76 | 5.42 | 7117 | |||
23.5 | 1750 | 347.8 | 5.03 | 7690 | |||
28.7 | 2000 | 424.76 | 4.71 | 8220 | |||
35.6 | 2250 | 526.88 | 4.27 | 8890 | |||
41.5 | 2310 | 614.2 | 3.76 | 8968 | |||
16.8 | 3.6 | 500 | 60.48 | 8.27 | 4206 | ||
6.2 | 750 | 104.16 | 7.20 | 5178 | |||
9.2 | 1000 | 154.56 | 6.47 | 5918 | |||
12.8 | 1250 | 215.04 | 5.81 | 6541 | |||
16.5 | 1500 | 277.2 | 5.41 | 7117 | |||
20.6 | 1750 | 346.08 | 5.06 | 7680 | |||
25.5 | 2000 | 428.4 | 4.67 | 8290 | |||
30.7 | 2250 | 515.76 | 4.36 | 8896 | |||
53.3 | 2840 | 895.44 | 3.17 | 9639 | |||
18.5 | 3.2 | 500 | 59.2 | 8.45 | 4210 | ||
5.8 | 750 | 107.3 | 6.99 | 5180 | |||
8.5 | 1000 | 157.25 | 6.36 | 5920 | |||
11.7 | 1250 | 216.45 | 5.78 | 6520 | |||
15.3 | 1500 | 283.05 | 5.30 | 7111 | |||
19 | 1750 | 351.5 | 4.98 | 7690 | |||
23.7 | 2000 | 438.45 | 4.56 | 8218 | |||
28.2 | 2250 | 521.7 | 4.31 | 8890 | |||
34.3 | 2500 | 634.55 | 3.94 | 9334 | |||
63.5 | 3220 | 1174.75 | 2.74 | 10200 | 125℃ 2min | ||
APC12*6 | 14.8 | 3.9 | 500 | 57.72 | 8.66 | 4650 |
|
6.6 | 750 | 97.68 | 7.68 | 5655 | |||
9.9 | 1000 | 146.52 | 6.83 | 6499 | |||
13.1 | 1250 | 193.88 | 6.45 | 7160 | |||
17.2 | 1500 | 254.56 | 5.89 | 7780 | |||
21.8 | 1750 | 322.64 | 5.42 | 8275 | |||
26.7 | 2000 | 395.16 | 5.06 | 8820 | |||
38.8 | 2530 | 574.24 | 4.41 | 9409 | |||
16.8 | 3.5 | 500 | 58.8 | 8.50 | 4652 | ||
5.9 | 750 | 99.12 | 7.57 | 5680 | |||
8.7 | 1000 | 146.16 | 6.84 | 6450 | |||
11.8 | 1250 | 198.24 | 6.31 | 7200 | |||
15.4 | 1500 | 258.72 | 5.80 | 7790 | |||
19.1 | 1750 | 320.88 | 5.45 | 8225 | |||
23.8 | 2000 | 399.84 | 5.00 | 8865 | |||
28.5 | 2250 | 478.8 | 4.70 | 9218 | |||
34 | 2500 | 571.2 | 4.38 | 9689 | |||
46.6 | 3020 | 782.88 | 3.86 | 10169 | |||
18.5 | 3.2 | 500 | 59.2 | 8.45 | 4560 | ||
5.4 | 750 | 99.9 | 7.51 | 5700 | |||
8 | 1000 | 148 | 6.76 | 6450 | |||
10.8 | 1250 | 199.8 | 6.26 | 7182 | |||
14.1 | 1500 | 260.85 | 5.75 | 7790 | |||
17.5 | 1750 | 323.75 | 5.41 | 82225 | |||
21.8 | 2000 | 403.3 | 4.96 | 8863 | |||
26 | 2250 | 481 | 4.68 | 9370 | |||
31.3 | 2500 | 579.05 | 4.32 | 9660 | |||
55 | 3450 | 1017.5 | 3.39 | 10980 | |||
21 | 2.8 | 500 | 58.8 | 8.50 | 4650 | ||
4.8 | 750 | 100.8 | 7.44 | 5680 | |||
7.1 | 1000 | 149.1 | 6.71 | 6459 | |||
9.8 | 1250 | 205.8 | 6.07 | 7128 | |||
12.6 | 1500 | 264.6 | 5.67 | 7760 | |||
15.8 | 1750 | 331.8 | 5.27 | 8222 | |||
19.6 | 2000 | 411.6 | 4.86 | 8685 | |||
21.15 | 2250 | 444.15 | 5.07 | 9204 | |||
27.9 | 2500 | 585.9 | 4.27 | 9640 | |||
33 | 2750 | 693 | 3.97 | 10042 | |||
38.8 | 3000 | 814.8 | 3.68 | 10529 | |||
65.2 | 3940 | 1369.2 | 2.88 | 11938 | 90℃ 3min | ||
APC13*6.5 | 14.8 | 3.9 | 500 | 57.72 | 8.66 | 3990 |
|
6.5 | 750 | 96.2 | 7.80 | 4721 | |||
9.3 | 1000 | 137.64 | 7.27 | 5501 | |||
12.6 | 1250 | 186.48 | 6.70 | 6110 | |||
16.3 | 1500 | 241.24 | 6.22 | 6567 | |||
20.9 | 1750 | 309.32 | 5.66 | 7067 | |||
25.8 | 2000 | 381.84 | 5.24 | 7510 | |||
30.8 | 2250 | 455.84 | 4.94 | 7932 | |||
36.4 | 2500 | 538.72 | 4.64 | 8324 | |||
47.6 | 2960 | 704.48 | 4.20 | 8992 | |||
16.8 | 3.2 | 500 | 53.76 | 9.30 | 3965 | ||
5.6 | 750 | 94.08 | 7.97 | 4701 | |||
8.3 | 1000 | 139.44 | 7.17 | 5521 | |||
11.2 | 1250 | 188.16 | 6.64 | 6130 | |||
14.9 | 1500 | 250.32 | 5.99 | 6587 | |||
18.1 | 1750 | 304.08 | 5.76 | 7047 | |||
23 | 2000 | 386.4 | 5.18 | 7502 | |||
27.4 | 2250 | 460.32 | 4.89 | 7922 | |||
32.6 | 2500 | 547.68 | 4.56 | 8230 | |||
38.1 | 2750 | 640.08 | 4.30 | 8604 | |||
44.8 | 3000 | 752.64 | 3.99 | 9010 | |||
55.6 | 3540 | 934.08 | 3.79 | 9498 | 90℃ 3min | ||
APC13*8 | 14.8 | 3.6 | 500 | 53.28 | 9.38 | 3777 |
|
6.2 | 750 | 91.76 | 8.17 | 4555 | |||
9.6 | 1000 | 142.08 | 7.04 | 5200 | |||
13 | 1250 | 192.4 | 6.50 | 5789 | |||
17.2 | 1500 | 254.56 | 5.89 | 6258 | |||
21.1 | 1750 | 312.28 | 5.60 | 6670 | |||
26.9 | 2000 | 398.12 | 5.02 | 7181 | |||
31.9 | 2250 | 472.12 | 4.77 | 7575 | |||
38.6 | 2500 | 571.28 | 4.38 | 8013 | |||
49.8 | 2930 | 737.04 | 3.98 | 8600 | |||
16.8 | 3.3 | 500 | 55.44 | 9.02 | 3750 | ||
5.7 | 750 | 95.76 | 7.83 | 4535 | |||
8.6 | 1000 | 144.48 | 6.92 | 5189 | |||
11.7 | 1250 | 196.56 | 6.36 | 5777 | |||
15.5 | 1500 | 260.4 | 5.76 | 6256 | |||
19.3 | 1750 | 324.24 | 5.40 | 6890 | |||
23.7 | 2000 | 398.16 | 5.02 | 7333 | |||
28.8 | 2250 | 483.84 | 4.65 | 7769 | |||
33.9 | 2500 | 569.52 | 4.39 | 8000 | |||
40.5 | 2750 | 680.4 | 4.04 | 8355 | |||
47.1 | 3000 | 791.28 | 3.79 | 8800 | |||
61 | 3520 | 1024.8 | 3.43 | 9280 | 110℃ 4min | ||
APC14*7 | 14.8 | 3.4 | 500 | 50.32 | 9.94 | 3360 |
|
5.9 | 750 | 87.32 | 8.59 | 4089 | |||
8.6 | 1000 | 127.28 | 7.86 | 4675 | |||
11.9 | 1250 | 176.12 | 7.10 | 5260 | |||
15.6 | 1500 | 230.88 | 6.50 | 5620 | |||
19.3 | 1750 | 285.64 | 6.13 | 6060 | |||
23.6 | 2000 | 349.28 | 5.73 | 6506 | |||
29.3 | 2250 | 433.64 | 5.19 | 6870 | |||
35 | 2500 | 518 | 4.83 | 7219 | |||
41 | 2750 | 606.8 | 4.53 | 7490 | |||
51.2 | 3350 | 757.76 | 4.42 | 8117 | |||
16.8 | 3 | 500 | 50.4 | 9.92 | 3340 | ||
5.2 | 750 | 87.36 | 8.59 | 4087 | |||
7.9 | 1000 | 132.72 | 7.53 | 4672 | |||
10.9 | 1250 | 183.12 | 6.83 | 5235 | |||
13.8 | 1500 | 231.84 | 6.47 | 5620 | |||
17.6 | 1750 | 295.68 | 5.92 | 6060 | |||
21.5 | 2000 | 361.2 | 5.54 | 6506 | |||
26.2 | 2250 | 440.16 | 5.11 | 6800 | |||
31.6 | 2500 | 530.88 | 4.71 | 7217 | |||
36.2 | 2750 | 608.16 | 4.52 | 7520 | |||
43.9 | 3000 | 737.52 | 4.07 | 7789 | |||
59.2 | 3500 | 994.56 | 3.52 | 8338 | |||
67 | 3819 | 1125.6 | 3.39 | 8699 | 127℃ 2min |
Specifications | X3120 | Max Continuous Current | 74A/30s |
Stator Diameter | 31mm | Max Continuous Power | 1250W |
Stator Thickness | 20mm | Weight | 157g |
No.of Stator Slots | 12 | Rotor Diameter | 37.7mm |
No.of Rotor Poles | 14 | Body Length | 42mm |
Motor Kv | 880 | Max Lipo Cell | 3-4S |
NO-Load Current(A/10V) | 1.6A | ESC | 60-80A |
Motor Resistance | 20mΩ | Recommend Prop(inch) | EOLO12*6.5 EOLO13*7 EOLO14*7 APC12*8 APC12*6 APC13*6.5 APC14*7 |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 14.8 | 4.2 | 500 | 62.16 | 8.04 | 4218 |
|
7 | 750 | 103.6 | 7.24 | 5042 | |||
10.3 | 1000 | 152.44 | 6.56 | 5940 | |||
14 | 1250 | 207.2 | 6.03 | 6500 | |||
17.9 | 1500 | 264.92 | 5.66 | 7200 | |||
22.3 | 1750 | 330.04 | 5.30 | 7720 | |||
27.2 | 2000 | 402.56 | 4.97 | 8248 | |||
32.7 | 2250 | 483.96 | 4.65 | 8589 | |||
39.6 | 2500 | 586.08 | 4.27 | 9060 | |||
46.4 | 2750 | 686.72 | 4.00 | 9445 | |||
57.2 | 3160 | 846.56 | 3.73 | 10020 | |||
16.8 | 3.7 | 500 | 62.16 | 8.04 | 4200 | ||
6.2 | 750 | 104.16 | 7.20 | 5146 | |||
9.1 | 1000 | 152.88 | 6.54 | 5925 | |||
12.3 | 1250 | 206.64 | 6.05 | 6520 | |||
15.9 | 1500 | 267.12 | 5.62 | 7111 | |||
19.9 | 1750 | 334.32 | 5.23 | 7657 | |||
24.2 | 2000 | 406.56 | 4.92 | 8156 | |||
29.2 | 2250 | 490.56 | 4.59 | 8659 | |||
35 | 2500 | 588 | 4.25 | 9099 | |||
40.4 | 2750 | 678.72 | 4.05 | 9543 | |||
46.5 | 3000 | 781.2 | 3.84 | 9909 | |||
68.6 | 3850 | 1152.48 | 3.34 | 10898 | 110℃ 2min | ||
EOLO 13*7 | 11.1 | 5.1 | 500 | 56.61 | 8.83 | 3610 |
|
8.4 | 750 | 93.24 | 8.04 | 4380 | |||
12.5 | 1000 | 138.75 | 7.21 | 5053 | |||
17.1 | 1250 | 189.81 | 6.59 | 5589 | |||
22.3 | 1500 | 247.53 | 6.06 | 6077 | |||
28 | 1750 | 310.8 | 5.63 | 6632 | |||
34.4 | 2000 | 381.84 | 5.24 | 6925 | |||
45.3 | 2380 | 502.83 | 4.73 | 7517 | |||
12.5 | 4.7 | 500 | 58.75 | 8.51 | 3612 | ||
7.8 | 750 | 97.5 | 7.69 | 4420 | |||
11.3 | 1000 | 141.25 | 7.08 | 5014 | |||
15.6 | 1250 | 195 | 6.41 | 5553 | |||
20 | 1500 | 250 | 6.00 | 6069 | |||
25.2 | 1750 | 315 | 5.56 | 6487 | |||
31 | 2000 | 387.5 | 5.16 | 6969 | |||
37.8 | 2250 | 472.5 | 4.76 | 7373 | |||
53.3 | 2780 | 666.25 | 4.17 | 8050 | 90℃ 5min | ||
EOLO 14*7 | 11.1 | 4.8 | 500 | 53.28 | 9.38 | 330 |
|
7.8 | 750 | 86.58 | 8.66 | 3936 | |||
11.5 | 1000 | 127.65 | 7.83 | 4600 | |||
15.7 | 1250 | 174.27 | 7.17 | 5037 | |||
20.5 | 1500 | 227.55 | 6.59 | 5560 | |||
25.9 | 1750 | 287.49 | 6.09 | 5930 | |||
31.8 | 2000 | 352.98 | 5.67 | 6320 | |||
38.8 | 2250 | 430.68 | 5.22 | 6726 | |||
50.7 | 2700 | 562.77 | 4.80 | 7200 | |||
12.5 | 4.2 | 500 | 52.5 | 9.52 | 3230 | ||
7 | 750 | 87.5 | 8.57 | 3932 | |||
10.4 | 1000 | 130 | 7.69 | 4550 | |||
14.2 | 1250 | 177.5 | 7.04 | 5060 | |||
18.5 | 1500 | 231.25 | 6.49 | 5510 | |||
23 | 1750 | 287.5 | 6.09 | 5940 | |||
28.6 | 2000 | 357.5 | 5.59 | 6310 | |||
34.3 | 2250 | 428.75 | 5.25 | 6740 | |||
41.1 | 2500 | 513.75 | 4.87 | 7000 | |||
49.3 | 2750 | 616.25 | 4.46 | 7300 | |||
61.2 | 3260 | 765 | 4.26 | 7840 | 100℃ 5min | ||
EOLO 14*8 | 11.1 | 4.8 | 500 | 53.28 | 9.38 | 3130 |
|
8.1 | 750 | 89.91 | 8.34 | 3755 | |||
12 | 1000 | 133.2 | 7.51 | 4320 | |||
16.5 | 1250 | 183.15 | 6.83 | 4797 | |||
21.5 | 1500 | 238.65 | 6.29 | 5240 | |||
27.4 | 1750 | 304.14 | 5.75 | 5651 | |||
34.2 | 2000 | 379.62 | 5.27 | 5988 | |||
41.3 | 2250 | 458.43 | 4.91 | 6264 | |||
55.7 | 2700 | 618.27 | 4.37 | 6800 | |||
12.5 | 4.4 | 500 | 55 | 9.09 | 3183 | ||
7.5 | 750 | 93.75 | 8.00 | 3715 | |||
11 | 1000 | 137.5 | 7.27 | 4316 | |||
15.1 | 1250 | 188.75 | 6.62 | 4757 | |||
19.6 | 1500 | 245 | 6.12 | 5200 | |||
25 | 1750 | 312.5 | 5.60 | 5618 | |||
31 | 2000 | 387.5 | 5.16 | 5959 | |||
37.2 | 2250 | 465 | 4.84 | 6313 | |||
45.2 | 2500 | 565 | 4.42 | 6658 | |||
53.1 | 2750 | 663.75 | 4.14 | 6965 | |||
66.9 | 3260 | 836.25 | 3.90 | 7490 | 116℃ 2min | ||
APC12*8 | 14.8 | 4.1 | 500 | 60.68 | 8.24 | 4211 |
|
7.2 | 750 | 106.56 | 7.04 | 5160 | |||
10.8 | 1000 | 159.84 | 6.26 | 5960 | |||
14.8 | 1250 | 219.04 | 5.71 | 6490 | |||
19.2 | 1500 | 284.16 | 5.28 | 7125 | |||
24.2 | 1750 | 358.16 | 4.89 | 7760 | |||
30.2 | 2000 | 446.96 | 4.47 | 8085 | |||
38.4 | 2250 | 568.32 | 3.96 | 8668 | |||
45.9 | 2500 | 679.32 | 3.68 | 9221 | |||
62.5 | 2750 | 925 | 2.97 | 9820 | |||
16.8 | 3.7 | 500 | 62.16 | 8.04 | 4250 | ||
6.5 | 750 | 109.2 | 6.87 | 5160 | |||
9.65 | 1000 | 162.12 | 6.17 | 5920 | |||
13.3 | 1250 | 223.44 | 5.59 | 6450 | |||
17.4 | 1500 | 292.32 | 5.13 | 7120 | |||
21.7 | 1750 | 364.56 | 4.80 | 7795 | |||
27 | 2000 | 453.6 | 4.41 | 8060 | |||
32.6 | 2250 | 547.68 | 4.11 | 8645 | |||
41 | 2500 | 688.8 | 3.63 | 9160 | |||
53.8 | 2750 | 903.84 | 3.04 | 9909 | |||
74.9 | 3240 | 1258.32 | 2.57 | 10550 | 115℃ 1min | ||
APC12*6 | 14.8 | 4.2 | 500 | 62.16 | 8.04 | 4635 |
|
6.8 | 750 | 100.64 | 7.45 | 5655 | |||
10.2 | 1000 | 150.96 | 6.62 | 6490 | |||
13.8 | 1250 | 204.24 | 6.12 | 7150 | |||
17.9 | 1500 | 264.92 | 5.66 | 7764 | |||
22.65 | 1750 | 335.22 | 5.22 | 8300 | |||
27.9 | 2000 | 412.92 | 4.84 | 8895 | |||
33.2 | 2250 | 491.36 | 4.58 | 9117 | |||
39.1 | 2500 | 578.68 | 4.32 | 9607 | |||
49 | 2750 | 725.2 | 3.79 | 9930 | |||
54.6 | 3000 | 808.08 | 3.71 | 10380 | |||
16.8 | 3.7 | 500 | 62.16 | 8.04 | 4660 | ||
6.1 | 750 | 102.48 | 7.32 | 5700 | |||
9.1 | 1000 | 152.88 | 6.54 | 6427 | |||
12.3 | 1250 | 206.64 | 6.05 | 7180 | |||
15.8 | 1500 | 265.44 | 5.65 | 7750 | |||
19.8 | 1750 | 332.64 | 5.26 | 8235 | |||
24.4 | 2000 | 409.92 | 4.88 | 8860 | |||
29.3 | 2250 | 492.24 | 4.57 | 9350 | |||
34.1 | 2500 | 572.88 | 4.36 | 9769 | |||
43.1 | 2750 | 724.08 | 3.80 | 10126 | |||
49.3 | 3000 | 828.24 | 3.62 | 10473 | |||
66.8 | 3540 | 1122.24 | 3.15 | 11126 | 105℃ 2min | ||
APC13*6.5 | 11.1 | 4.8 | 500 | 53.28 | 9.38 | 3985 |
|
8.3 | 750 | 92.13 | 8.14 | 4833 | |||
12.5 | 1000 | 138.75 | 7.21 | 5570 | |||
17.1 | 1250 | 189.81 | 6.59 | 6125 | |||
22.4 | 1500 | 248.64 | 6.03 | 6587 | |||
28.5 | 1750 | 316.35 | 5.53 | 7082 | |||
35.3 | 2000 | 391.83 | 5.10 | 7480 | |||
43.9 | 2330 | 487.29 | 4.78 | 7876 | |||
12.5 | 4.3 | 500 | 53.75 | 9.30 | 3962 | ||
7.5 | 750 | 93.75 | 8.00 | 4831 | |||
11.2 | 1000 | 140 | 7.14 | 5537 | |||
15.3 | 1250 | 191.25 | 6.54 | 7139 | |||
20.1 | 1500 | 251.25 | 5.97 | 7625 | |||
25.5 | 1750 | 318.75 | 5.49 | 7124 | |||
31.2 | 2000 | 390 | 5.13 | 7517 | |||
50.5 | 2618 | 631.25 | 4.15 | 8674 | 90℃ 3min | ||
APC13*8 | 11.1 | 5 | 500 | 55.5 | 9.01 | 3720 |
|
8.6 | 750 | 95.46 | 7.86 | 4535 | |||
12.7 | 1000 | 140.97 | 7.09 | 5188 | |||
17.7 | 1250 | 196.47 | 6.36 | 5776 | |||
23 | 1500 | 255.3 | 5.88 | 6245 | |||
29.4 | 1750 | 326.34 | 5.36 | 690 | |||
36.3 | 2000 | 402.93 | 4.96 | 7198 | |||
47.9 | 2330 | 531.69 | 4.38 | 7798 | |||
12.5 | 4.5 | 500 | 56.25 | 8.89 | 3765 | ||
7.7 | 750 | 96.25 | 7.79 | 4520 | |||
11.5 | 1000 | 143.75 | 6.96 | 5198 | |||
15.8 | 1250 | 197.5 | 6.33 | 5760 | |||
20.9 | 1500 | 261.25 | 5.74 | 6300 | |||
26.7 | 1750 | 333.75 | 5.24 | 6830 | |||
32.9 | 2000 | 411.25 | 4.86 | 7350 | |||
39.9 | 2250 | 498.75 | 4.51 | 7628 | |||
56.7 | 2810 | 708.75 | 3.96 | 8401 | 95℃ 3min | ||
APC14*7 | 11.1 | 4.5 | 500 | 49.95 | 10.01 | 3380 |
|
8 | 750 | 88.8 | 8.45 | 4120 | |||
11.9 | 1000 | 132.09 | 7.57 | 4868 | |||
16.4 | 1250 | 182.04 | 6.87 | 5286 | |||
21.5 | 1500 | 238.65 | 6.29 | 5640 | |||
27.6 | 1750 | 306.36 | 5.71 | 6120 | |||
34.6 | 2000 | 384.06 | 5.21 | 6440 | |||
42.5 | 2250 | 471.75 | 4.77 | 6870 | |||
53.5 | 2660 | 593.85 | 4.48 | 7334 | |||
12.5 | 4.3 | 500 | 53.75 | 9.30 | 3357 | ||
7.4 | 750 | 92.5 | 8.11 | 4123 | |||
11 | 1000 | 137.5 | 7.27 | 4870 | |||
15 | 1250 | 187.5 | 6.67 | 5286 | |||
19.6 | 1500 | 245 | 6.12 | 5650 | |||
25 | 1750 | 312.5 | 5.60 | 6122 | |||
30.95 | 2000 | 386.875 | 5.17 | 6468 | |||
37.3 | 2250 | 466.25 | 4.83 | 6877 | |||
45.4 | 2500 | 567.5 | 4.41 | 7190 | |||
63.4 | 3100 | 792.5 | 3.91 | 7931 | 105℃ 5min |
Specifications | X3120 | Max Continuous Current | 77A/30s |
Stator Diameter | 31mm | Max Continuous Power | 1300W |
Stator Thickness | 20mm | Weight | 158g |
No.of Stator Slots | 12 | Rotor Diameter | 37.7mm |
No.of Rotor Poles | 14 | Body Length | 42mm |
MotorKv | 1025 | MaxLipo Cell | 3-4S |
NO-Load Current(A/10V) | 2.1A | ESC | 60-80A |
Motor Resistance | 20mΩ | Recommend Prop(inch) | EOLO12*6.5 EOLO13*7 APC12*8 APC12*6 APC13*6.5 APC13*8 |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 11.1 | 5.5 | 500 | 61.05 | 8.19 | 4260 |
|
9.1 | 750 | 101.01 | 7.43 | 5168 | |||
13.3 | 1000 | 147.63 | 6.77 | 5870 | |||
18.1 | 1250 | 200.91 | 6.22 | 6530 | |||
23.6 | 1500 | 261.96 | 5.73 | 7098 | |||
29.7 | 1750 | 329.67 | 5.31 | 7668 | |||
36.5 | 2000 | 405.15 | 4.94 | 8145 | |||
47.4 | 2400 | 526.14 | 4.56 | 8750 | |||
12.5 | 5 | 500 | 62.5 | 8.00 | 4264 | ||
8.3 | 750 | 103.75 | 7.23 | 5170 | |||
12.2 | 1000 | 152.5 | 6.56 | 5980 | |||
16.5 | 1250 | 206.25 | 6.06 | 6580 | |||
21.2 | 1500 | 265 | 5.66 | 7100 | |||
26.7 | 1750 | 333.75 | 5.24 | 7760 | |||
32.8 | 2000 | 410 | 4.88 | 8150 | |||
39.8 | 2250 | 497.5 | 4.52 | 8660 | |||
47.8 | 2500 | 597.5 | 4.18 | 9130 | |||
57.6 | 2870 | 720 | 3.99 | 9520 | 85℃ 5min | ||
EOLO 13*7 | 11.1 | 5.4 | 500 | 59.94 | 8.34 | 3570 |
|
8.7 | 750 | 96.57 | 7.77 | 4450 | |||
12.8 | 1000 | 142.08 | 7.04 | 4980 | |||
17.7 | 1250 | 196.47 | 6.36 | 5588 | |||
23 | 1500 | 255.3 | 5.88 | 6036 | |||
29.3 | 1750 | 325.23 | 5.38 | 6600 | |||
36 | 2000 | 399.6 | 5.01 | 6992 | |||
44 | 2250 | 488.4 | 4.61 | 7432 | |||
52.4 | 2500 | 581.64 | 4.30 | 7705 | |||
60 | 2750 | 666 | 4.13 | 7992 | 95℃ 5min | ||
APC12*8 | 11.1 | 5.6 | 500 | 62.16 | 8.04 | 4220 |
|
9.6 | 750 | 106.56 | 7.04 | 5160 | |||
14.3 | 1000 | 158.73 | 6.30 | 5960 | |||
20.1 | 1250 | 223.11 | 5.60 | 6490 | |||
26.4 | 1500 | 293.04 | 5.12 | 7120 | |||
33.2 | 1750 | 368.52 | 4.75 | 7725 | |||
42.2 | 2000 | 468.42 | 4.27 | 8090 | |||
55.1 | 2350 | 611.61 | 3.84 | 8796 | |||
12.5 | 5 | 500 | 62.5 | 8.00 | 4235 | ||
8.65 | 750 | 108.125 | 6.94 | 5169 | |||
13 | 1000 | 162.5 | 6.15 | 5911 | |||
17.8 | 1250 | 222.5 | 5.62 | 6450 | |||
23.5 | 1500 | 293.75 | 5.11 | 7143 | |||
29.8 | 1750 | 372.5 | 4.70 | 7745 | |||
37.3 | 2000 | 466.25 | 4.29 | 8090 | |||
46.4 | 2250 | 580 | 3.88 | 8635 | |||
56 | 2500 | 700 | 3.57 | 9256 | |||
66.4 | 2720 | 830 | 3.28 | 9450 | 104℃ 5min | ||
APC12*6 | 11.1 | 5.5 | 500 | 61.05 | 8.19 | 4635 |
|
9.1 | 750 | 101.01 | 7.43 | 5995 | |||
13.5 | 1000 | 149.85 | 6.67 | 6450 | |||
18.5 | 1250 | 205.35 | 6.09 | 7200 | |||
24.2 | 1500 | 268.62 | 5.58 | 7749 | |||
30.8 | 1750 | 341.88 | 5.12 | 8265 | |||
38.7 | 2000 | 429.57 | 4.66 | 8860 | |||
49.8 | 2390 | 552.78 | 4.32 | 9341 | |||
12.5 | 4.9 | 500 | 61.25 | 8.16 | 4695 | ||
8.3 | 750 | 103.75 | 7.23 | 5680 | |||
12.3 | 1000 | 153.75 | 6.50 | 6459 | |||
16.7 | 1250 | 208.75 | 5.99 | 7169 | |||
21.8 | 1500 | 272.5 | 5.50 | 7750 | |||
27.5 | 1750 | 343.75 | 5.09 | 8223 | |||
34.3 | 2000 | 428.75 | 4.66 | 8860 | |||
41.7 | 2250 | 521.25 | 4.32 | 9350 | |||
50.1 | 2500 | 626.25 | 3.99 | 9780 | |||
60.5 | 2840 | 756.25 | 3.76 | 10100 | 90℃ 5min | ||
APC13*6.5 | 11.1 | 5.1 | 500 | 56.61 | 8.83 | 3975 |
|
8.8 | 750 | 97.68 | 7.68 | 4830 | |||
13.1 | 1000 | 145.41 | 6.88 | 5527 | |||
18.1 | 1250 | 200.91 | 6.22 | 6150 | |||
23.7 | 1500 | 263.07 | 5.70 | 6666 | |||
30.3 | 1750 | 336.33 | 5.20 | 7200 | |||
37.5 | 2000 | 416.25 | 4.80 | 7666 | |||
46.1 | 2250 | 511.71 | 4.40 | 8120 | |||
60 | 2652 | 666 | 3.98 | 8554 | 90℃ 5min | ||
APC13*8 | 11.1 | 5.2 | 500 | 57.72 | 8.66 | 3750 |
|
9.1 | 750 | 101.01 | 7.43 | 4565 | |||
13.5 | 1000 | 149.85 | 6.67 | 5189 | |||
18.7 | 1250 | 207.57 | 6.02 | 5777 | |||
24.5 | 1500 | 271.95 | 5.52 | 6260 | |||
31.5 | 1750 | 349.65 | 5.01 | 6850 | |||
39.3 | 2000 | 436.23 | 4.58 | 7338 | |||
48 | 2250 | 532.8 | 4.22 | 7790 | |||
63.2 | 2660 | 701.52 | 3.79 | 8230 | 95℃ 5min |
Specifications | X3120II | Max Continuous Current | 74A/30s |
Stator Diameter | 31mm | Max Continuous Power | 1243w |
Stator Thickness | 20mm | Weight | 152g |
No.of Stator Slots | 12 | Rotor Diameter | 37.7mm |
No.of Rotor Poles | 14 | Body Length | 39.5mm |
Motor Kv | 800 | Max Lipo Cell | 3-4S |
NO-Load Current(A/10V) | 1.2A | ESC | 130A |
Motor Resistance | 30mΩ | Recommend Prop(inch) | EOLO12*6.5 13*7 14*7 14*8 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 14.8 | 4 | 500 | 59.2 | 8.45 | 4259 |
|
6.7 | 750 | 99.16 | 7.56 | 5178 | |||
10.1 | 1000 | 149.48 | 6.69 | 6004 | |||
13.6 | 1250 | 201.28 | 6.21 | 6622 | |||
18 | 1500 | 266.4 | 5.63 | 7261 | |||
22.8 | 1750 | 337.44 | 5.19 | 7861 | |||
27.8 | 2000 | 411.44 | 4.86 | 8409 | |||
33.6 | 2250 | 497.28 | 4.52 | 8896 | |||
41.9 | 2640 | 620.12 | 4.26 | 9425 | |||
16.8 | 3.6 | 500 | 60.48 | 8.27 | 4270 | ||
6.2 | 750 | 104.16 | 7.20 | 5161 | |||
9 | 1000 | 151.2 | 6.61 | 6005 | |||
12.4 | 1250 | 208.32 | 6.00 | 6654 | |||
16.3 | 1500 | 273.84 | 5.48 | 7292 | |||
20.5 | 1750 | 344.4 | 5.08 | 7840 | |||
25.1 | 2000 | 421.68 | 4.74 | 8447 | |||
30.2 | 2250 | 507.36 | 4.43 | 8852 | |||
35.3 | 2500 | 593.04 | 4.22 | 9297 | |||
51.3 | 3200 | 861.84 | 3.71 | 10322 | 1min30s 81℃ | ||
EOLO 13*7 | 14.8 | 3.9 | 500 | 57.72 | 8.66 | 3701 |
|
6.5 | 750 | 96.2 | 7.80 | 4479 | |||
9.5 | 1000 | 140.6 | 7.11 | 5133 | |||
13.4 | 1250 | 198.32 | 6.30 | 5703 | |||
17.6 | 1500 | 260.48 | 5.76 | 6227 | |||
22.2 | 1750 | 328.56 | 5.33 | 6755 | |||
27.2 | 2000 | 402.56 | 4.97 | 7213 | |||
33.1 | 2250 | 489.88 | 4.59 | 7592 | |||
39.2 | 2500 | 580.16 | 4.31 | 7945 | |||
54.3 | 3200 | 803.64 | 3.98 | 8813 | |||
16.8 | 3.5 | 500 | 58.8 | 8.50 | 3699 | ||
5.8 | 750 | 97.44 | 7.70 | 4484 | |||
8.6 | 1000 | 144.48 | 6.92 | 5124 | |||
11.8 | 1250 | 198.24 | 6.31 | 5681 | |||
15.5 | 1500 | 260.4 | 5.76 | 6211 | |||
19.7 | 1750 | 330.96 | 5.29 | 6721 | |||
24.2 | 2000 | 406.56 | 4.92 | 7192 | |||
28.8 | 2250 | 483.84 | 4.65 | 7525 | |||
34.3 | 2500 | 576.24 | 4.34 | 7924 | |||
44.7 | 3000 | 750.96 | 3.99 | 8638 | |||
66.5 | 3850 | 1117.2 | 3.45 | 9525 | 1min10s 90℃ | ||
EOLO 14*7 | 16.8 | 4.9 | 500 | 54.39 | 9.19 | 3293 |
|
8.4 | 750 | 93.24 | 8.04 | 3963 | |||
12.4 | 1000 | 137.64 | 7.27 | 4570 | |||
16.3 | 1250 | 180.93 | 6.91 | 5096 | |||
21.2 | 1500 | 235.32 | 6.37 | 5598 | |||
27.3 | 1750 | 303.03 | 5.78 | 6017 | |||
33.8 | 2000 | 375.18 | 5.33 | 6370 | |||
38.9 | 2200 | 431.79 | 5.10 | 6675 | |||
11．1 | 4.4 | 500 | 55 | 9.09 | 3272 | ||
7.3 | 750 | 91.25 | 8.22 | 3986 | |||
11 | 1000 | 137.5 | 7.27 | 4571 | |||
14.9 | 1250 | 186.25 | 6.71 | 5085 | |||
19.5 | 1500 | 243.75 | 6.15 | 5581 | |||
24.5 | 1750 | 306.25 | 5.71 | 6035 | |||
30.4 | 2000 | 380 | 5.26 | 6351 | |||
35.9 | 2250 | 448.75 | 5.01 | 6738 | |||
43.6 | 2500 | 545 | 4.59 | 7089 | |||
46.8 | 2700 | 585 | 4.62 | 7312 | 5min 90℃ | ||
12.5 | 3.6 | 500 | 53.28 | 9.38 | 3235 |
| |
6.1 | 750 | 90.28 | 8.31 | 3956 | |||
9 | 1000 | 133.2 | 7.51 | 4527 | |||
12.4 | 1250 | 183.52 | 6.81 | 5087 | |||
16.4 | 1500 | 242.72 | 6.18 | 5524 | |||
20.6 | 1750 | 304.88 | 5.74 | 5977 | |||
25.3 | 2000 | 374.44 | 5.34 | 6379 | |||
30.6 | 2250 | 452.88 | 4.97 | 6774 | |||
36.2 | 2500 | 535.76 | 4.67 | 7071 | |||
49.5 | 3000 | 732.6 | 4.10 | 7750 | |||
61.9 | 3610 | 916.12 | 3.94 | 8349 | |||
14.8 | 3.2 | 500 | 53.76 | 9.30 | 3251 | ||
5.5 | 750 | 92.4 | 8.12 | 3970 | |||
8.1 | 1000 | 136.08 | 7.35 | 4582 | |||
11.1 | 1250 | 186.48 | 6.70 | 5097 | |||
14.5 | 1500 | 243.6 | 6.16 | 5539 | |||
18.3 | 1750 | 307.44 | 5.69 | 5995 | |||
22.7 | 2000 | 381.36 | 5.24 | 6378 | |||
27.2 | 2250 | 456.96 | 4.92 | 6776 | |||
32.4 | 2500 | 544.32 | 4.59 | 7118 | |||
43.7 | 3000 | 734.16 | 4.09 | 7635 | |||
57.1 | 3500 | 959.28 | 3.65 | 8184 | |||
75 | 4300 | 1260 | 3.41 | 9053 | 45s 101℃ | ||
EOLO14*8 | 11.1 | 4.9 | 500 | 54.39 | 9.19 | 3164 |
|
8.4 | 750 | 93.24 | 8.04 | 3886 | |||
12.5 | 1000 | 138.75 | 7.21 | 4448 | |||
17 | 1250 | 188.7 | 6.62 | 4944 | |||
22 | 1500 | 244.2 | 6.14 | 5390 | |||
28.3 | 1750 | 314.13 | 5.57 | 5777 | |||
35.2 | 2000 | 390.72 | 5.12 | 6263 | |||
40.1 | 2330 | 445.11 | 5.23 | 6571 | |||
12.5 | 4.4 | 500 | 55 | 9.09 | 3174 | ||
7.4 | 750 | 92.5 | 8.11 | 3875 | |||
11 | 1000 | 137.5 | 7.27 | 4434 | |||
15.1 | 1250 | 188.75 | 6.62 | 4935 | |||
20.1 | 1500 | 251.25 | 5.97 | 5380 | |||
25.2 | 1750 | 315 | 5.56 | 5773 | |||
31.5 | 2000 | 393.75 | 5.08 | 6253 | |||
37.6 | 2250 | 470 | 4.79 | 6588 | |||
45.4 | 2500 | 567.5 | 4.41 | 6877 | |||
51.5 | 2760 | 643.75 | 4.29 | 7090 | 3min 87℃ |
Specifications | X3120II | Max Continuous Current | 93A/30s |
Stator Diameter | 31mm | Max Continuous Power | 1562.4w |
Stator Thickness | 20mm | Weight | 157g |
No.of Stator Slots | 12 | Rotor Diameter | 37.7mm |
No.of Rotor Poles | 14 | Body Length | 39.5mm |
Motor Kv | 950 | Max Lipo Cell | 3-4S |
NO-Load Current(A/10V) | 1.5A | ESC | 130A |
Motor Resistance | 19mΩ | Recommend Prop(inch) | EOLO12*6.5 13*7 14*7 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 14.8 | 4.5 | 500 | 66.6 | 7.51 | 4368 |
|
7.4 | 750 | 109.52 | 6.85 | 5305 | |||
11 | 1000 | 162.8 | 6.14 | 6112 | |||
15.1 | 1250 | 223.48 | 5.59 | 6762 | |||
19.3 | 1500 | 285.64 | 5.25 | 7454 | |||
23.9 | 1750 | 353.72 | 4.95 | 7930 | |||
29.2 | 2000 | 432.16 | 4.63 | 8445 | |||
35.4 | 2250 | 523.92 | 4.29 | 8907 | |||
41.7 | 2500 | 617.16 | 4.05 | 9354 | |||
58.6 | 3150 | 867.28 | 3.63 | 10289 | |||
16.8 | 3.8 | 500 | 63.84 | 7.83 | 4320 | ||
6.6 | 750 | 110.88 | 6.76 | 5294 | |||
9.7 | 1000 | 162.96 | 6.14 | 6083 | |||
13 | 1250 | 218.4 | 5.72 | 6784 | |||
16.9 | 1500 | 283.92 | 5.28 | 7409 | |||
21.4 | 1750 | 359.52 | 4.87 | 7950 | |||
26 | 2000 | 436.8 | 4.58 | 8490 | |||
31.1 | 2250 | 522.48 | 4.31 | 8958 | |||
36.5 | 2500 | 613.2 | 4.08 | 9323 | |||
49.4 | 3000 | 829.92 | 3.61 | 10220 | |||
63.4 | 3500 | 1065.12 | 3.29 | 11025 | |||
72.8 | 3900 | 1223.04 | 3.19 | 11297 | 1min 91℃ | ||
EOLO 13*7 | 14.8 | 4.1 | 500 | 60.68 | 8.24 | 3684 |
|
6.9 | 750 | 102.12 | 7.34 | 4543 | |||
10.2 | 1000 | 150.96 | 6.62 | 5215 | |||
14 | 1250 | 207.2 | 6.03 | 5836 | |||
18.1 | 1500 | 267.88 | 5.60 | 6282 | |||
22.6 | 1750 | 334.48 | 5.23 | 6791 | |||
28.5 | 2000 | 421.8 | 4.74 | 7247 | |||
33.4 | 2250 | 494.32 | 4.55 | 7665 | |||
40.7 | 2500 | 602.36 | 4.15 | 8076 | |||
55.3 | 3000 | 818.44 | 3.67 | 8778 | |||
76 | 3750 | 1124.8 | 3.33 | 9476 | |||
16.8 | 3.7 | 500 | 62.16 | 8.04 | 3688 | ||
6 | 750 | 100.8 | 7.44 | 4525 | |||
9 | 1000 | 151.2 | 6.61 | 5230 | |||
12.4 | 1250 | 208.32 | 6.00 | 5817 | |||
16.3 | 1500 | 273.84 | 5.48 | 6285 | |||
20.2 | 1750 | 339.36 | 5.16 | 6778 | |||
25.4 | 2000 | 426.72 | 4.69 | 7230 | |||
30.6 | 2250 | 514.08 | 4.38 | 7670 | |||
36 | 2500 | 604.8 | 4.13 | 8031 | |||
48.8 | 3000 | 819.84 | 3.66 | 8741 | |||
62.8 | 3500 | 1055.04 | 3.32 | 9278 | |||
92.1 | 4380 | 1547.28 | 2.83 | 10257 | 30s 80℃ | ||
EOLO 13*7 | 11.1 | 5.2 | 500 | 57.72 | 8.66 | 3667 |
|
8.9 | 750 | 98.79 | 7.59 | 4514 | |||
13.2 | 1000 | 146.52 | 6.83 | 5182 | |||
18.3 | 1250 | 203.13 | 6.15 | 5770 | |||
24.1 | 1500 | 267.51 | 5.61 | 6335 | |||
30.4 | 1750 | 337.44 | 5.19 | 6850 | |||
37.6 | 2000 | 417.36 | 4.79 | 7287 | |||
48.4 | 2430 | 537.24 | 4.52 | 7765 | |||
12.5 | 4.8 | 500 | 60 | 8.33 | 3647 | ||
8 | 750 | 100 | 7.50 | 4557 | |||
12 | 1000 | 150 | 6.67 | 5184 | |||
16.7 | 1250 | 208.75 | 5.99 | 5756 | |||
21.6 | 1500 | 270 | 5.56 | 6326 | |||
27.1 | 1750 | 338.75 | 5.17 | 6851 | |||
33.9 | 2000 | 423.75 | 4.72 | 7239 | |||
40.4 | 2250 | 505 | 4.46 | 7613 | |||
48.1 | 2500 | 601.25 | 4.16 | 8044 | |||
57.1 | 2860 | 713.75 | 4.01 | 8461 | 5min 92℃ | ||
EOLO 14*7 | 11.1 | 4.7 | 500 | 52.17 | 9.58 | 3218 |
|
7.9 | 750 | 87.69 | 8.55 | 3948 | |||
11.9 | 1000 | 132.09 | 7.57 | 4582 | |||
16.5 | 1250 | 183.15 | 6.83 | 5071 | |||
21.8 | 1500 | 241.98 | 6.20 | 5572 | |||
27.4 | 1750 | 304.14 | 5.75 | 5981 | |||
33.8 | 2000 | 375.18 | 5.33 | 6378 | |||
40.6 | 2250 | 450.66 | 4.99 | 6739 | |||
49.3 | 2500 | 547.23 | 4.57 | 7060 | |||
57.3 | 2850 | 636.03 | 4.48 | 7460 | |||
12.5 | 4.3 | 500 | 53.75 | 9.30 | 3250 | ||
7.2 | 750 | 90 | 8.33 | 3925 | |||
10.8 | 1000 | 135 | 7.41 | 4550 | |||
14.8 | 1250 | 185 | 6.76 | 5086 | |||
19.4 | 1500 | 242.5 | 6.19 | 5536 | |||
24.5 | 1750 | 306.25 | 5.71 | 5972 | |||
30.1 | 2000 | 376.25 | 5.32 | 6359 | |||
36.1 | 2250 | 451.25 | 4.99 | 6776 | |||
43.2 | 2500 | 540 | 4.63 | 7097 | |||
68.9 | 3380 | 861.25 | 3.92 | 8115 | 2min40s 95℃ |
Specifications | X3120II | Max Continuous Current | 86A/30s |
Stator Diameter | 31mm | Max Continuous Power | 1075w |
Stator Thickness | 20mm | Weight | 152g |
No.of Stator Slots | 12 | Rotor Diameter | 37.7mm |
No.of Rotor Poles | 14 | Body Length | 39.5mm |
Motor Kv | 1100 | Max Lipo Cell | 3S |
NO-Load Current(A/10V) | 2.2A | ESC | 130A |
Motor Resistance | 16mΩ | Recommend Prop(inch) | EOLO12*6.5 13*7 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 13*7 | 11.1 | 5.7 | 500 | 63.27 | 7.90 | 4261 |
|
9.6 | 750 | 106.56 | 7.04 | 5209 | |||
14.1 | 1000 | 156.51 | 6.39 | 6038 | |||
19.4 | 1250 | 215.34 | 5.80 | 6640 | |||
25.3 | 1500 | 280.83 | 5.34 | 7295 | |||
32.1 | 1750 | 356.31 | 4.91 | 7853 | |||
40.1 | 2000 | 445.11 | 4.49 | 8294 | |||
48.2 | 2250 | 535.02 | 4.21 | 8852 | |||
58 | 2600 | 643.8 | 4.04 | 9312 | |||
12.5 | 5.2 | 500 | 65 | 7.69 | 4252 | ||
8.8 | 750 | 110 | 6.82 | 5192 | |||
12.8 | 1000 | 160 | 6.25 | 5994 | |||
17.4 | 1250 | 217.5 | 5.75 | 6697 | |||
23 | 1500 | 287.5 | 5.22 | 7309 | |||
29 | 1750 | 362.5 | 4.83 | 7851 | |||
35.6 | 2000 | 445 | 4.49 | 8301 | |||
43.1 | 2250 | 538.75 | 4.18 | 8820 | |||
51.3 | 2500 | 641.25 | 3.90 | 9289 | |||
69.3 | 3100 | 866.25 | 3.58 | 10058 | 3min30s 74℃ | ||
EOLO 13*7 | 11.1 | 5.5 | 500 | 61.05 | 8.19 | 3684 |
|
9.2 | 750 | 102.12 | 7.34 | 4543 | |||
13.8 | 1000 | 153.18 | 6.53 | 5215 | |||
19 | 1250 | 210.9 | 5.93 | 5836 | |||
25.1 | 1500 | 278.61 | 5.38 | 6282 | |||
31.5 | 1750 | 349.65 | 5.01 | 6791 | |||
39.7 | 2000 | 440.67 | 4.54 | 7247 | |||
47.5 | 2250 | 527.25 | 4.27 | 7665 | |||
57.5 | 2500 | 638.25 | 3.92 | 8076 | |||
72 | 2950 | 799.2 | 3.69 | 8778 | |||
12.5 | 5 | 500 | 63.75 | 7.84 | 3688 | ||
8.3 | 750 | 103.75 | 7.23 | 4525 | |||
12.2 | 1000 | 152.5 | 6.56 | 5230 | |||
16.8 | 1250 | 210 | 5.95 | 5817 | |||
22.2 | 1500 | 277.5 | 5.41 | 6285 | |||
28.4 | 1750 | 355 | 4.93 | 6778 | |||
34.6 | 2000 | 432.5 | 4.62 | 7230 | |||
42.4 | 2250 | 530 | 4.25 | 7670 | |||
50.6 | 2500 | 632.5 | 3.95 | 8031 | |||
68.7 | 3000 | 858.75 | 3.49 | 8741 | |||
85.4 | 3500 | 1067.5 | 3.28 | 9278 | 2min 102℃ |
