Motor Model / KV X2220-III/ KV980 X2220-III/ KV1400
Stator/Rotor Poles 12N14P 12N14P
Internal resistance 51mΩ 29mΩ
Motor size Motor length: 38mm Motor length:38mm
Shaft diameter 4.0mm 4.0mm
AWG 20AWG 100mm 20AWG 100mm
Motor weight(wire included) 85g 85g
Motor weight(wire excluded) No data No data
Rated operational voltage 3-4S 3S
No-load current 0.7A/10V 1.5A
Maximum continuous power 638W 745W
Maximum continuous current 38A/30s 45A/30s
ESC recommended use 40A 40-60A
Propeller size recommended use APC9047/APC9045/APC9060/APC1047/APC1147 APC9045 APC9047 APC9060 APC8060

X2220-III

Specifications

X2220

Max Continuous Current

38A/30s

Stator Diameter

22mm

Max Continuous Power

638W

Stator Thickness

20mm

Weight

85g

No.of Stator Slots

12

Rotor Diameter

27.7mm

No.of Rotor Poles

14

Body Length

38mm

MotorKv

980

MaxLipo Cell

3S-4S

NO-Load Current(A/10V)

0.7A

ESC

40A

Motor Resistance

51mΩ

Recommend Prop(inch)

APC9047 APC9045 APC9060 APC1047 APC1147


propeller inch

Voltage (V)

Amps (A)

Thrust(g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in 100% throttle

APC9060

11.1

1

100

11.1

9.01

3146



2.5

200

27.75

7.21

4388

4.1

300

45.51

6.59

5265

5.5

400

61.05

6.55

6060

7.2

500

79.92

6.26

6710

9.1

600

101.01

5.94

7229

10.9

700

120.99

5.79

7843

13.7

800

152.07

5.26

8442

16.5

900

183.15

4.91

8886

18.7

1020

207.57

4.91

9583

14.8

0.8

100

11.84

8.45

3108

1.8

200

26.64

7.51

4296

2.9

300

42.92

6.99

5210

4.2

400

62.16

6.44

5949

5.6

500

82.88

6.03

6823

7.1

600

105.08

5.71

7303

8.6

700

127.28

5.50

7801

10.8

800

159.84

5.01

8398

12.6

900

186.48

4.83

8827

14.3

1000

211.64

4.73

9338

17.4

1100

257.52

4.27

9692

20.1

1200

297.48

4.03

10167

22.8

1300

337.44

3.85

10690

25.8

1400

381.84

3.67

10900

28.6

1536

423.28

3.63

11702

16.8

0.8

100

13.44

7.44

3120

1.6

200

26.88

7.44

4462

2.6

300

43.68

6.87

5250

3.7

400

62.16

6.44

6006

5

500

84

5.95

6715

6.6

600

110.88

5.41

7276

7.9

700

132.72

5.27

7856

9.5

800

159.6

5.01

8451

11

900

184.8

4.87

8827

12.9

1000

216.72

4.61

9303

15.1

1100

253.68

4.34

9743

17.7

1200

297.36

4.04

10226

20.3

1300

341.04

3.81

10532

22.6

1400

379.68

3.69

10949

25.8

1500

433.44

3.46

11186

28.2

1600

473.76

3.38

11580

32.3

1700

542.64

3.13

11906

35.8

1850

601.44

3.08

12822

85℃ 2min

APC1047

11.1

0.8

100

8.88

11.26

2520



1.8

200

19.98

10.01

3490

3.3

300

36.63

8.19

4256

4.8

400

53.28

7.51

4755

6.6

500

73.26

6.83

5305

7.8

600

86.58

6.93

5791

9.9

700

109.89

6.37

6167

11.6

800

128.76

6.21

6608

14.2

900

157.62

5.71

6924

16.3

1000

180.93

5.53

7332

18.5

1100

205.35

5.36

7657

21

1200

233.1

5.15

7993

24

1300

266.4

4.88

8319

27

1454

299.7

4.85

8620

14.8

0.6

100

8.88

11.26

2527

1.4

200

20.72

9.65

3517

2.3

300

34.04

8.81

4236

3.5

400

51.8

7.72

4784

4.8

500

71.04

7.04

5310

6

600

88.8

6.76

5757

7.9

700

116.92

5.99

6200

9.4

800

139.12

5.75

6621

11.1

900

164.28

5.48

7020

13

1000

192.4

5.20

7318

14.6

1100

216.08

5.09

7625

17.1

1200

253.08

4.74

7990

19

1300

281.2

4.62

8287

21.2

1400

313.76

4.46

8505

23.2

1500

343.36

4.37

8860

26.1

1600

386.28

4.14

9120

29.3

1700

433.64

3.92

9405

35

1900

518

3.67

10082

38.4

2130

568.32

3.75

10476

90℃ 1min

APC9045

11.1

1.2

100

13.32

7.51

3476



2.5

200

27.75

7.21

4870

3.9

300

43.29

6.93

5722

5.2

400

57.72

6.93

6572

6.9

500

76.59

6.53

7300

8.6

600

95.46

6.29

8000

10.6

700

117.66

5.95

8600

12.7

800

140.97

5.67

9135

15.8

960

175.38

5.47

9800

14.8

0.9

100

13.32

7.51

3488

1.8

200

26.64

7.51

4890

3

300

44.4

6.76

5710

4.3

400

63.64

6.29

6571

5.4

500

79.92

6.26

7298

6.8

600

100.64

5.96

7995

8.1

700

119.88

5.84

8600

9.8

800

145.04

5.52

9124

11.4

900

168.72

5.33

9570

13.3

1000

196.84

5.08

10231

15.5

1100

229.4

4.80

10606

17.3

1200

256.04

4.69

11075

19.3

1300

285.64

4.55

11407

21.4

1400

316.72

4.42

11787

23.6

1506

349.28

4.31

12305

16.8

0.8

100

13.44

7.44

3482

1.6

200

26.88

7.44

4808

2.6

300

43.68

6.87

5777

3.7

400

62.16

6.44

6656

5.1

500

85.68

5.84

7378

6.1

600

102.48

5.85

8083

7.6

700

127.68

5.48

8618

8.8

800

147.84

5.41

9165

10.5

900

176.4

5.10

9577

12.2

1000

204.96

4.88

10237

13.8

1100

231.84

4.74

10682

15.5

1200

260.4

4.61

11085

17.5

1300

294

4.42

11404

19.7

1400

330.96

4.23

11795

21.3

1500

357.84

4.19

12160

24

1600

403.2

3.97

12605

28.5

1835

478.8

3.83

13409

75℃ 10min

APC9047

11.1

1

100

11.1

9.01

3426



2.2

200

24.42

8.19

4217

3.6

300

39.96

7.51

5588

4.9

400

54.39

7.35

6520

6.5

500

72.15

6.93

7280

8.2

600

91.02

6.59

8000

10.2

700

113.22

6.18

8730

12.3

800

136.53

5.86

9350

16.4

945

182.04

5.19

10050

14.8

0.8

100

11.84

8.45

3146

1.6

200

23.68

8.45

4527

2.7

300

39.96

7.51

5592

4

400

59.2

6.76

6521

5.3

500

78.44

6.37

7243

6.5

600

96.2

6.24

7994

8.2

700

121.36

5.77

8698

9.6

800

142.08

5.63

9338

11.2

900

165.76

5.43

9890

13

1000

192.4

5.20

10416

15.2

1100

224.96

4.89

11031

17.2

1200

254.56

4.71

11606

18.9

1300

279.72

4.65

11985

22.1

1450

327.08

4.43

12622

16.8

0.8

100

13.44

7.44

3276

1.5

200

25.2

7.94

4592

2.6

300

43.68

6.87

5603

3.6

400

60.48

6.61

6523

4.8

500

80.64

6.20

7291

6.1

600

102.48

5.85

8070

7.4

700

124.32

5.63

8753

8.9

800

149.52

5.35

9328

10.5

900

176.4

5.10

9986

11.8

1000

198.24

5.04

10550

13.6

1100

228.48

4.81

11054

15.6

1200

262.08

4.58

11617

17

1300

285.6

4.55

12095

18.9

1400

317.52

4.41

12629

21.4

1500

359.52

4.17

13164

23.3

1600

391.44

4.09

13464

25.2

1720

423.36

4.06

13965

67℃ 10min








Specifications

X2220

Max Continuous Current

45A/30s

Stator Diameter

22mm

Max Continuous Power

745W

Stator Thickness

20mm

Weight

85g

No.of Stator Slots

12

Rotor Diameter

27.7mm

No.of Rotor Poles

14

Body Length

38mm

MotorKv

1380

MaxLipo Cell

3S

NO-Load Current(A/10V)

1.5A

ESC

40-60A

Motor Resistance

29mΩ

Recommend Prop(inch)

APC9045 APC9047 APC9060 APC8060


propellerinch

Voltage (V)

Amps (A)

Thrust(g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in 100% throttle

APC9045

11.1

1.2

100

13.32

7.51

3343



2.6

200

28.86

6.93

4698

4.4

300

48.84

6.14

5640

6.1

400

67.71

5.91

6606

7.9

500

87.69

5.70

7347

9.7

600

107.67

5.57

8017

12

700

133.2

5.26

8581

14.3

800

158.73

5.04

9005

16.5

900

183.15

4.91

9618

19

1000

210.9

4.74

10146

21.8

1100

241.98

4.55

10668

25.1

1200

278.61

4.31

11082

28.3

1300

314.13

4.14

11580

31.8

1400

352.98

3.97

11778

36

1500

399.6

3.75

12354

59℃ 10min

APC9047

11.1

1.1

100

12.21

8.19

3279



2.3

200

25.53

7.83

4604

4.1

300

45.51

6.59

5712

5.8

400

64.38

6.21

6517

7.5

500

83.25

6.01

7282

9.4

600

104.34

5.75

8017

11.7

700

129.87

5.39

8710

13.8

800

153.18

5.22

9401

16

900

177.6

5.07

9940

18.5

1000

205.35

4.87

10541

20.7

1100

229.77

4.79

10958

23.7

1200

263.07

4.56

11507

26.7

1300

296.37

4.39

12060

30.4

1430

337.44

4.24

12680

54℃ 10min

APC9060

11.1

1.2

100

13.32

7.51

3122



2.5

200

27.75

7.21

4370

4.2

300

46.62

6.44

5272

6.3

400

69.93

5.72

6002

8.5

500

94.35

5.30

6736

10.4

600

115.44

5.20

7406

12.5

700

138.75

5.05

8006

15.1

800

167.61

4.77

8407

18.5

900

205.35

4.38

8882

20.8

1000

230.88

4.33

9333

24.1

1100

267.51

4.11

9776

27.8

1200

308.58

3.89

10158

31.4

1300

348.54

3.73

10604

36.6

1400

406.26

3.45

10873

40.9

1549

453.99

3.41

11679

67℃ 10min
