X3520-III_SUNNYSKY-The most stable power system

Motor Model / KV	X3530-III/ KV220	X3530-III/ KV520	X3530-III/ KV650	X3530-III/ KV860
Stator/Rotor Poles	12N14P	12N14P	12N14P	12N14P
Internal resistance	92mΩ	19.7mΩ	11.3mΩ	7.3mΩ
Motor size	φ43.34*55mm	φ42.5*55mm	φ42.5*55mm	φ42.5*55mm
Shaft diameter	5.0mm	5.0mm	5.0mm	5.0mm
AWG	20AWG 110mm	20AWG 110mm	20AWG 110mm	20AWG 110mm
Motor weight(wire included)	307g	305g	305g	303g
Motor weight(wire excluded)	No data	No data	No data	No data
Rated operational voltage	6S	6S	5-6S	4S
No-load current	0.5A	1.6A/10V	2A/10V	3A/10V
Maximum continuous power	2300w	2250W	2310W	1800W
Maximum continuous current	46A/30s	90A/30s	110A/30s	120A/30s
ESC recommended use	80A	80-100A	80-120A	100-120A
Propeller size recommended use	EOLO 147 148 158 1510	6S (EOLO148/147/13*7)	6S (APC128/EOLO137) 5S(EOLO144/148)	EOLO147 148 13*7)

X3530-III

KV220 KV520 KV650 KV860

Specifications	X3530-III	Max Continuous Current	46A/30s
Stator Diameter	35mm	Max Continuous Power	2300W
Stator Thickness	30mm	Weight	307g
No.of Stator Slots	12	Rotor Diameter	55mm
No.of Rotor Poles	14	Body Length	43.34mm
Motor Kv	220	Max Lipo Cell	12S
NO-Load Current(A/10V)	0.5A	ESC	80A
Motor Resistance	92mΩ	Recommend Prop(inch)	EOLO 147 148 158 1510

Propeller (inch)	Voltage (V)	Current (A)	Thrust (g)	Watts (W)	Efficiency (g/W)	RPM	Load temperature in 100% throttle
EOLO 14*7	44.4	1.1	500	48.8	10.24	3188
		1.8	750	79.9	9.38	3920
		2.6	1000	115.4	8.66	4485
		3.5	1250	155.4	8.04	5008
		4.6	1500	204.2	7.34	5493
		5.7	1750	253.1	6.91	5873
		6.8	2000	301.9	6.62	6215
		8	2250	355.2	6.33	6618
		9.3	2500	412.9	6.05	6942
		12.1	3000	537.2	5.58	7580
		15.2	3500	674.9	5.19	8189
		18.6	4000	825.8	4.84	8674
		22.1	4500	981.2	4.59	9145
	50	1	500	50.0	10.00	3160
		1.7	750	85.0	8.82	3912
		2.4	1000	120.0	8.33	4489
		3.2	1250	160.0	7.81	5011
		4.1	1500	205.0	7.32	5478
		5	1750	250.0	7.00	5860
		6	2000	300.0	6.67	6211
		7.1	2250	355.0	6.34	6609
		8.3	2500	415.0	6.02	6937
		10.7	3000	535.0	5.61	7571
		13.5	3500	675.0	5.19	8172
		16.7	4000	835.0	4.79	8665
		19.9	4500	995.0	4.52	9183
		23.5	5000	1175.0	4.26	9655
		27.4	5550	1370.0	4.05	10072	10min 118℃
EOLO 14*8	44.4	1.2	500	53.3	9.38	3064
		1.9	750	84.4	8.89	3726
		2.7	1000	119.9	8.34	4257
		3.7	1250	164.3	7.61	4789
		4.8	1500	213.1	7.04	5226
		5.9	1750	262.0	6.68	5604
		7.1	2000	315.2	6.34	5986
		8.3	2250	368.5	6.11	6312
		9.7	2500	430.7	5.80	6651
		12.7	3000	563.9	5.32	7248
		16	3500	710.4	4.93	7765
		19.6	4000	870.2	4.60	8275
		25.7	4730	1141.1	4.15	8984
	50	1.1	500	55.0	9.09	3057
		1.7	750	85.0	8.82	3731
		2.5	1000	125.0	8.00	4250
		3.3	1250	165.0	7.58	4781
		4.3	1500	215.0	6.98	5218
		5.3	1750	265.0	6.60	5601
		6.4	2000	320.0	6.25	5976
		7.5	2250	375.0	6.00	6309
		8.7	2500	435.0	5.75	6642
		11.3	3000	565.0	5.31	7251
		14.4	3500	720.0	4.86	7760
		17.6	4000	880.0	4.55	8281
		21.2	4500	1060.0	4.25	8785
		26.2	5000	1310.0	3.82	9212
		32.8	5670	1640.0	3.46	9804	10min 125℃
EOLO 15*8	44.4	1.1	500	48.8	10.24	2802
		1.7	750	75.5	9.94	3405
		2.5	1000	111.0	9.01	3911
		3.4	1250	151.0	8.28	4330
		4.3	1500	190.9	7.86	4740
		5.3	1750	235.3	7.44	5096
		6.4	2000	284.2	7.04	5431
		7.5	2250	333.0	6.76	5742
		8.8	2500	390.7	6.40	6015
		11.4	3000	506.2	5.93	6551
		14.3	3500	634.9	5.51	7091
		17.4	4000	772.6	5.18	7516
		21	4500	932.4	4.83	7984
		24.7	5000	1096.7	4.56	8356
		29.8	5700	1323.1	4.31	8815
	50	1	500	50.0	10.00	2805
		1.6	750	80.0	9.38	3410
		2.3	1000	115.0	8.70	3915
		3	1250	150.0	8.33	4328
		3.9	1500	195.0	7.69	4733
		4.8	1750	240.0	7.29	5087
		5.7	2000	285.0	7.02	5425
		6.8	2250	340.0	6.62	5731
		7.9	2500	395.0	6.33	6008
		10.2	3000	510.0	5.88	6547
		12.8	3500	640.0	5.47	7088
		15.5	4000	775.0	5.16	7521
		18.9	4500	945.0	4.76	7988
		22.4	5000	1120.0	4.46	8350
		26	5500	1300.0	4.23	8749
		30.1	6000	1505.0	3.99	9047
		37.2	6900	1860.0	3.71	9682	2min30s 130℃
EOLO 15*10	44.4	1.1	500	48.8	10.24	2608
		1.8	750	79.9	9.38	3141
		2.6	1000	115.4	8.66	3612
		3.5	1250	155.4	8.04	4047
		4.6	1500	204.2	7.34	4421
		5.6	1750	248.6	7.04	4776
		6.9	2000	306.4	6.53	5076
		8.1	2250	359.6	6.26	5375
		9.5	2500	421.8	5.93	5657
		12.6	3000	559.4	5.36	6178
		16.1	3500	714.8	4.90	6675
		19.8	4000	879.1	4.55	7121
		24.4	4500	1083.4	4.15	7511
		30	5000	1332.0	3.75	7963
		37.5	5600	1665.0	3.36	8453
	50	1	500	50.0	10.00	2610
		1.7	750	85.0	8.82	3142
		2.4	1000	120.0	8.33	3608
		3.3	1250	165.0	7.58	4035
		4.2	1500	210.0	7.14	4417
		5.2	1750	260.0	6.73	4768
		6.4	2000	320.0	6.25	5082
		7.5	2250	375.0	6.00	5371
		8.8	2500	440.0	5.68	5660
		11.6	3000	580.0	5.17	6172
		14.7	3500	735.0	4.76	6684
		18.3	4000	915.0	4.37	7110
		22.5	4500	1125.0	4.00	7507
		27.9	5000	1395.0	3.58	7953
		34.1	5500	1705.0	3.23	8393
		40.7	6000	2035.0	2.95	8790
		46.5	6650	2325.0	2.86	9064	1min30s 135℃

Specifications	3530	Max Continuous Current	90A/30s
Stator Diameter	35mm	Max Continuous Power	2250W
Stator Thickness	30mm	Weight	305g
No.of Stator Slots	12	Rotor Diameter	42.5mm
No.of Rotor Poles	14	Body Length	55mm
MotorKv	520	MaxLipo Cell	6S
NO-Load Current(A/10V)	1.6A	ESC	80-100A
Motor Resistance	19.7mΩ	Recommend Prop(inch)	6S(EOLO148 147 13*7)

Propeller (inch)	Voltage (V)	Amps (A)	Thrust(g)	Watts (W)	Efficiency (g/W)	RPM	Load temperature in 100% throttle
EOLO 14*8	22.2	2.5	500	55.5	9.01	3063
		4.1	750	91.02	8.24	3742
		5.9	1000	130.98	7.63	4320
		7.8	1250	173.16	7.22	4830
		9.9	1500	219.78	6.83	5224
		12.2	1750	270.84	6.46	5650
		14.6	2000	324.12	6.17	5972
		17.1	2250	379.62	5.93	6405
		20.1	2500	446.22	5.60	6753
		23	2750	510.6	5.39	7052
		26	3000	577.2	5.20	7360
		33	3500	732.6	4.78	7880
		41	4000	910.2	4.39	8197
		67.8	5600	1505.16	3.72	9677
	25	2.3	500	57.5	8.70	3090
		3.7	750	92.5	8.11	3762
		5.4	1000	135	7.41	4277
		7	1250	175	7.14	4787
		8.9	1500	222.5	6.74	5245
		11.1	1750	277.5	6.31	5670
		13.2	2000	330	6.06	6168
		15.5	2250	387.5	5.81	6365
		18	2500	450	5.56	6505
		20.8	2750	520	5.29	6939
		23.5	3000	587.5	5.11	7372
		29.5	3500	737.5	4.75	7806
		36.5	4000	912.5	4.38	8385
		51	5000	1275	3.92	9190
		86	6666	2150	3.10	10582	125℃ 1min30s
EOLO 14*7	22.2	2.5	500	55.5	9.01	3223
		3.9	750	86.58	8.66	3950
		5.7	1000	126.54	7.90	4509
		7.6	1250	168.72	7.41	5002
		9.6	1500	213.12	7.04	5440
		11.8	1750	261.96	6.68	5830
		14.1	2000	313.02	6.39	6202
		16.5	2250	366.3	6.14	6554
		19.2	2500	426.24	5.87	6930
		22.1	2750	490.62	5.61	7222
		25	3000	555	5.41	7537
		31.6	3500	701.52	4.99	8060
		38.7	4000	859.14	4.66	8610
		60.6	5370	1345.32	3.99	9898
	25	2.2	500	55	9.09	3187
		3.6	750	90	8.33	3960
		5.1	1000	127.5	7.84	4443
		6.8	1250	170	7.35	4990
		8.6	1500	215	6.98	5422
		10.6	1750	265	6.60	5938
		12.8	2000	320	6.25	6267
		14.9	2250	372.5	6.04	6640
		17.3	2500	432.5	5.78	6987
		19.9	2750	497.5	5.53	7300
		22.5	3000	562.5	5.33	7565
		28.2	3500	705	4.96	8129
		34.6	4000	865	4.62	8630
		48.7	5000	1217.5	4.11	9455
		75.5	6510	1887.5	3.45	10704	117℃ 1min50s
EOLO 13*7	22.2	2.7	500	59.94	8.34	3594
		4.2	750	93.24	8.04	4345
		6.2	1000	137.64	7.27	5040
		8.3	1250	184.26	6.78	5526
		10.5	1500	233.1	6.44	6111
		13	1750	288.6	6.06	6605
		15.5	2000	344.1	5.81	7022
		18.2	2250	404.04	5.57	7412
		21.2	2500	470.64	5.31	7774
		24.3	2750	539.46	5.10	8222
		27.4	3000	608.28	4.93	8543
		34.8	3500	772.56	4.53	9157
		51.2	4500	1136.64	3.96	10208
	25	2.3	500	57.5	8.70	3600
		3.8	750	95	7.89	4414
		5.5	1000	137.5	7.27	5030
		7.5	1250	187.5	6.67	5640
		9.3	1500	232.5	6.45	6127
		11.5	1750	287.5	6.09	6605
		14	2000	350	5.71	7004
		16.3	2250	407.5	5.52	7512
		18.9	2500	472.5	5.29	7770
		21.6	2750	540	5.09	8150
		24.3	3000	607.5	4.94	8424
		30.6	3500	765	4.58	9151
		37.5	4000	937.5	4.27	9748
		65	5500	1625	3.38	11119	110℃ 10min

Specifications	3530	Max Continuous Current	110A/30s
Stator Diameter	35mm	Max Continuous Power	2310W
Stator Thickness	30mm	Weight	305g
No.of Stator Slots	12	Rotor Diameter	42.5mm
No.of Rotor Poles	14	Body Length	55mm
Motor Kv	668	Max Lipo Cell	5-6S
NO-Load Current(A/10V)	2A	ESC	80-120A
Motor Resistance	11.3mΩ	Recommend Prop(inch)	6S(128 EOLO137) 5S(EOLO147 148)

Propeller (inch)	Voltage (V)	Amps (A)	Thrust(g)	Watts (W)	Efficiency (g/W)	RPM	Load temperature in 100% throttle
APC12*8	22.2	3.1	500	68.82	7.27	4154
		5.2	750	115.44	6.50	4986
		7.5	1000	166.5	6.01	5782
		10	1250	222	5.63	6422
		12.9	1500	286.38	5.24	7035
		15.8	1750	350.76	4.99	7628
		19.9	2000	441.78	4.53	8119
		24.2	2250	537.24	4.19	8638
		31.4	2500	697.08	3.59	9355
		36.2	2750	803.64	3.42	9840
		44.2	3000	981.24	3.06	10264
		56.2	3500	1247.64	2.81	11034
		77.1	4240	1711.62	2.48	12179
	25	2.8	500	70	7.14	4230
		4.6	750	115	6.52	5127
		6.8	1000	170	5.88	6066
		9.1	1250	227.5	5.49	6510
		11.6	1500	290	5.17	7080
		14.5	1750	362.5	4.83	7604
		17.7	2000	442.5	4.52	8289
		22	2250	550	4.09	8640
		28.5	2500	712.5	3.51	9296
		33.2	2750	830	3.31	9780
		39.2	3000	980	3.06	10380
		50.4	3500	1260	2.78	11000
		63	4000	1575	2.54	11900
		78	4500	1950	2.31	12410
		96.1	5180	2402.5	2.16	13260	115℃ 50s
EOLO13*7	22.2	3.3	500	73.26	6.83	3759
		5.4	750	119.88	6.26	4500
		7.8	1000	173.16	5.78	5230
		10.4	1250	230.88	5.41	5760
		13.4	1500	297.48	5.04	6320
		16.5	1750	366.3	4.78	6708
		19.9	2000	441.78	4.53	7160
		23.4	2250	519.48	4.33	7585
		27.2	2500	603.84	4.14	7936
		31.4	2750	697.08	3.95	8376
		35.8	3000	794.76	3.77	8736
		45.9	3500	1018.98	3.43	9340
		62.1	4300	1378.62	3.12	10230
	25	2.9	500	72.5	6.90	3690
		4.9	750	122.5	6.12	4450
		7.1	1000	177.5	5.63	5162
		9.4	1250	235	5.32	5678
		12.1	1500	302.5	4.96	6173
		14.7	1750	367.5	4.76	6700
		17.8	2000	445	4.49	7224
		20.9	2250	522.5	4.31	7530
		24.1	2500	602.5	4.15	7950
		28.1	2750	702.5	3.91	8275
		31.4	3000	785	3.82	8544
		40	3500	1000	3.50	9270
		49.4	4000	1235	3.24	9990
		58.6	4500	1465	3.07	10400
		78	5280	1950	2.71	11264	127℃ 2min
EOLO 14*7	18.5	3	500	55.5	9.01	3320
		4.9	750	90.65	8.27	3940
		7.1	1000	131.35	7.61	4549
		9.6	1250	177.6	7.04	5080
		12.1	1500	223.85	6.70	5532
		15	1750	277.5	6.31	6020
		17.9	2000	331.15	6.04	6354
		21.2	2250	392.2	5.74	6822
		24.5	2500	453.25	5.52	7074
		28.1	2750	519.85	5.29	7527
		31.8	3000	588.3	5.10	7684
		40.3	3500	745.55	4.69	8280
		50	4000	925	4.32	8811
		59.2	4500	1095.2	4.11	9320
		72.5	5130	1341.25	3.82	9957
	21	2.7	500	56.7	8.82	3200
		4.4	750	92.4	8.12	3904
		6.3	1000	132.3	7.56	4426
		8.35	1250	175.35	7.13	4905
		10.6	1500	222.6	6.74	5419
		13.2	1750	277.2	6.31	5769
		15.8	2000	331.8	6.03	6212
		18.8	2250	394.8	5.70	6538
		21.8	2500	457.8	5.46	6804
		24.7	2750	518.7	5.30	7178
		28.3	3000	594.3	5.05	7513
		36	3500	756	4.63	8068
		44.4	4000	932.4	4.29	8533
		52.8	4500	1108.8	4.06	8969
		61.9	5000	1299.9	3.85	9480
		90.3	6320	1896.3	3.33	10545	125℃ 1min
EOLO 14*8	18.5	3.1	500	57.35	8.72	3115
		5.2	750	96.2	7.80	3844
		7.4	1000	136.9	7.30	4387
		9.8	1250	181.3	6.89	4938
		12.6	1500	233.1	6.44	5309
		15.6	1750	288.6	6.06	5810
		18.8	2000	347.8	5.75	6130
		21.9	2250	405.15	5.55	6526
		25.7	2500	475.45	5.26	6866
		29.7	2750	549.45	5.01	7149
		33.6	3000	621.6	4.83	7433
		42.8	3500	791.8	4.42	8079
		53	4000	980.5	4.08	8503
		63.3	4500	1171.05	3.84	9000
		80.8	5211	1494.8	3.49	9640
	21	2.7	500	56.7	8.82	3200
		4.5	750	94.5	7.94	3904
		6.5	1000	136.5	7.33	4426
		8.8	1250	184.8	6.76	4905
		11.2	1500	235.2	6.38	5419
		13.9	1750	291.9	6.00	5769
		16.8	2000	352.8	5.67	6212
		19.6	2250	411.6	5.47	6538
		22.9	2500	480.9	5.20	6804
		26.2	2750	550.2	5.00	7178
		29.7	3000	623.7	4.81	7513
		37.6	3500	789.6	4.43	8068
		47.3	4000	993.3	4.03	8533
		56.5	4500	1186.5	3.79	8969
		66.4	5000	1394.4	3.59	9480
		101.6	6280	2133.6	2.94	10545	110℃ 45s

Specifications	3530	Max Continuous Current	120A/30s
Stator Diameter	35mm	Max Continuous Power	1800W
Stator Thickness	30mm	Weight	303g
No.of Stator Slots	12	Rotor Diameter	42.5mm
No.of Rotor Poles	14	Body Length	55mm
Motor Kv	885	Max Lipo Cell	4S
NO-Load Current(A/10V)	3A	ESC	100-120A
Motor Resistance	7.3mΩ	Recommend Prop(inch)	EOLO147 148 13*7)

propeller（inch）	Voltage (V)	Current (A)	Input power (W)	Speed (rpm)	Thrust (g)	Force effect	Load temperature in 100% throttle
EOLO13*7	15.06	4.353	65.55	3648.57	492.72	7.51
	15.03	6.953	104.5	4470.19	733.48	7.01
	14.96	10.19	152.44	5170.6	1004.17	6.58
	14.86	13.541	201.21	5788.43	1257.02	6.24
	14.81	16.911	250.45	6276.93	1490.27	5.95
	14.73	20.532	302.43	6730.04	1721.22	5.69
	14.61	24.853	363.1	7143.49	1991.4	5.48
	14.52	28.958	420.47	7581.59	2201.75	5.23
	14.41	34.277	493.93	7957.14	2509.73	5.08
	14.27	40.167	573.18	8334.36	2769.89	4.83
	14.14	45.611	644.93	8685.82	3014.98	4.67
	13.84	58.266	806.4	9302.79	3489.48	4.32
	13.38	78.341	1048.2	10014.76	4198.48	4

	16.8	9.341	156.92	5162.13	1003.24	6.39
	16.72	12.916	215.95	5917.06	1291.12	5.97
	16.65	16.1	268.06	6414.59	1547.89	5.77
	16.57	19.887	329.52	6872.1	1815.4	5.5
	16.49	22.905	377.7	7283.69	2003.55	5.3
	16.39	27.088	443.97	7640.24	2249.83	5.06
	16.28	32.43	527.96	8013.99	2545.36	4.82
	16.09	40.856	657.37	8697.14	2963.69	4.5
	15.8	52.969	836.91	9340.43	3559.56	4.25
	15.51	64.942	1007.25	9979.38	4020.83	3.99
	14.81	92.197	1365.43	10851.75	4859.44	3.55	90℃ 1min27s
EOLO14*7	15.01	4.581	68.76	3207.89	542.65	7.89
	14.97	6.278	93.98	3722.62	718.61	7.64
	14.91	9.265	138.14	4498.1	988.4	7.15
	14.82	12.863	190.62	5152.11	1289.56	6.76
	14.73	16.471	242.61	5577.99	1554.69	6.4
	14.68	20.055	294.4	6046.31	1789.7	6.07
	14.58	23.631	344.53	6419.84	2022.98	5.87
	14.47	28.253	408.82	6791.09	2299.39	5.62
	14.36	33.306	478.27	7201.26	2594.57	5.42
	14.28	36.437	520.32	7367.46	2764.4	5.31
	14.19	40.577	575.78	7606.89	2963.24	5.14
	13.92	52.805	735.04	8194.5	3498.5	4.75
	13.64	64.023	873.27	8728.56	3932.88	4.5
	13.02	89.902	1170.52	9504.93	4810.07	4.1

	16.78	11.271	189.12	5035.04	1265.65	6.69
	16.72	14.18	237.08	5511.42	1502.23	6.33
	16.63	17.927	298.12	5996.4	1795.39	6.02
	16.57	20.451	338.87	6423.61	1979.71	5.84
	16.47	24.318	400.51	6527.15	2220.52	5.54
	16.4	27.519	451.31	6972.22	2458.76	5.44
	16.27	32.257	524.82	7300.33	2753.79	5.24
	16.17	36.791	594.91	7653.45	2989.51	5.02
	15.96	46.467	741.61	8185.68	3499.2	4.71
	15.69	57.946	909.17	8685.38	3993.87	4.39
	15.05	84.044	1264.86	9671.14	5009.26	3.96
	14.48	106.434	1541.16	10228.69	5699.88	3.69	70℃ 1min
EOLO14*8	14.63	4.389	64.21	3190.19	504.62	7.85
	14.59	7.154	104.37	3852.62	765.77	7.33
	14.49	9.985	144.68	4433.51	1010.8	6.98
	14.42	13.58	195.82	4974.92	1295.94	6.61
	14.36	16.96	243.54	5301.26	1524.77	6.26
	14.26	20.08	286.34	5599.82	1719.95	6
	14.16	24.951	353.3	6091.54	2027.1	5.73
	14.06	29.275	411.6	6496.8	2262.1	5.49
	13.93	34.467	480.12	6725.84	2543.79	5.29
	13.71	43.533	596.83	7344.11	2954.66	4.95
	13.37	58.094	776.71	8067.41	3574.96	4.6
	13.08	69.166	904.69	8433.62	3935.43	4.35
	12.53	92.594	1160.2	9029.84	4617.38	3.97

	16.79	11.171	187.56	4779.66	1232.25	6.56
	16.7	14.838	247.79	5277.91	1526.61	6.16
	16.63	17.852	296.87	5819.84	1752.62	5.9
	16.54	21.744	359.64	6119.38	2015.96	5.6
	16.43	26.438	434.37	6526.25	2332.92	5.37
	16.33	30.582	499.4	6855.85	2572.24	5.15
	16.22	34.56	560.56	7167.29	2807.84	5
	16.14	38.38	619.45	7427.56	2985.21	4.81
	15.89	49.168	781.27	7995.46	3548.81	4.54
	15.6	60.378	941.89	8404.44	4014.49	4.26
	14.31	112.88	1615.31	9737.76	5724.49	3.54	70℃ 45s

Products

MotorsMOTOR

ESCESC

PropellersPropeller

BatteryBattery

Model airplane accessoriesModel airplane accessories

News

About Us

Company Introduce

Development History

Core Advantages

Corporate Culture

Join Us

Qualification Honor

Anti-Fake

Service and Support

Data Download

Store Locator

After-Sales Service

Contact us

X3530-III
