X2820-III
Details Technical parameters Test report Package including Photos
@@title



Motor Model / KV X2212-III/ KV1250 X2216-III/ KV570 X2820-III/ KV860 X2820-III/ KV1000
Stator/Rotor Poles 12N14P 12N14P 12N14P 12N14P
Internal resistance 54mΩ 173mΩ 25.8mΩ 18.5mΩ
Motor size Motor length：30mm Motor length：34mm Motor length：42mm
 Motor length：42mm
Shaft diameter 3.175mm 3.175mm 5.0mm 5.0mm
AWG 20AWG 100mm 20AWG 100mm 20AWG 110mm 20AWG 110mm
Motor weight(wire included) 59g 72g 143g 147g
Motor weight(wire excluded) No data No data No data No data
Rated operational voltage 3-4S 3-4S 3-4S 3-4S
No-load current 0.8A/10V 0.32A/10V 1.3A/10V 1.7A/10V
Maximum continuous power 518W 525w 960W 1036W
Maximum continuous current 35A/30S 21A/30s 65A/30s 70A/30s
ESC recommended use 30-40A 40A 50-60A 60-80A
Propeller size recommended use APC9047 APC9060 APC8060 APC7060 APC 9060 1047 EOLO12*6 EOLO13*7 APC13*6.5 APC12*6 APC12*8 4S(APC11*5.5 APC11*8) 3S(EOLO12*6.5 EOLO13*7 APC12*6 13*6.5)

X2820-III

KV1250 KV570 KV860 KV1000

Specifications

X2212

Max Continuous Current

35A/30s

Stator Diameter

22mm

Max Continuous Power

518W

Stator Thickness

12mm

Weight

59g

No.of Stator Slots

12

Rotor Diameter

27.5mm

No.of Rotor Poles

14

Body Length

30mm

Motor Kv

1250

Max Lipo Cell

3-4S

NO-Load Current(A/10V)

0.8A

ESC

20-30A

Motor Resistance

54mΩ

Recommend Prop(inch)

APC9047 APC9060 APC8060 APC7060


propeller（inch）

Voltage (V)

Amps (A)

Thrust(g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in 100% throttle

APC9047

11.1

0.8

100

8.88

11.26

3215



2

200

22.2

9.01

4595

3.3

300

36.63

8.19

5659

5.1

400

56.61

7.07

6569

6.8

500

75.48

6.62

7337

8.8

600

97.68

6.14

8041

10.9

700

120.99

5.79

8934

13.5

800

149.85

5.34

9510

16

900

177.6

5.07

10102

18.9

1000

209.79

4.77

10765

23.6

1220

261.96

4.66

11475

65℃ 10min

APC9045

11.1

0.9

100

9.99

10.01

3451



2.1

200

23.31

8.58

4722

3.6

300

39.96

7.51

5767

5.1

400

56.61

7.07

6665

6.9

500

76.59

6.53

7409

9

600

99.9

6.01

8035

11

700

122.1

5.73

8581

13.5

800

149.85

5.34

9286

16.2

900

179.82

5.01

9690

19.2

1000

213.12

4.69

10170

25.5

1210

283.05

4.27

11234

63℃ 10min

APC9060

11.1

0.9

100

9.99

10.01

3185



2.2

200

24.42

8.19

4414

3.9

300

43.29

6.93

5287

5.7

400

63.27

6.32

6129

7.9

500

87.69

5.70

6765

10.1

600

112.11

5.35

7390

12.5

700

138.75

5.05

7881

15

800

166.5

4.80

8393

18.3

900

203.13

4.43

8990

22

1000

244.2

4.10

9402

25.5

1100

283.05

3.89

9887

31.2

1290

346.32

3.72

10547

60℃ 10min

APC8060

11.1

1.2

100

13.32

7.51

3829



3

200

33.3

6.01

5533

5.1

300

56.61

5.30

6544

7.1

400

78.81

5.08

7561

9.2

500

102.12

4.90

8315

12

600

133.2

4.50

9094

15.6

700

173.16

4.04

9840

18.7

800

207.57

3.85

10403

24

950

266.4

3.57

11277

14.8

0.9

100

13.32

7.51

3897

2.2

200

32.56

6.14

5490

3.7

300

54.76

5.48

6622

5.4

400

79.92

5.01

7560

7.1

500

105.08

4.76

8484

9.1

600

134.68

4.46

9134

12.1

700

179.08

3.91

9908

15.15

800

224.22

3.57

10486

18.3

900

270.84

3.32

11119

22.5

1000

333

3.00

11586

25.4

1100

375.92

2.93

12147

29.3

1200

433.64

2.77

12573

34.8

1350

515.04

2.62

13427

77℃ 30S








Specifications

X2216-III

Max Continuous Current

21A/30s

Stator Diameter

22mm

Max Continuous Power

525w

Stator Thickness

16mm

Weight

72g

No.of Stator Slots

12

Rotor Diameter

27.7mm

No.of Rotor Poles

14

Body Length

34mm

Motor Kv

570

Max Lipo Cell

6S

NO-Load Current(A/10V)

0.32A

ESC

40A

Motor Resistance

173mΩ

Recommend Prop(inch)

APC 9060 1047





Propeller (inch)

Voltage (V)

Current (A)

Thrust (g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in 100% throttle

APC 9060

22.2

0.4

100

8.88

11.26

3148



1

200

22.2

9.01

4322

1.7

300

37.74

7.95

5281

2.5

400

55.5

7.21

6032

3.4

500

75.48

6.62

6710

4.4

600

97.68

6.14

7263

5.5

700

122.1

5.73

7847

6.7

800

148.74

5.38

8322

8

900

177.6

5.07

8796

9.5

1000

210.9

4.74

9221

12.9

1230

286.38

4.29

10146

25

0.4

100

10

10.00

3124

0.9

200

22.5

8.89

4352

1.5

300

37.5

8.00

5262

2.2

400

55

7.27

6005

3

500

75

6.67

6746

3.9

600

97.5

6.15

7254

4.9

700

122.5

5.71

7866

6

800

150

5.33

8334

7.2

900

180

5.00

8759

8.4

1000

210

4.76

9212

11.4

1200

285

4.21

10096

15.8

1470

395

3.72

11044

2min 65℃

APC 1047

22.2

0.4

100

8.88

11.26

2648



0.8

200

17.76

11.26

3592

1.4

300

31.08

9.65

4312

2.1

400

46.62

8.58

4932

2.8

500

62.16

8.04

5416

3.7

600

82.14

7.30

5931

4.6

700

102.12

6.85

6358

5.7

800

126.54

6.32

6739

6.9

900

153.18

5.88

7127

8.2

1000

182.04

5.49

7349

10.7

1200

237.54

5.05

8017

14.2

1400

315.24

4.44

8613

17.5

1650

388.5

4.25

9268

25

0.3

100

7.5

13.33

2627

0.7

200

17.5

11.43

3596

1.3

300

32.5

9.23

4341

1.9

400

47.5

8.42

4965

2.6

500

65

7.69

5421

3.4

600

85

7.06

5940

4.2

700

105

6.67

6344

5.1

800

127.5

6.27

6728

6.2

900

155

5.81

7133

7.2

1000

180

5.56

7356

9.8

1200

245

4.90

8020

12.6

1400

315

4.44

8604

15.4

1600

385

4.16

9251

19

1800

475

3.79

9816

20.5

1930

512.5

3.77

10093

40s 80℃







图片 1.jpg

Specifications

X2820

Max Continuous Current

65A/30s

Stator Diameter

28mm

Max Continuous Power

960W

Stator Thickness

20mm

Weight

143g

No.of Stator Slots

12

Rotor Diameter

35mm

No.of Rotor Poles

14

Body Length

42mm

Motor Kv

860

Max Lipo Cell

3-4S

NO-Load Current(A/10V)

1.3A

ESC

50-60A

Motor Resistance

53mΩ

Recommend Prop(inch)

EOLO12*6 \ EOLO13*7 \ APC13*6.5

APC12*6 \ APC12*8


propeller（inch）

Voltage (V)

Amps (A)

Thrust(g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in 100% throttle

EOLO 12*6.5

14.8

3.9

500

57.72

8.66

4114



6.6

750

97.68

7.68

5064

9.9

1000

146.52

6.83

5835

13.6

1250

201.28

6.21

6517

17.6

1500

260.48

5.76

7073

22.1

1750

327.08

5.35

7637

26.8

2000

396.64

5.04

8176

32.3

2250

478.04

4.71

8670

38.5

2500

569.8

4.39

9103

45.4

2750

671.92

4.09

9530

53.3

3050

788.84

3.87

9736

85℃ 2min

EOLO 13*7

11.1

5

500

55.5

9.01

3654



8.4

750

93.24

8.04

4390

12.6

1000

139.86

7.15

5029

17.3

1250

192.03

6.51

5590

22.5

1500

249.75

6.01

6056

28.3

1750

314.13

5.57

6644

42.7

2290

473.97

4.83

7376

14.8

3.9

500

57.72

8.66

3570

6.7

750

99.16

7.56

4450

9.8

1000

145.04

6.89

4986

13.5

1250

199.8

6.26

5577

17.4

1500

257.52

5.82

6070

22.3

1750

330.04

5.30

6620

27.3

2000

404.04

4.95

6990

32.9

2250

486.92

4.62

7420

38.9

2500

575.72

4.34

7803

45.9

2750

679.32

4.05

8060

62

3400

917.6

3.71

8720

90℃ 1min

APC13*6.5

11.1

5.1

500

56.61

8.83

3952



8

750

88.8

8.45

4755

13.1

1000

145.41

6.88

5460

17.9

1250

198.69

6.29

6050

23.3

1500

258.63

5.80

6570

29.6

1750

328.56

5.33

7067

40.3

2150

447.33

4.81

7687

14.8

3.9

500

57.72

8.66

3897

6.7

750

99.16

7.56

4804

10.2

1000

150.96

6.62

5421

13.9

1250

205.72

6.08

6071

18.1

1500

267.88

5.60

6564

22.6

1750

334.48

5.23

7077

27.6

2000

408.48

4.90

7560

33.5

2250

495.8

4.54

8016

40.1

2500

593.48

4.21

8346

47

2750

695.6

3.95

8695

63.2

3300

935.36

3.53

9230

92℃ 1min

APC12*6

14.8

4.3

500

63.64

7.86

4510



7.2

750

106.56

7.04

5504

10.6

1000

156.88

6.37

6300

14.4

1250

213.12

5.87

7005

18.7

1500

276.76

5.42

7640

22.8

1750

337.44

5.19

8189

28

2000

414.4

4.83

8706

33

2250

488.4

4.61

9100

39.5

2500

584.6

4.28

9626

50.4

2769

745.92

3.71

10060

88℃ 2min

APC12*8

14.8

4.3

500

63.64

7.86

4167



7.5

750

111

6.76

5088

11.5

1000

170.2

5.88

5836

15.3

1250

226.44

5.52

6540

20

1500

296

5.07

7140

25.4

1750

375.92

4.66

7676

31.7

2000

469.16

4.26

8200

39.5

2250

584.6

3.85

8700

53.1

2500

785.88

3.18

9175

60

2750

888

3.10

9431

92℃ 2min








Specifications

X2820

Max Continuous Current

70A/30s

Stator Diameter

28mm

Max Continuous Power

1036W

Stator Thickness

20mm

Weight

147g

No.of Stator Slots

12

Rotor Diameter

35mm

No.of Rotor Poles

14

Body Length

42mm

Motor Kv

1000

Max Lipo Cell

3-4S

NO-Load Current(A/10V)

1.7A

ESC

60-80A

Motor Resistance

18.5mΩ

Recommend Prop(inch)

4S(APC11*5.5 APC11*8) 3S(EOLO12*6.5

EOLO13*7 APC12*6 13*6.5)


propeller（inch）

Voltage (V)

Amps (A)

Thrust(g)

Watts (W)

Efficiency (g/W)

RPM

Load temperature in 100% throttle

EOLO 12*6.5

11.1

5.7

500

63.27

7.90

4317



9.5

750

105.45

7.11

5214

13.8

1000

153.18

6.53

6086

18.8

1250

208.68

5.99

6715

24.3

1500

269.73

5.56

7271

30.8

1750

341.88

5.12

7875

38

2000

421.8

4.74

8358

47.4

2300

526.14

4.37

8846

85℃ 10min

APC11*5.5

14.8

4.7

500

69.56

7.19

5252



7.8

750

115.44

6.50

6510

11.4

1000

168.72

5.93

7498

15.5

1250

229.4

5.45

8279

19.6

1500

290.08

5.17

9010

25.3

1750

374.44

4.67

9668

30.5

2000

451.4

4.43

10247

35.9

2250

531.32

4.23

10896

42.8

2500

633.44

3.95

11310

53.4

2989

790.32

3.78

12300

88℃ 10min

APC11*8

14.8

4.8

500

71.04

7.04

4700



8.75

750

129.5

5.79

5788

12.7

1000

187.96

5.32

6637

17.1

1250

253.08

4.94

7490

22.9

1500

338.92

4.43

8058

28.6

1750

423.28

4.13

8720

35.2

2000

520.96

3.84

9302

43.4

2250

642.32

3.50

9733

68.8

2760

1018.24

2.71

10950

95℃ 5min

APC12*6

11.1

5.6

500

62.16

8.04

4520



9.5

750

105.45

7.11

5440

13.8

1000

153.18

6.53

6280

18.7

1250

207.57

6.02

7023

24.4

1500

270.84

5.54

7613

30.8

1750

341.88

5.12

8216

38.1

2000

422.91

4.73

8760

45.3

2290

502.83

4.55

9200

81℃ 10min
