| Motor Model / KV | X2814-III/ KV900 | X2814-III/ KV1000 | X2814-III/ KV1200 | X2814-III/ KV1400 | X2814-III/ KV1250 | X2814-V2/KV1450 |
|---|---|---|---|---|---|---|
| Stator/Rotor Poles | 12N14P | 12N14P | 12N14P | 12N14P | 12N14P | 12N14P |
| Internal resistance | 33.6mΩ | 35.5mΩ | 21.3mΩ | 15.9mΩ | 21.3mΩ | 18mΩ |
| Motor size | Motor length：36mm |
Motor length：36mm |
φ35.0*54.0mm |
Motor length：36mm |
Motor length：36mm | Motor length: 36mm |
| Shaft diameter | 4.0mm | 4.0mm | 4.0mm | 4.0mm | 4.0mm | 35mm |
| AWG | 20AWG 110mm | 20AWG 110mm | 20AWG 110mm | 20AWG 110mm | 20AWG 110mm | 20AWG 100mm |
| Motor weight(wire included) | 108g | 113g | 110g | 109g | 110g | 109g |
| Motor weight(wire excluded) | No data | No data | No data | No data | No data | No data |
| Rated operational voltage | 3-4S | 3-4S | 3-4S | 3-4S | 3-4S | 4s |
| No-load current | 1.2A/10V | 1.3A/10V | 1.7A/10V | 2.3A/10V | 1.7A | 2.1A |
| Maximum continuous power | 680W | 750W | 815W | 1180W | 950W | 1440W |
| Maximum continuous current | 50A/30s | 55A/30s | 55A/30s | 80A/30s | 64A/30s | 86A/30s |
| ESC recommended use | 40-60A | 40-60A | 50-60A | 80A | 50-60A | 130A |
| Propeller size recommended use | EOLO12*6.5 EOLO13*7 APC11*5.5 APC13*6.5 APC11*8 APC13*8 | EOLO12*6.5 EOLO13*7 APC11*5.5 APC13*6.5 APC12*6 APC12*8 | APC11*5.5/APC1050/APC9060 | APC8060/APC9060 | APC11*5.5 APC1050 APC9060 | 7060/8060 |
Specifications | X2814 | Max Continuous Current | 50A/30s |
Stator Diameter | 28mm | Max Continuous Power | 680W |
Stator Thickness | 14mm | Weight | 108g |
No.of Stator Slots | 12 | Rotor Diameter | 35mm |
No.of Rotor Poles | 14 | Body Length | 36mm |
Motor Kv | 900 | Max Lipo Cell | 3-4S |
NO-Load Current(A/10V) | 1.2A | ESC | 40-60A |
Motor Resistance | 33.6mΩ | Recommend Prop(inch) | EOLO12*6.5 EOLO13*7 APC11*5.5 APC13*6.5 APC11*8 APC13*8 |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 11.1 | 5 | 500 | 55.5 | 9.01 | 4203 |
|
8.75 | 750 | 97.125 | 7.72 | 5074 | |||
13.2 | 1000 | 146.52 | 6.83 | 5900 | |||
18.3 | 1250 | 203.13 | 6.15 | 6500 | |||
24 | 1500 | 266.4 | 5.63 | 7159 | |||
31.8 | 1820 | 352.98 | 5.16 | 7776 | |||
14.8 | 3.8 | 500 | 56.24 | 8.89 | 4159 | ||
6.7 | 750 | 99.16 | 7.56 | 5138 | |||
10.2 | 1000 | 150.96 | 6.62 | 5887 | |||
13.8 | 1250 | 204.24 | 6.12 | 6640 | |||
18.3 | 1500 | 270.84 | 5.54 | 7160 | |||
23.2 | 1750 | 343.36 | 5.10 | 7660 | |||
28.5 | 2000 | 421.8 | 4.74 | 8203 | |||
35 | 2250 | 518 | 4.34 | 8636 | |||
42 | 2500 | 621.6 | 4.02 | 9010 | |||
51.3 | 2900 | 759.24 | 3.82 | 9604 | 115℃ 1min | ||
EOLO 13*7 | 11.1 | 5.1 | 500 | 56.61 | 8.83 | 3644 |
|
8.6 | 750 | 95.46 | 7.86 | 4385 | |||
12.9 | 1000 | 143.19 | 6.98 | 5070 | |||
17.9 | 1250 | 198.69 | 6.29 | 5610 | |||
23.4 | 1500 | 259.74 | 5.78 | 6070 | |||
30.6 | 1750 | 339.66 | 5.15 | 6570 | |||
42.4 | 2210 | 470.64 | 4.70 | 7115 | 103℃ 10min | ||
APC13*6.5 | 11.1 | 4.8 | 500 | 53.28 | 9.38 | 3913 |
|
8.4 | 750 | 93.24 | 8.04 | 4724 | |||
12.9 | 1000 | 143.19 | 6.98 | 5424 | |||
18 | 1250 | 199.8 | 6.26 | 6088 | |||
23.6 | 1500 | 261.96 | 5.73 | 6536 | |||
30.9 | 1750 | 342.99 | 5.10 | 7029 | |||
39.4 | 2110 | 437.34 | 4.82 | 7668 | 95℃ 10min | ||
APC13*8 | 11.1 | 5.1 | 500 | 56.61 | 8.83 | 3693 |
|
8.9 | 750 | 98.79 | 7.59 | 4506 | |||
13.7 | 1000 | 152.07 | 6.58 | 5234 | |||
19.1 | 1250 | 212.01 | 5.90 | 5751 | |||
25.5 | 1500 | 283.05 | 5.30 | 6295 | |||
32.6 | 1750 | 361.86 | 4.84 | 6770 | |||
40.9 | 2000 | 453.99 | 4.41 | 7205 | |||
44.5 | 2180 | 493.95 | 4.41 | 7463 | 105℃ 10min | ||
APC11*5.5 | 14.8 | 4.3 | 500 | 63.64 | 7.86 | 5430 |
|
7 | 750 | 103.6 | 7.24 | 6576 | |||
10.8 | 1000 | 159.84 | 6.26 | 7460 | |||
14.8 | 1250 | 219.04 | 5.71 | 8219 | |||
19.1 | 1500 | 282.68 | 5.31 | 9100 | |||
25.3 | 1750 | 374.44 | 4.67 | 9660 | |||
30.5 | 2000 | 451.4 | 4.43 | 10310 | |||
37.2 | 2299 | 550.56 | 4.18 | 10978 | 90℃ 10min | ||
APC11*8 | 14.8 | 4.7 | 500 | 69.56 | 7.19 | 4830 |
|
8.3 | 750 | 122.84 | 6.11 | 5852 | |||
12.3 | 1000 | 182.04 | 5.49 | 6720 | |||
16.9 | 1250 | 250.12 | 5.00 | 7512 | |||
22.3 | 1500 | 330.04 | 4.54 | 8166 | |||
28.8 | 1750 | 426.24 | 4.11 | 8727 | |||
34.5 | 2000 | 510.6 | 3.92 | 9307 | |||
45.5 | 2320 | 673.4 | 3.45 | 10221 | 94℃ 3min |
Specifications | X2814 | Max Continuous Current | 55A/30s |
Stator Diameter | 28mm | Max Continuous Power | 750W |
Stator Thickness | 14mm | Weight | 113g |
No.of Stator Slots | 12 | Rotor Diameter | 35mm |
No.of Rotor Poles | 14 | Body Length | 36mm |
MotorKv | 1000 | MaxLipo Cell | 3-4S |
NO-Load Current(A/10V) | 1.3A | ESC | 40-60A |
Motor Resistance | 35.5mΩ | Recommend Prop(inch) | EOLO12*6.5 EOLO13*7 APC11*5.5 APC13*6.5 APC12*6 APC12*8 |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO 12*6.5 | 11.1 | 5.2 | 500 | 57.72 | 8.66 | 4312 |
|
9.1 | 750 | 101.01 | 7.43 | 5170 | |||
13.6 | 1000 | 150.96 | 6.62 | 5956 | |||
18.9 | 1250 | 209.79 | 5.96 | 6615 | |||
24.8 | 1500 | 275.28 | 5.45 | 7218 | |||
31.4 | 1750 | 348.54 | 5.02 | 7776 | |||
38.7 | 2000 | 429.57 | 4.66 | 8265 | |||
44 | 2260 | 488.4 | 4.63 | 8370 | 80℃ 5min | ||
EOLO 13*7 | 11.1 | 5 | 500 | 55.5 | 9.01 | 3690 |
|
9 | 750 | 99.9 | 7.51 | 4435 | |||
13.5 | 1000 | 149.85 | 6.67 | 5060 | |||
19 | 1250 | 210.9 | 5.93 | 5632 | |||
25.7 | 1500 | 285.27 | 5.26 | 6137 | |||
32.6 | 1750 | 361.86 | 4.84 | 6593 | |||
41.5 | 2000 | 460.65 | 4.34 | 7059 | |||
51.9 | 2395 | 576.09 | 4.16 | 7460 | 88℃ 5min | ||
APC13*6.5 | 11.1 | 5 | 500 | 55.5 | 9.01 | 3960 |
|
9 | 750 | 99.9 | 7.51 | 4832 | |||
13.5 | 1000 | 149.85 | 6.67 | 5590 | |||
19 | 1250 | 210.9 | 5.93 | 6203 | |||
25.8 | 1500 | 286.38 | 5.24 | 6767 | |||
32.8 | 1750 | 364.08 | 4.81 | 7330 | |||
41.7 | 2000 | 462.87 | 4.32 | 7780 | |||
50.7 | 2300 | 562.77 | 4.09 | 7979 | 86℃ 5min | ||
APC12*6 | 11.1 | 5.4 | 500 | 59.94 | 8.34 | 4100 |
|
9.3 | 750 | 103.23 | 7.27 | 5580 | |||
14 | 1000 | 155.4 | 6.44 | 6290 | |||
19 | 1250 | 210.9 | 5.93 | 6970 | |||
25 | 1500 | 277.5 | 5.41 | 7620 | |||
31.5 | 1750 | 349.65 | 5.01 | 8157 | |||
41.3 | 2050 | 458.43 | 4.47 | 8687 | 75℃ 5min | ||
APC12*8 | 11.1 | 5.6 | 500 | 62.16 | 8.04 | 4205 |
|
9.1 | 750 | 101.01 | 7.43 | 5061 | |||
15.2 | 1000 | 168.72 | 5.93 | 5862 | |||
20.4 | 1250 | 226.44 | 5.52 | 6475 | |||
27.8 | 1500 | 308.58 | 4.86 | 7044 | |||
35.1 | 1750 | 389.61 | 4.49 | 7631 | |||
44.9 | 2070 | 498.39 | 4.15 | 8293 | 80 10min | ||
APC11*5.5 | 11.1 | 5.6 | 500 | 62.16 | 8.04 | 5338 |
|
9.55 | 750 | 106.005 | 7.08 | 6476 | |||
14 | 1000 | 155.4 | 6.44 | 7438 | |||
19.4 | 1250 | 215.34 | 5.80 | 8304 | |||
25.4 | 1500 | 281.94 | 5.32 | 9014 | |||
29.6 | 1655 | 328.56 | 5.04 | 9488 | |||
14.8 | 4.4 | 500 | 65.12 | 7.68 | 5327 | ||
7.5 | 750 | 111 | 6.76 | 6481 | |||
11 | 1000 | 162.8 | 6.14 | 7420 | |||
15.2 | 1250 | 224.96 | 5.56 | 8345 | |||
19.7 | 1500 | 291.56 | 5.14 | 8984 | |||
24.8 | 1750 | 367.04 | 4.77 | 9652 | |||
30.2 | 2000 | 446.96 | 4.47 | 10209 | |||
45.6 | 2556 | 674.88 | 3.79 | 11676 | 85℃ 10min |
| Stator Diameter | 28mm | Rotor Diameter | 35mm |
|---|---|---|---|
| Stator Thickness | 14mm | Body Length | 36mm |
| No.of Stator Slots | 12 | Max Lipo Cell | 3-4S |
| No.of Rotor Poles | 14 | ESC | 50-60A |
| Motor Kv | 1200 | Recommended Prop(inch) | APC11*5.5/APC1050/APC9060 |
| No-load current | 1.7A/10V | Weight for aerobatics airplane | 1000g-1300g (4S APC1060\APC9060\APC8060) (3S APC11*5.5) |
| Motor Resistance | 21.3mΩ | ||
| Max Continuous Current | 55A/30s | ||
| Max Continuous Power | 815W | ||
| Weight | 110g |
| Prop(inch) | Voltage(V) | Amps(A) | Thrust(gf) | Watts(W) | Efficiency(g/W) | RPM | Load temperature in 100% throttle |
|---|---|---|---|---|---|---|---|
| APC11*5.5 | 11.1 | 6 | 500 | 66.6 | 7.51 | 5410 | 57℃ 10min |
| 10.3 | 750 | 114.33 | 6.56 | 6557 | |||
| 14.9 | 1000 | 165.39 | 6.05 | 7512 | |||
| 20.3 | 1250 | 225.33 | 5.55 | 8260 | |||
| 27 | 1500 | 299.7 | 5.01 | 9139 | |||
| 33.9 | 1750 | 376.29 | 4.65 | 9692 | |||
| 45.5 | 2060 | 505.05 | 4.08 | 10624 | |||
| APC1050 | 11.1 | 6.6 | 500 | 73.26 | 6.83 | 6268 | 76℃ 10min |
| 10.7 | 750 | 118.77 | 6.31 | 7536 | |||
| 16.1 | 1000 | 178.71 | 5.60 | 8706 | |||
| 22.25 | 1250 | 246.975 | 5.06 | 9629 | |||
| 29 | 1500 | 321.9 | 4.66 | 10417 | |||
| 34.6 | 1670 | 384.06 | 4.35 | 11201 | |||
| 14.8 | 5.1 | 500 | 75.48 | 6.62 | 6234 | ||
| 8.1 | 750 | 119.88 | 6.26 | 6534 | |||
| 12.7 | 1000 | 187.96 | 5.32 | 8759 | |||
| 17.1 | 1250 | 253.08 | 4.94 | 9635 | |||
| 22.4 | 1500 | 331.52 | 4.52 | 10427 | |||
| 28.1 | 1750 | 415.88 | 4.21 | 11192 | |||
| 35.8 | 2000 | 529.84 | 3.77 | 11899 | |||
| 41.15 | 2250 | 609.02 | 3.69 | 12544 | |||
| 53.8 | 2650 | 796.24 | 3.33 | 13778 | |||
| APC9060 | 14.8 | 6 | 500 | 88.8 | 5.63 | 6795 | 62℃ 10min |
| 10 | 750 | 148 | 5.07 | 8200 | |||
| 14.7 | 1000 | 217.56 | 4.60 | 9379 | |||
| 20.1 | 1250 | 297.48 | 4.20 | 10336 | |||
| 26.2 | 1500 | 387.76 | 3.87 | 11271 | |||
| 32.9 | 1750 | 486.92 | 3.59 | 12115 | |||
| 43.3 | 2000 | 640.84 | 3.12 | 12926 | |||
| 52.3 | 2360 | 774.04 | 3.05 | 13942 |
Specifications | X2814 | Max Continuous Current | 80A/30s |
Stator Diameter | 28mm | Max Continuous Power | 1180W |
Stator Thickness | 14mm | Weight | 109g |
No.of Stator Slots | 12 | Rotor Diameter | 35mm |
No.of Rotor Poles | 14 | Body Length | 36mm |
MotorKv | 1400 | MaxLipo Cell | 3-4S |
NO-Load Current(A/10V) | 2.3A | ESC | 80A |
Motor Resistance | 15.9mΩ | Recommend Prop(inch) | APC8060 APC9060 |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
APC8060 | 14.8 | 8.2 | 500 | 121.36 | 4.12 | 8282 |
|
13.9 | 750 | 205.72 | 3.65 | 9958 | |||
21.3 | 1000 | 315.24 | 3.17 | 11388 | |||
30.2 | 1250 | 446.96 | 2.80 | 12540 | |||
40.9 | 1500 | 605.32 | 2.48 | 13893 | |||
54.6 | 1750 | 808.08 | 2.17 | 14775 | |||
70.4 | 2024 | 1041.92 | 1.94 | 16088 | 85℃ 3min | ||
APC9060 | 6.3 | 500 | 93.24 | 5.36 | 6825 |
| |
10.7 | 750 | 158.36 | 4.74 | 8285 | |||
15.9 | 1000 | 235.32 | 4.25 | 9333 | |||
21.8 | 1250 | 322.64 | 3.87 | 10370 | |||
31.2 | 1500 | 461.76 | 3.25 | 11200 | |||
42.2 | 1750 | 624.56 | 2.80 | 12072 | |||
58.4 | 2000 | 864.32 | 2.31 | 12804 | |||
71.4 | 2250 | 1056.72 | 2.13 | 15171 | 90℃ 1min30S |
Specifications | X2814 | Max Continuous Current | 64A/30s |
Stator Diameter | 28mm | Max Continuous Power | 950W |
Stator Thickness | 14mm | Weight | 110g |
No.of Stator Slots | 12 | Rotor Diameter | 35mm |
No.of Rotor Poles | 14 | Body Length | 36mm |
Motor Kv | 1250 | Max Lipo Cell | 3-4S |
NO-Load Current(A/10V) | 1.7A | ESC | 50-60A |
Motor Resistance | 21.3mΩ | Recommend Prop(inch) | APC11*5.5 APC1050 APC9060 |
propeller（inch） | Voltage (V) | Amps (A) | Thrust(g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
APC11*5.5 | 11.1 | 6 | 500 | 66.6 | 7.51 | 5410 |
|
10.3 | 750 | 114.33 | 6.56 | 6557 | |||
14.9 | 1000 | 165.39 | 6.05 | 7512 | |||
20.3 | 1250 | 225.33 | 5.55 | 8260 | |||
27 | 1500 | 299.7 | 5.01 | 9139 | |||
33.9 | 1750 | 376.29 | 4.65 | 9692 | |||
45.5 | 2060 | 505.05 | 4.08 | 10624 | 75℃ 10min | ||
APC1050 | 11.1 | 6.6 | 500 | 73.26 | 6.83 | 6268 |
|
10.7 | 750 | 118.77 | 6.31 | 7536 | |||
16.1 | 1000 | 178.71 | 5.60 | 8706 | |||
22.25 | 1250 | 246.975 | 5.06 | 9629 | |||
29 | 1500 | 321.9 | 4.66 | 10417 | |||
34.6 | 1670 | 384.06 | 4.35 | 11201 | |||
14.8 | 5.1 | 500 | 75.48 | 6.62 | 6234 | ||
8.1 | 750 | 119.88 | 6.26 | 6534 | |||
12.7 | 1000 | 187.96 | 5.32 | 8759 | |||
17.1 | 1250 | 253.08 | 4.94 | 9635 | |||
22.4 | 1500 | 331.52 | 4.52 | 10427 | |||
28.1 | 1750 | 415.88 | 4.21 | 11192 | |||
35.8 | 2000 | 529.84 | 3.77 | 11899 | |||
41.15 | 2250 | 609.02 | 3.69 | 12544 | |||
53.8 | 2650 | 796.24 | 3.33 | 13778 | 92℃ 5min | ||
APC9060 | 14.8 | 6 | 500 | 88.8 | 5.63 | 6795 |
|
10 | 750 | 148 | 5.07 | 8200 | |||
14.7 | 1000 | 217.56 | 4.60 | 9379 | |||
20.1 | 1250 | 297.48 | 4.20 | 10336 | |||
26.2 | 1500 | 387.76 | 3.87 | 11271 | |||
32.9 | 1750 | 486.92 | 3.59 | 12115 | |||
43.3 | 2000 | 640.84 | 3.12 | 12926 | |||
52.3 | 2360 | 774.04 | 3.05 | 13942 | 78℃ 10min |
Specifications | X2814II | Max Continuous Current | 86A/30s |
Stator Diameter | 28mm | Max Continuous Power | 1444.8w |
Stator Thickness | 14mm | Weight | 109g |
No.of Stator Slots | 12 | Rotor Diameter | 35mm |
No.of Rotor Poles | 14 | Body Length | 36mm |
Motor Kv | 1450 | Max Lipo Cell | 4S |
NO-Load Current(A/10V) | 2.1A | ESC | 130A |
Motor Resistance | 18mΩ | Recommend Prop(inch) | 7060 8060 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
7060 | 14.8 | 3.9 | 250 | 57.72 | 4.33 | 7544 |
|
8.9 | 500 | 131.72 | 3.80 | 10670 | |||
14.6 | 750 | 216.08 | 3.47 | 12683 | |||
20.7 | 1000 | 306.36 | 3.26 | 14609 | |||
28.2 | 1250 | 417.36 | 3.00 | 16042 | |||
37.1 | 1500 | 549.08 | 2.73 | 17703 | |||
43.1 | 1660 | 637.88 | 2.60 | 18342 | |||
3.5 | 250 | 58.8 | 4.25 | 7561 | |||
16.8 | 8.1 | 500 | 136.08 | 3.67 | 10650 | ||
13.3 | 750 | 223.44 | 3.36 | 12675 | |||
19.4 | 1000 | 325.92 | 3.07 | 14704 | |||
25.4 | 1250 | 426.72 | 2.93 | 16004 | |||
33.9 | 1500 | 569.52 | 2.63 | 17592 | |||
41.2 | 1750 | 692.16 | 2.53 | 18796 | |||
54.1 | 1930 | 908.88 | 2.12 | 20064 | 70℃ | ||
8060 | 14.8 | 3.4 | 250 | 50.32 | 4.97 | 5942 |
|
7.6 | 500 | 112.48 | 4.45 | 8202 | |||
13.4 | 750 | 198.32 | 3.78 | 10115 | |||
19.9 | 1000 | 294.52 | 3.40 | 11416 | |||
28 | 1250 | 414.4 | 3.02 | 12650 | |||
37.9 | 1500 | 560.92 | 2.67 | 13760 | |||
51.7 | 1750 | 765.16 | 2.29 | 14720 | |||
68.7 | 2100 | 1016.76 | 2.07 | 16027 | |||
16.8 | 3 | 250 | 50.4 | 4.96 | 5922 | ||
6.8 | 500 | 114.24 | 4.38 | 8266 | |||
12 | 750 | 201.6 | 3.72 | 10070 | |||
18 | 1000 | 302.4 | 3.31 | 11450 | |||
25.1 | 1250 | 421.68 | 2.96 | 12678 | |||
33.8 | 1500 | 567.84 | 2.64 | 13757 | |||
45.1 | 1750 | 757.68 | 2.31 | 14736 | |||
57.8 | 2000 | 971.04 | 2.06 | 15771 | |||
85.8 | 2450 | 1441.44 | 1.70 | 17301 | 60℃ |
