This product is designed solely for use by RC model enthusiasts and for recreational purposes. It is
not intended for professional, military, commercial, or industrial applications.
This product is designed solely for use by RC model enthusiasts and for recreational purposes. It isnot intended for professional, military, commercial, or industrial applications.
| Motor Model / KV | V8117/KV90 | V8117/KV100 | V8117/KV120 |
|---|---|---|---|
| Stator/Rotor Poles | 36N40P | 36N40P | 36N40P |
| Internal resistance | 76mΩ | 61mΩ | 43mΩ |
| Motor size | Motor length: 35.5mm |
Motor length: 35.5mm |
Motor length: 35.5mm |
| Shaft diameter | 88.6mm | 88.6mm | 88.6mm |
| AWG | No data | No data | No data |
| Motor weight(wire included) | 470g | 461g | 468g |
| Motor weight(wire excluded) | No data | No data | No data |
| Rated operational voltage | 12s | 12s | 12s |
| No-load current | 0.7A | 0.9A | 1.1A |
| Maximum continuous power | 2064W | 2880W | 4080W |
| Maximum continuous current | 43A/30s | 60A/30s | 85A/30s |
| ESC recommended use | 60-80A | 60-80A | 60-80A |
| Propeller size recommended use | EOLO C27*9 C28*9.5 CN30*9.5 C30*10 | EOLO C27*9 C28*9.5 CN30*9.5 C30*10 | EOLO C27*9 C28*9.5 CN30*9.5 C30*10 |
Specifications | V8117 | Max Continuous Current | 43A/30s |
Stator Diameter | 81mm | Max Continuous Power | 2064W |
Stator Thickness | 17mm | Weight | 470g |
No.of Stator Slots | 36 | Rotor Diameter | 88.6mm |
No.of Rotor Poles | 40 | Body Length | 35.5mm |
Motor Kv | 90 | Max Lipo Cell | 12S |
NO-Load Current(A/10V) | 0.7A | ESC | 60-80A |
Motor Resistance | 76mΩ | Recommend Prop(inch) | EOLO C27*9 C28*9.5 CN30*9.5 C30*10 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO C27*9 | 44.4 | 4 | 2000 | 177.6 | 11.26 | 2077 |
|
5.3 | 2500 | 235.32 | 10.62 | 2319 | |||
6.7 | 3000 | 297.48 | 10.08 | 2524 | |||
8.3 | 3500 | 368.52 | 9.50 | 2701 | |||
10 | 4000 | 444 | 9.01 | 2895 | |||
13.8 | 5000 | 612.72 | 8.16 | 3261 | |||
19.4 | 6400 | 861.36 | 7.43 | 3633 | |||
48 | 3.8 | 2000 | 182.4 | 10.96 | 2058 | ||
5 | 2500 | 240 | 10.42 | 2301 | |||
6.3 | 3000 | 302.4 | 9.92 | 2533 | |||
7.8 | 3500 | 374.4 | 9.35 | 2733 | |||
9.4 | 4000 | 451.2 | 8.87 | 2898 | |||
12.8 | 5000 | 614.4 | 8.14 | 3258 | |||
16.8 | 6000 | 806.4 | 7.44 | 3546 | |||
22.2 | 7350 | 1065.6 | 6.90 | 3899 | 77℃ | ||
EOLO C28*9.5 | 44.4 | 3.9 | 2000 | 173.16 | 11.55 | 1815 |
|
5.2 | 2500 | 230.88 | 10.83 | 2031 | |||
6.8 | 3000 | 301.92 | 9.94 | 2221 | |||
8.3 | 3500 | 368.52 | 9.50 | 2395 | |||
9.9 | 4000 | 439.56 | 9.10 | 2591 | |||
13.7 | 5000 | 608.28 | 8.22 | 2882 | |||
17.8 | 6000 | 790.32 | 7.59 | 3125 | |||
22.4 | 7000 | 994.56 | 7.04 | 3380 | |||
26.4 | 7950 | 1172.16 | 6.78 | 3516 | |||
48 | 3.6 | 2000 | 172.8 | 11.57 | 1809 | ||
4.9 | 2500 | 235.2 | 10.63 | 2034 | |||
6.3 | 3000 | 302.4 | 9.92 | 2225 | |||
7.7 | 3500 | 369.6 | 9.47 | 2412 | |||
9.3 | 4000 | 446.4 | 8.96 | 2538 | |||
12.8 | 5000 | 614.4 | 8.14 | 2867 | |||
16.6 | 6000 | 796.8 | 7.53 | 3152 | |||
20.8 | 7000 | 998.4 | 7.01 | 3375 | |||
24.9 | 8000 | 1195.2 | 6.69 | 3583 | |||
29.8 | 9100 | 1430.4 | 6.36 | 3776 | 111℃ | ||
EOLO CN28*9.5 | 44.4 | 3.8 | 2000 | 168.72 | 11.85 | 1853 |
|
5.1 | 2500 | 226.44 | 11.04 | 2093 | |||
6.7 | 3000 | 297.48 | 10.08 | 2274 | |||
8.1 | 3500 | 359.64 | 9.73 | 2470 | |||
9.8 | 4000 | 435.12 | 9.19 | 2643 | |||
13.6 | 5000 | 603.84 | 8.28 | 2931 | |||
17.8 | 6000 | 790.32 | 7.59 | 3211 | |||
24.5 | 7600 | 1087.8 | 6.99 | 3559 | |||
48 | 3.6 | 2000 | 172.8 | 11.57 | 1893 | ||
4.9 | 2500 | 235.2 | 10.63 | 2108 | |||
6.2 | 3000 | 297.6 | 10.08 | 2287 | |||
7.7 | 3500 | 369.6 | 9.47 | 2450 | |||
9.3 | 4000 | 446.4 | 8.96 | 2647 | |||
12.7 | 5000 | 609.6 | 8.20 | 2946 | |||
16.2 | 6000 | 777.6 | 7.72 | 3229 | |||
20.4 | 7000 | 979.2 | 7.15 | 3461 | |||
27.8 | 8700 | 1334.4 | 6.52 | 3801 | 103℃ | ||
EOLO C30*10 | 44.4 | 3.6 | 2000 | 159.84 | 12.51 | 1517 |
|
4.8 | 2500 | 213.12 | 11.73 | 1719 | |||
6.2 | 3000 | 275.28 | 10.90 | 1854 | |||
7.6 | 3500 | 337.44 | 10.37 | 2003 | |||
9.1 | 4000 | 404.04 | 9.90 | 2130 | |||
12.7 | 5000 | 563.88 | 8.87 | 2384 | |||
16.6 | 6000 | 737.04 | 8.14 | 2598 | |||
21 | 7000 | 932.4 | 7.51 | 2785 | |||
25.4 | 8000 | 1127.76 | 7.09 | 2977 | |||
30.8 | 9000 | 1367.52 | 6.58 | 3175 | |||
37.2 | 10500 | 1651.68 | 6.36 | 3361 | |||
48 | 3.3 | 2000 | 158.4 | 12.63 | 1511 | ||
4.6 | 2500 | 220.8 | 11.32 | 1706 | |||
5.8 | 3000 | 278.4 | 10.78 | 1845 | |||
7.3 | 3500 | 350.4 | 9.99 | 1997 | |||
8.6 | 4000 | 412.8 | 9.69 | 2148 | |||
11.8 | 5000 | 566.4 | 8.83 | 2395 | |||
15.6 | 6000 | 748.8 | 8.01 | 2633 | |||
19.4 | 7000 | 931.2 | 7.52 | 2820 | |||
23.4 | 8000 | 1123.2 | 7.12 | 2996 | |||
27.3 | 9000 | 1310.4 | 6.87 | 3159 | |||
33.4 | 10000 | 1603.2 | 6.24 | 3338 | |||
42.4 | 11900 | 2035.2 | 5.85 | 3564 | 3min 10s 137℃ | ||
EOLO CN30*9.5 | 44.4 | 3.5 | 2000 | 155.4 | 12.87 | 1568 |
|
4.7 | 2500 | 208.68 | 11.98 | 1750 | |||
6 | 3000 | 266.4 | 11.26 | 1907 | |||
7.5 | 3500 | 333 | 10.51 | 2065 | |||
9.1 | 4000 | 404.04 | 9.90 | 2207 | |||
12.5 | 5000 | 555 | 9.01 | 2452 | |||
16.4 | 6000 | 728.16 | 8.24 | 2687 | |||
20.5 | 7000 | 910.2 | 7.69 | 2908 | |||
24.9 | 8000 | 1105.56 | 7.24 | 3103 | |||
30.1 | 9000 | 1336.44 | 6.73 | 3295 | |||
33.8 | 10000 | 1500.72 | 6.66 | 3398 | |||
48 | 3.2 | 2000 | 153.6 | 13.02 | 1568 | ||
4.4 | 2500 | 211.2 | 11.84 | 1770 | |||
5.6 | 3000 | 268.8 | 11.16 | 1925 | |||
7 | 3500 | 336 | 10.42 | 2068 | |||
8.5 | 4000 | 408 | 9.80 | 2190 | |||
11.6 | 5000 | 556.8 | 8.98 | 2451 | |||
15.3 | 6000 | 734.4 | 8.17 | 2700 | |||
18.9 | 7000 | 907.2 | 7.72 | 2914 | |||
23.1 | 8000 | 1108.8 | 7.22 | 3092 | |||
27.5 | 9000 | 1320 | 6.82 | 3267 | |||
32.4 | 10000 | 1555.2 | 6.43 | 3433 | |||
38.2 | 11500 | 1833.6 | 6.27 | 3616 | 3min 30s 135℃ |
Specifications | V8117 | Max Continuous Current | 60A/30s |
Stator Diameter | 81mm | Max Continuous Power | 2880W |
Stator Thickness | 17mm | Weight | 461g |
No.of Stator Slots | 36 | Rotor Diameter | 88.6mm |
No.of Rotor Poles | 40 | Body Length | 35.5mm |
Motor Kv | 100 | Max Lipo Cell | 12S |
NO-Load Current(A/10V) | 0.9A | ESC | 60-80A |
Motor Resistance | 61mΩ | Recommend Prop(inch) | EOLO C27*9 C28*9.5 CN30*9.5 C30*10 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO C27*9 | 44.4 | 4.2 | 2000 | 186.48 | 10.73 | 2094 |
|
7 | 3000 | 310.8 | 9.65 | 2567 | |||
10.4 | 4000 | 461.76 | 8.66 | 2930 | |||
14.1 | 5000 | 626.04 | 7.99 | 3259 | |||
18.5 | 6000 | 821.4 | 7.30 | 3544 | |||
28.1 | 8200 | 1247.64 | 6.57 | 4095 | |||
48 | 3.9 | 2000 | 187.2 | 10.68 | 2080 | ||
6.5 | 3000 | 312 | 9.62 | 2533 | |||
9.7 | 4000 | 465.6 | 8.59 | 2912 | |||
13.3 | 5000 | 638.4 | 7.83 | 3224 | |||
17.2 | 6000 | 825.6 | 7.27 | 3546 | |||
25.8 | 8000 | 1238.4 | 6.46 | 4067 | |||
31.1 | 9100 | 1492.8 | 6.10 | 4321 | 10min 87℃ | ||
EOLO C28*9.5 | 44.4 | 4 | 2000 | 177.6 | 11.26 | 1823 |
|
6.8 | 3000 | 301.92 | 9.94 | 2256 | |||
10.1 | 4000 | 448.44 | 8.92 | 2577 | |||
14 | 5000 | 621.6 | 8.04 | 2893 | |||
18.1 | 6000 | 803.64 | 7.47 | 3151 | |||
27.7 | 8000 | 1229.88 | 6.50 | 3604 | |||
36.5 | 9900 | 1620.6 | 6.11 | 3908 | |||
48 | 3.7 | 2000 | 177.6 | 11.26 | 1815 | ||
6.4 | 3000 | 307.2 | 9.77 | 2216 | |||
9.5 | 4000 | 456 | 8.77 | 2575 | |||
12.9 | 5000 | 619.2 | 8.07 | 2860 | |||
16.8 | 6000 | 806.4 | 7.44 | 3135 | |||
25.4 | 8000 | 1219.2 | 6.56 | 3595 | |||
35.5 | 10000 | 1704 | 5.87 | 4009 | |||
41.3 | 11300 | 1982.4 | 5.70 | 4171 | 10min 121℃ | ||
EOLO CN28*9.5 | 44.4 | 3.9 | 2000 | 173.16 | 11.55 | 1857 |
|
6.8 | 3000 | 301.92 | 9.94 | 2289 | |||
10.1 | 4000 | 448.44 | 8.92 | 2623 | |||
13.7 | 5000 | 608.28 | 8.22 | 2923 | |||
18.2 | 6000 | 808.08 | 7.43 | 3245 | |||
27.4 | 8000 | 1216.56 | 6.58 | 3699 | |||
33.7 | 9300 | 1496.28 | 6.22 | 3950 | |||
48 | 3.6 | 2000 | 172.8 | 11.57 | 1860 | ||
6.3 | 3000 | 302.4 | 9.92 | 2307 | |||
9.4 | 4000 | 451.2 | 8.87 | 2659 | |||
12.9 | 5000 | 619.2 | 8.07 | 2949 | |||
16.7 | 6000 | 801.6 | 7.49 | 3250 | |||
25.1 | 8000 | 1204.8 | 6.64 | 3708 | |||
38.2 | 10700 | 1833.6 | 5.84 | 4221 | 10min 115℃ | ||
EOLO C30*10 | 44.4 | 3.7 | 2000 | 164.28 | 12.17 | 1544 |
|
6.5 | 3000 | 288.6 | 10.40 | 1878 | |||
9.6 | 4000 | 426.24 | 9.38 | 2152 | |||
13.3 | 5000 | 590.52 | 8.47 | 2412 | |||
17.2 | 6000 | 763.68 | 7.86 | 2645 | |||
26.4 | 8000 | 1172.16 | 6.83 | 3026 | |||
37 | 10000 | 1642.8 | 6.09 | 3357 | |||
51.5 | 12800 | 2286.6 | 5.60 | 3684 | |||
48 | 3.4 | 2000 | 163.2 | 12.25 | 1556 | ||
5.9 | 3000 | 283.2 | 10.59 | 1861 | |||
8.9 | 4000 | 427.2 | 9.36 | 2138 | |||
12.3 | 5000 | 590.4 | 8.47 | 2416 | |||
15.9 | 6000 | 763.2 | 7.86 | 2640 | |||
24.3 | 8000 | 1166.4 | 6.86 | 3000 | |||
34.2 | 10000 | 1641.6 | 6.09 | 3334 | |||
45.5 | 12000 | 2184 | 5.49 | 3678 | |||
57.7 | 14600 | 2769.6 | 5.27 | 3938 | 7min 130℃ | ||
EOLO CN30*9.5 | 44.4 | 3.6 | 2000 | 159.84 | 12.51 | 1629 |
|
6.2 | 3000 | 275.28 | 10.90 | 1976 | |||
9.3 | 4000 | 412.92 | 9.69 | 2280 | |||
12.8 | 5000 | 568.32 | 8.80 | 2540 | |||
16.6 | 6000 | 737.04 | 8.14 | 2777 | |||
25.4 | 8000 | 1127.76 | 7.09 | 3200 | |||
35.6 | 10000 | 1580.64 | 6.33 | 3569 | |||
43.7 | 11700 | 1940.28 | 6.03 | 3788 | |||
48 | 3.3 | 2000 | 158.4 | 12.63 | 1622 | ||
5.8 | 3000 | 278.4 | 10.78 | 1960 | |||
8.7 | 4000 | 417.6 | 9.58 | 2289 | |||
11.8 | 5000 | 566.4 | 8.83 | 2552 | |||
15.4 | 6000 | 739.2 | 8.12 | 2791 | |||
23.6 | 8000 | 1132.8 | 7.06 | 3228 | |||
32.6 | 10000 | 1564.8 | 6.39 | 3605 | |||
43.3 | 12000 | 2078.4 | 5.77 | 3910 | |||
49.8 | 13400 | 2390.4 | 5.61 | 4037 | 8min 127℃ |
Specifications | V8117 | Max Continuous Current | 85A/30s |
Stator Diameter | 81mm | Max Continuous Power | 4080W |
Stator Thickness | 17mm | Weight | 468g |
No.of Stator Slots | 36 | Rotor Diameter | 88.6mm |
No.of Rotor Poles | 40 | Body Length | 35.5mm |
Motor Kv | 120 | Max Lipo Cell | 12S |
NO-Load Current(A/10V) | 1.1A | ESC | 60-80A |
Motor Resistance | 43mΩ | Recommend Prop(inch) | EOLO C27*9 C28*9.5 CN30*9.5 C30*10 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO C27*9 | 44.4 | 4.4 | 2000 | 195.36 | 10.24 | 2085 |
|
7.3 | 3000 | 324.12 | 9.26 | 2544 | |||
10.8 | 4000 | 479.52 | 8.34 | 2933 | |||
14.6 | 5000 | 648.24 | 7.71 | 3229 | |||
18.7 | 6000 | 830.28 | 7.23 | 3563 | |||
27.8 | 8000 | 1234.32 | 6.48 | 4050 | |||
40.8 | 10300 | 1811.52 | 5.69 | 4597 | |||
48 | 4.1 | 2000 | 196.8 | 10.16 | 2073 | ||
6.7 | 3000 | 321.6 | 9.33 | 2552 | |||
9.9 | 4000 | 475.2 | 8.42 | 2921 | |||
13.5 | 5000 | 648 | 7.72 | 3294 | |||
17.4 | 6000 | 835.2 | 7.18 | 3548 | |||
26.3 | 8000 | 1262.4 | 6.34 | 4054 | |||
36 | 10000 | 1728 | 5.79 | 4514 | |||
46.6 | 11900 | 2236.8 | 5.32 | 4900 | 10min 105℃ | ||
EOLO C28*9.5 | 44.4 | 4.1 | 2000 | 182.04 | 10.99 | 1815 |
|
7 | 3000 | 310.8 | 9.65 | 2201 | |||
10.2 | 4000 | 452.88 | 8.83 | 2538 | |||
14.1 | 5000 | 626.04 | 7.99 | 2811 | |||
18.2 | 6000 | 808.08 | 7.43 | 3098 | |||
27.8 | 8000 | 1234.32 | 6.48 | 3547 | |||
38.1 | 10000 | 1691.64 | 5.91 | 3987 | |||
54.3 | 12800 | 2410.92 | 5.31 | 4403 | |||
48 | 3.8 | 2000 | 182.4 | 10.96 | 1796 | ||
6.5 | 3000 | 312 | 9.62 | 2193 | |||
9.7 | 4000 | 465.6 | 8.59 | 2534 | |||
13 | 5000 | 624 | 8.01 | 2843 | |||
17.1 | 6000 | 820.8 | 7.31 | 3105 | |||
25.7 | 8000 | 1233.6 | 6.49 | 3583 | |||
35.5 | 10000 | 1704 | 5.87 | 4004 | |||
46.3 | 12000 | 2222.4 | 5.40 | 4327 | |||
61.6 | 14600 | 2956.8 | 4.94 | 4686 | 8min 125℃ | ||
EOLO CN28*9.5 | 44.4 | 4.1 | 2000 | 182.04 | 10.99 | 1878 |
|
7 | 3000 | 310.8 | 9.65 | 2255 | |||
10.2 | 4000 | 452.88 | 8.83 | 2618 | |||
13.9 | 5000 | 617.16 | 8.10 | 2917 | |||
18.1 | 6000 | 803.64 | 7.47 | 3223 | |||
27.6 | 8000 | 1225.44 | 6.53 | 3681 | |||
37.7 | 10000 | 1673.88 | 5.97 | 4101 | |||
50.3 | 12100 | 2233.32 | 5.42 | 4467 | |||
48 | 3.8 | 2000 | 182.4 | 10.96 | 1866 | ||
6.5 | 3000 | 312 | 9.62 | 2278 | |||
9.6 | 4000 | 460.8 | 8.68 | 2647 | |||
13 | 5000 | 624 | 8.01 | 2949 | |||
17 | 6000 | 816 | 7.35 | 3225 | |||
25.4 | 8000 | 1219.2 | 6.56 | 3691 | |||
35.2 | 10000 | 1689.6 | 5.92 | 4087 | |||
46.2 | 12000 | 2217.6 | 5.41 | 4488 | |||
56.4 | 13700 | 2707.2 | 5.06 | 4759 | 10min 130℃ | ||
EOLO C30*10 | 44.4 | 3.7 | 2000 | 164.28 | 12.17 | 1486 |
|
6.3 | 3000 | 279.72 | 10.73 | 1869 | |||
9.5 | 4000 | 421.8 | 9.48 | 2148 | |||
13 | 5000 | 577.2 | 8.66 | 2363 | |||
16.9 | 6000 | 750.36 | 8.00 | 2576 | |||
26.2 | 8000 | 1163.28 | 6.88 | 2958 | |||
36.8 | 10000 | 1633.92 | 6.12 | 3329 | |||
49.1 | 12000 | 2180.04 | 5.50 | 3632 | |||
61.5 | 14000 | 2730.6 | 5.13 | 3907 | |||
76.1 | 16200 | 3378.84 | 4.79 | 4136 | |||
48 | 3.4 | 2000 | 163.2 | 12.25 | 1518 | ||
5.9 | 3000 | 283.2 | 10.59 | 1850 | |||
8.8 | 4000 | 422.4 | 9.47 | 2123 | |||
12.1 | 5000 | 580.8 | 8.61 | 2352 | |||
15.8 | 6000 | 758.4 | 7.91 | 2594 | |||
24.2 | 8000 | 1161.6 | 6.89 | 2971 | |||
34.1 | 10000 | 1636.8 | 6.11 | 3309 | |||
45.2 | 12000 | 2169.6 | 5.53 | 3630 | |||
56.7 | 14000 | 2721.6 | 5.14 | 3896 | |||
71.6 | 16000 | 3436.8 | 4.66 | 4262 | |||
85 | 18200 | 4080 | 4.46 | 4420 | 6min 135℃ | ||
EOLO CN30*9.5 | 44.4 | 3.7 | 2000 | 164.28 | 12.17 | 1598 |
|
6.3 | 3000 | 279.72 | 10.73 | 1958 | |||
9.4 | 4000 | 417.36 | 9.58 | 2277 | |||
12.9 | 5000 | 572.76 | 8.73 | 2548 | |||
16.5 | 6000 | 732.6 | 8.19 | 2741 | |||
25.6 | 8000 | 1136.64 | 7.04 | 3186 | |||
35.8 | 10000 | 1589.52 | 6.29 | 3589 | |||
47.5 | 12000 | 2109 | 5.69 | 3917 | |||
65 | 14800 | 2886.00 | 5.13 | 4259 | |||
48 | 3.4 | 2000 | 163.2 | 12.25 | 1618 | ||
5.9 | 3000 | 283.2 | 10.59 | 1950 | |||
8.8 | 4000 | 422.4 | 9.47 | 2276 | |||
11.9 | 5000 | 571.2 | 8.75 | 2544 | |||
15.6 | 6000 | 748.8 | 8.01 | 2780 | |||
23.9 | 8000 | 1147.2 | 6.97 | 3213 | |||
33.3 | 10000 | 1598.4 | 6.26 | 3605 | |||
44.8 | 12000 | 2150.4 | 5.58 | 3916 | |||
56.4 | 14000 | 2707.2 | 5.17 | 4226 | |||
73 | 16800 | 3504 | 4.79 | 4554 | 7min 141℃ |
