| Motor Model / KV | V4010/KV375 |
|---|---|
| Stator/Rotor Poles | 18N24P |
| Internal resistance | 100mΩ |
| Motor size | Motor length: 26.5mm |
| Shaft diameter | 44.8mm |
| AWG | No data |
| Motor weight(wire included) | 115g |
| Motor weight(wire excluded) | No data |
| Rated operational voltage | 6s |
| No-load current | 0.5A |
| Maximum continuous power | 725W |
| Maximum continuous current | 29A/30s |
| ESC recommended use | 50A |
| Propeller size recommended use | EOLO12*5/13*5/15*5.5/16*6 |
Specifications | V4010 | Max Continuous Current | 29A/30s |
Stator Diameter | 40mm | Max Continuous Power | 725w |
Stator Thickness | 10mm | Weight | 115g |
No.of Stator Slots | 18 | Rotor Diameter | 44.8mm |
No.of Rotor Poles | 24 | Body Length | 26.5mm |
Motor Kv | 375 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 0.5A | ESC | 50A |
Motor Resistance | 100mΩ | Recommend Prop(inch) | EOLO12*5 13*5 15*5.5 16*6 |
|
Propeller (inch) |
Voltage (V) |
Current (A) |
Thrust (g) |
RPM |
Watts (W) |
Efficiency (G/W) |
Load temperature in 100% throttle |
|
EOLO CN12*5 |
22.2 |
0.9 |
200 |
2976 |
19.98 |
10.01 |
|
|
1.9 |
400 |
4100 |
42.18 |
9.48 |
|||
|
3.2 |
600 |
4918 |
71.04 |
8.45 |
|||
|
4.6 |
800 |
5656 |
102.12 |
7.83 |
|||
|
6.3 |
1000 |
6317 |
139.86 |
7.15 |
|||
|
7.1 |
1100 |
6629 |
157.62 |
6.98 |
|||
|
8.5 |
1260 |
6962 |
188.7 |
6.68 |
|||
|
25 |
0.8 |
200 |
2959 |
20 |
10.00 |
||
|
1.7 |
400 |
4092 |
42.5 |
9.41 |
|||
|
2.8 |
600 |
4902 |
70 |
8.57 |
|||
|
4.1 |
800 |
5626 |
102.5 |
7.80 |
|||
|
5.6 |
1000 |
6321 |
140 |
7.14 |
|||
|
6.4 |
1100 |
6660 |
160 |
6.88 |
|||
|
7.2 |
1200 |
6839 |
180 |
6.67 |
|||
|
8.9 |
1400 |
7360 |
222.5 |
6.29 |
|||
|
10.3 |
1550 |
7670 |
257.5 |
6.02 |
5min 103 ℃ |
||
|
EOLO CN13*5 |
22.2 |
0.6 |
200 |
2497 |
13.32 |
15.02 |
|
|
1.6 |
400 |
3480 |
35.52 |
11.26 |
|||
|
2.7 |
600 |
4276 |
59.94 |
10.01 |
|||
|
4 |
800 |
4908 |
88.8 |
9.01 |
|||
|
5.4 |
1000 |
5426 |
119.88 |
8.34 |
|||
|
6.2 |
1100 |
5726 |
137.64 |
7.99 |
|||
|
7.1 |
1200 |
5989 |
157.62 |
7.61 |
|||
|
8.9 |
1400 |
6384 |
197.58 |
7.09 |
|||
|
10.7 |
1600 |
6786 |
237.54 |
6.74 |
|||
|
25 |
0.6 |
200 |
2537 |
15 |
13.33 |
||
|
1.4 |
400 |
3493 |
35 |
11.43 |
|||
|
2.4 |
600 |
4281 |
60 |
10.00 |
|||
|
3.6 |
800 |
4925 |
90 |
8.89 |
|||
|
4.9 |
1000 |
5512 |
122.5 |
8.16 |
|||
|
5.7 |
1100 |
5690 |
142.5 |
7.72 |
|||
|
6.4 |
1200 |
5939 |
160 |
7.50 |
|||
|
7.9 |
1400 |
6405 |
197.5 |
7.09 |
|||
|
9.7 |
1600 |
6820 |
242.5 |
6.60 |
|||
|
12.9 |
1970 |
7453 |
322.5 |
6.11 |
3min 100 ℃ |
||
|
EOLO CN15*5.5 |
22.2 |
0.5 |
200 |
2019 |
11.1 |
18.02 |
|
|
1.4 |
400 |
2807 |
31.08 |
12.87 |
|||
|
2.3 |
600 |
3400 |
51.06 |
11.75 |
|||
|
3.6 |
800 |
3950 |
79.92 |
10.01 |
|||
|
4.9 |
1000 |
4440 |
108.78 |
9.19 |
|||
|
5.6 |
1100 |
4632 |
124.32 |
8.85 |
|||
|
6.3 |
1200 |
4851 |
139.86 |
8.58 |
|||
|
8 |
1400 |
5142 |
177.6 |
7.88 |
|||
|
9.9 |
1600 |
5510 |
219.78 |
7.28 |
|||
|
11.5 |
1800 |
5860 |
255.3 |
7.05 |
|||
|
15.3 |
2180 |
6324 |
339.66 |
6.42 |
|||
|
25 |
0.5 |
200 |
2008 |
12.5 |
16.00 |
||
|
1.2 |
400 |
2804 |
30 |
13.33 |
|||
|
2.1 |
600 |
3425 |
52.5 |
11.43 |
|||
|
3.2 |
800 |
3970 |
80 |
10.00 |
|||
|
4.4 |
1000 |
4413 |
110 |
9.09 |
|||
|
5 |
1100 |
4634 |
125 |
8.80 |
|||
|
5.7 |
1200 |
4816 |
142.5 |
8.42 |
|||
|
7.1 |
1400 |
5212 |
177.5 |
7.89 |
|||
|
8.7 |
1600 |
5505 |
217.5 |
7.36 |
|||
|
10.3 |
1800 |
5778 |
257.5 |
6.99 |
|||
|
12.1 |
2000 |
6147 |
302.5 |
6.61 |
|||
|
14.1 |
2200 |
6454 |
352.5 |
6.24 |
|||
|
16 |
2400 |
6660 |
400 |
6.00 |
|||
|
18.2 |
2640 |
6905 |
455 |
5.80 |
2min15s 125 ℃ |
||
|
EOLO CN16*6 |
22.2 |
0.5 |
200 |
1693 |
11.1 |
18.02 |
|
|
1.3 |
400 |
2283 |
28.86 |
13.86 |
|||
|
2.3 |
600 |
2735 |
51.06 |
11.75 |
|||
|
3.4 |
800 |
3107 |
75.48 |
10.60 |
|||
|
4.6 |
1000 |
3473 |
102.12 |
9.79 |
|||
|
5.3 |
1100 |
3636 |
117.66 |
9.35 |
|||
|
6 |
1200 |
3786 |
133.2 |
9.01 |
|||
|
7.5 |
1400 |
4084 |
166.5 |
8.41 |
|||
|
9.1 |
1600 |
4365 |
202.02 |
7.92 |
|||
|
11.1 |
1800 |
4584 |
246.42 |
7.30 |
|||
|
12.6 |
2000 |
4828 |
279.72 |
7.15 |
|||
|
15.3 |
2200 |
5052 |
339.66 |
6.48 |
|||
|
17.9 |
2400 |
5315 |
397.38 |
6.04 |
|||
|
19.7 |
2600 |
5505 |
437.34 |
5.95 |
|||
|
22.1 |
2770 |
5619 |
490.62 |
5.65 |
|||
|
25 |
0.4 |
200 |
1700 |
10 |
20.00 |
||
|
1.1 |
400 |
2275 |
27.5 |
14.55 |
|||
|
2.1 |
600 |
2730 |
52.5 |
11.43 |
|||
|
3 |
800 |
3102 |
75 |
10.67 |
|||
|
4.1 |
1000 |
3464 |
102.5 |
9.76 |
|||
|
4.6 |
1100 |
3607 |
115 |
9.57 |
|||
|
5.3 |
1200 |
3782 |
132.5 |
9.06 |
|||
|
6.8 |
1400 |
4107 |
170 |
8.24 |
|||
|
8.4 |
1600 |
4362 |
210 |
7.62 |
|||
|
10.1 |
1800 |
4660 |
252.5 |
7.13 |
|||
|
12 |
2000 |
4847 |
300 |
6.67 |
|||
|
14 |
2200 |
5110 |
350 |
6.29 |
|||
|
16.1 |
2400 |
5330 |
402.5 |
5.96 |
|||
|
18.5 |
2600 |
5506 |
462.5 |
5.62 |
|||
|
20.5 |
2800 |
5676 |
512.5 |
5.46 |
|||
|
23.6 |
3000 |
5895 |
590 |
5.08 |
|||
|
26 |
3240 |
6047 |
650 |
4.98 |
1min10s 135 ℃ |
||
|
EOLO CN17*6.2 |
22.2 |
0.4 |
200 |
1460 |
8.88 |
22.52 |
|
|
1.2 |
400 |
2112 |
26.64 |
15.02 |
|||
|
2.1 |
600 |
2500 |
46.62 |
12.87 |
|||
|
3.1 |
800 |
2900 |
68.82 |
11.62 |
|||
|
4.3 |
1000 |
3100 |
95.46 |
10.48 |
|||
|
5 |
1100 |
3260 |
111 |
9.91 |
|||
|
5.7 |
1200 |
3436 |
126.54 |
9.48 |
|||
|
7.3 |
1400 |
3700 |
162.06 |
8.64 |
|||
|
8.9 |
1600 |
4050 |
197.58 |
8.10 |
|||
|
10.8 |
1800 |
4180 |
239.76 |
7.51 |
|||
|
12.6 |
2000 |
4450 |
279.72 |
7.15 |
|||
|
15.2 |
2200 |
4686 |
337.44 |
6.52 |
|||
|
17.2 |
2400 |
4890 |
381.84 |
6.29 |
|||
|
19.9 |
2600 |
5020 |
441.78 |
5.89 |
|||
|
22.6 |
2800 |
5200 |
501.72 |
5.58 |
|||
|
25.4 |
3030 |
5510 |
563.88 |
5.37 |
|||
|
25 |
0.4 |
200 |
1460 |
10 |
20.00 |
||
|
1.1 |
400 |
2100 |
27.5 |
14.55 |
|||
|
1.8 |
600 |
2480 |
45 |
13.33 |
|||
|
2.8 |
800 |
2886 |
70 |
11.43 |
|||
|
3.9 |
1000 |
3090 |
97.5 |
10.26 |
|||
|
4.5 |
1100 |
3280 |
112.5 |
9.78 |
|||
|
5.1 |
1200 |
3438 |
127.5 |
9.41 |
|||
|
6.5 |
1400 |
3680 |
162.5 |
8.62 |
|||
|
8.1 |
1600 |
4040 |
202.5 |
7.90 |
|||
|
9.7 |
1800 |
4190 |
242.5 |
7.42 |
|||
|
11.4 |
2000 |
4440 |
285 |
7.02 |
|||
|
13.4 |
2200 |
4680 |
335 |
6.57 |
|||
|
15.7 |
2400 |
4849 |
392.5 |
6.11 |
|||
|
17.6 |
2600 |
5070 |
440 |
5.91 |
|||
|
20.2 |
2800 |
5220 |
505 |
5.54 |
|||
|
23.3 |
3000 |
5390 |
582.5 |
5.15 |
|||
|
29.3 |
3600 |
5746 |
732.5 |
4.91 |
50s 140 ℃ |
