| Motor Model / KV | M8 V2/KV85 | M8 V2/KV90 | M8 V2/KV100 | M8 V2/KV115 | M8 V2/KV135 | M8 V2/KV150 | M8 V2/KV190 |
|---|---|---|---|---|---|---|---|
| Stator/Rotor Poles | 36N42P | 36N42P | 36N42P | 36N42P | 36N42P | 36N42P | 36N42P |
| Internal resistance | 168mΩ | 149mΩ | 138mΩ | 106mΩ | 76mΩ | 63mΩ | 42mΩ |
| Motor size | Motor length: 31mm |
Motor length: 31mm | Motor length: 31mm | Motor length: 31mm | Motor length: 31mm | Motor length: 31mm | Motor length: 31mm |
| Shaft diameter | 87mm | 87mm | 87mm | 87mm | 87mm | 87mm | 87mm |
| AWG | No data | No data | No data | No data | No data | No data | No data |
| Motor weight(wire included) | 283g | 283g | 283g | 283g | 283g | 283g | 283g |
| Motor weight(wire excluded) | No data | No data | No data | No data | No data | No data | No data |
| Rated operational voltage | 12S | 12s | 12s | 8-12s | 6-8s | No data | 6s |
| No-load current | 0.42V | 0.38A | 0.41A | 0.5A | 0.6A | 0.69A | 0.95A |
| Maximum continuous power | 1248W | 1440W | 1680W | 974.4W | 1414W | 850W | 1450W |
| Maximum continuous current | 26A/30s | 30A/30s | 35A/30s | 29A/30s | 42A/30s | 34A/30s | 58A/30s |
| ESC recommended use | 40A | 40A | 40A | 40A | 40-60A | 40A | 60-80A |
| Propeller size recommended use | EOLO27*9 28*9.5 28*9.5 | EOLO27*9 28*9.5 28*9.5 | EOLO27*9 28*9.5 28*9.5 | EOLO27*9 28*9.5 28*9.5 | EOLO27*9 28*9.5 28*9.5 | EOLO27*9 28*9.5 28*9.5 | EOLO27*9 28*9.5 28*9.5 |
Specifications | 8108 | Max Continuous Current | 26A/30s |
Stator Diameter | 81mm | Max Continuous Power | 1248W |
Stator Thickness | 8mm | Weight | 283g |
No.of Stator Slots | 36 | Rotor Diameter | 87mm |
No.of Rotor Poles | 42 | Body Length | 31mm |
Motor Kv | 85 | Max Lipo Cell | 12S |
NO-Load Current(A/10V) | 0.42A | ESC | 40A |
Motor Resistance | 168mΩ | Recommend Prop(inch) | EOLO27*9 28*9.5 28*9.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
C27*9 | 44.4 | 1.5 | 1000 | 66.6 | 15.02 | 1462 |
|
2.5 | 1500 | 111.0 | 13.51 | 1797 | |||
3.7 | 2000 | 164.3 | 12.17 | 2073 | |||
5 | 2500 | 222.0 | 11.26 | 2334 | |||
6.6 | 3000 | 293.0 | 10.24 | 2530 | |||
8.3 | 3500 | 368.5 | 9.50 | 2734 | |||
10.2 | 4000 | 452.9 | 8.83 | 2915 | |||
17.3 | 5700 | 768.1 | 7.42 | 3474 | |||
48 | 1.4 | 1000 | 67.2 | 14.88 | 1471 | ||
2.3 | 1500 | 110.4 | 13.59 | 1789 | |||
3.5 | 2000 | 168.0 | 11.90 | 2072 | |||
4.7 | 2500 | 225.6 | 11.08 | 2303 | |||
6.2 | 3000 | 297.6 | 10.08 | 2546 | |||
7.8 | 3500 | 374.4 | 9.35 | 2728 | |||
9.4 | 4000 | 451.2 | 8.87 | 2922 | |||
13.1 | 5000 | 628.8 | 7.95 | 3251 | |||
19.6 | 6550 | 940.8 | 6.96 | 3695 | 101℃ | ||
CN27*9 | 44.4 | 1.4 | 1000 | 62.2 | 16.09 | 1322 |
|
2.4 | 1500 | 106.6 | 14.08 | 1617 | |||
3.6 | 2000 | 159.8 | 12.51 | 1890 | |||
4.9 | 2500 | 217.6 | 11.49 | 2120 | |||
6.4 | 3000 | 284.2 | 10.56 | 2284 | |||
8.1 | 3500 | 359.6 | 9.73 | 2472 | |||
9.9 | 4000 | 439.6 | 9.10 | 2645 | |||
13.8 | 5000 | 612.7 | 8.16 | 2952 | |||
21 | 6600 | 932.4 | 7.08 | 3342 | |||
48 | 1.3 | 1000 | 62.4 | 16.03 | 1339 | ||
2.2 | 1500 | 105.6 | 14.20 | 1627 | |||
3.4 | 2000 | 163.2 | 12.25 | 1902 | |||
4.7 | 2500 | 225.6 | 11.08 | 2112 | |||
6.1 | 3000 | 292.8 | 10.25 | 2307 | |||
7.7 | 3500 | 369.6 | 9.47 | 2473 | |||
9.3 | 4000 | 446.4 | 8.96 | 2677 | |||
13 | 5000 | 624.0 | 8.01 | 2980 | |||
17.3 | 6000 | 830.4 | 7.23 | 3292 | |||
23.7 | 7450 | 1137.6 | 6.55 | 3551 | 5min 10s 125℃ | ||
C28*9.5 | 44.4 | 1.4 | 1000 | 62.2 | 16.09 | 1280 |
|
2.4 | 1500 | 115.2 | 13.02 | 1578 | |||
3.6 | 2000 | 172.8 | 11.57 | 1812 | |||
5 | 2500 | 240.0 | 10.42 | 2041 | |||
6.5 | 3000 | 312.0 | 9.62 | 2235 | |||
8.3 | 3500 | 398.4 | 8.79 | 2406 | |||
10.1 | 4000 | 484.8 | 8.25 | 2557 | |||
14.1 | 5000 | 676.8 | 7.39 | 2904 | |||
22.6 | 6800 | 1084.8 | 6.27 | 3301 | |||
48 | 1.3 | 1000 | 62.4 | 16.03 | 1288 | ||
2.3 | 1500 | 110.4 | 13.59 | 1585 | |||
3.4 | 2000 | 163.2 | 12.25 | 1831 | |||
4.7 | 2500 | 225.6 | 11.08 | 2030 | |||
6.1 | 3000 | 292.8 | 10.25 | 2232 | |||
7.7 | 3500 | 369.6 | 9.47 | 2419 | |||
9.4 | 4000 | 451.2 | 8.87 | 2578 | |||
12.9 | 5000 | 619.2 | 8.07 | 2897 | |||
17.5 | 6000 | 840.0 | 7.14 | 3166 | |||
25.6 | 7700 | 1228.8 | 6.27 | 3511 | 3min 30s 150℃ |
Specifications | 8108 | Max Continuous Current | 30A/30s |
Stator Diameter | 81mm | Max Continuous Power | 1440W |
Stator Thickness | 8mm | Weight | 283g |
No.of Stator Slots | 36 | Rotor Diameter | 87mm |
No.of Rotor Poles | 42 | Body Length | 31mm |
Motor Kv | 90 | Max Lipo Cell | 12S |
NO-Load Current(A/10V) | 0.38A | ESC | 40A |
Motor Resistance | 149mΩ | Recommend Prop(inch) | EOLO27*9 28*9.5 28*9.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
C27*9 | 44.4 | 1.5 | 1000 | 66.6 | 15.02 | 1480 |
|
2.6 | 1500 | 115.4 | 12.99 | 1789 | |||
3.8 | 2000 | 168.7 | 11.85 | 2075 | |||
5.1 | 2500 | 226.4 | 11.04 | 2317 | |||
6.7 | 3000 | 297.5 | 10.08 | 2530 | |||
8.5 | 3500 | 377.4 | 9.27 | 2756 | |||
10.3 | 4000 | 457.3 | 8.75 | 2938 | |||
14.3 | 5000 | 634.9 | 7.88 | 3256 | |||
20.3 | 6340 | 901.3 | 7.03 | 3639 | |||
48 | 1.4 | 1000 | 67.2 | 14.88 | 1487 | ||
2.4 | 1500 | 115.2 | 13.02 | 1806 | |||
3.5 | 2000 | 168.0 | 11.90 | 2082 | |||
4.7 | 2500 | 225.6 | 11.08 | 2302 | |||
6.2 | 3000 | 297.6 | 10.08 | 2533 | |||
7.8 | 3500 | 374.4 | 9.35 | 2743 | |||
9.3 | 4000 | 446.4 | 8.96 | 2910 | |||
13.1 | 5000 | 628.8 | 7.95 | 3246 | |||
17.5 | 6000 | 840.0 | 7.14 | 3548 | |||
22.7 | 7100 | 1089.6 | 6.52 | 3851 | 5min 115℃ | ||
CN28*9.5 | 44.4 | 1.5 | 1000 | 66.6 | 15.02 | 1337 |
|
2.5 | 1500 | 111.0 | 13.51 | 1627 | |||
3.7 | 2000 | 164.3 | 12.17 | 1871 | |||
5 | 2500 | 222.0 | 11.26 | 2089 | |||
6.5 | 3000 | 288.6 | 10.40 | 2303 | |||
8.3 | 3500 | 368.5 | 9.50 | 2477 | |||
10.1 | 4000 | 448.4 | 8.92 | 2632 | |||
14 | 5000 | 621.6 | 8.04 | 2943 | |||
18.6 | 6000 | 825.8 | 7.27 | 3223 | |||
24.7 | 7250 | 1096.7 | 6.61 | 3472 | |||
48 | 1.4 | 1000 | 67.2 | 14.88 | 1322 | ||
2.3 | 1500 | 110.4 | 13.59 | 1618 | |||
3.4 | 2000 | 163.2 | 12.25 | 1869 | |||
4.7 | 2500 | 225.6 | 11.08 | 2095 | |||
6.1 | 3000 | 292.8 | 10.25 | 2318 | |||
7.7 | 3500 | 369.6 | 9.47 | 2479 | |||
9.4 | 4000 | 451.2 | 8.87 | 2640 | |||
13.2 | 5000 | 633.6 | 7.89 | 2976 | |||
17.6 | 6000 | 844.8 | 7.10 | 3225 | |||
22.3 | 7000 | 1070.4 | 6.54 | 3461 | |||
28.1 | 8300 | 1348.8 | 6.15 | 3712 | 2min 30s 140℃ | ||
C28*9.5 | 44.4 | 1.4 | 1000 | 62.2 | 16.09 | 1280 |
|
2.4 | 1500 | 106.6 | 14.08 | 1557 | |||
3.6 | 2000 | 159.8 | 12.51 | 1783 | |||
5 | 2500 | 222.0 | 11.26 | 2005 | |||
6.5 | 3000 | 288.6 | 10.40 | 2212 | |||
8.3 | 3500 | 368.5 | 9.50 | 2389 | |||
10 | 4000 | 444.0 | 9.01 | 2516 | |||
14.1 | 5000 | 626.0 | 7.99 | 2829 | |||
18.7 | 6000 | 830.3 | 7.23 | 3106 | |||
26.7 | 7580 | 1185.5 | 6.39 | 3421 | |||
48 | 1.3 | 1000 | 62.4 | 16.03 | 1278 | ||
2.3 | 1500 | 110.4 | 13.59 | 1562 | |||
3.4 | 2000 | 163.2 | 12.25 | 1805 | |||
4.7 | 2500 | 225.6 | 11.08 | 2037 | |||
6.1 | 3000 | 292.8 | 10.25 | 2242 | |||
7.7 | 3500 | 369.6 | 9.47 | 2397 | |||
9.3 | 4000 | 446.4 | 8.96 | 2553 | |||
13.1 | 5000 | 628.8 | 7.95 | 2834 | |||
17.4 | 6000 | 835.2 | 7.18 | 3113 | |||
22.3 | 7000 | 1070.4 | 6.54 | 3342 | |||
29.7 | 8500 | 1425.6 | 5.96 | 3657 | 2min 141℃ |
Specifications | 8108 | Max Continuous Current | 35A/30s |
Stator Diameter | 81mm | Max Continuous Power | 1680W |
Stator Thickness | 8mm | Weight | 283g |
No.of Stator Slots | 36 | Rotor Diameter | 87mm |
No.of Rotor Poles | 42 | Body Length | 31mm |
Motor Kv | 100 | Max Lipo Cell | 12S |
NO-Load Current(A/10V) | 0.41A | ESC | 40A |
Motor Resistance | 138mΩ | Recommend Prop(inch) | EOLO27*9 28*9.5 28*9.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
C27*9 | 44.4 | 1.5 | 1000 | 66.6 | 15.02 | 1458 |
|
2.6 | 1500 | 115.4 | 12.99 | 1785 | |||
3.8 | 2000 | 168.7 | 11.85 | 2080 | |||
5.2 | 2500 | 230.9 | 10.83 | 2308 | |||
6.7 | 3000 | 297.5 | 10.08 | 2518 | |||
8.4 | 3500 | 373.0 | 9.38 | 2723 | |||
10.3 | 4000 | 457.3 | 8.75 | 2919 | |||
14.3 | 5000 | 634.9 | 7.88 | 3275 | |||
19 | 6000 | 843.6 | 7.11 | 3533 | |||
23.6 | 6950 | 1047.8 | 6.63 | 3778 | |||
48 | 1.4 | 1000 | 67.2 | 14.88 | 1466 | ||
2.4 | 1500 | 115.2 | 13.02 | 1788 | |||
3.5 | 2000 | 168.0 | 11.90 | 2062 | |||
4.8 | 2500 | 230.4 | 10.85 | 2310 | |||
6.2 | 3000 | 297.6 | 10.08 | 2524 | |||
7.8 | 3500 | 374.4 | 9.35 | 2701 | |||
9.5 | 4000 | 456.0 | 8.77 | 2896 | |||
13.4 | 5000 | 643.2 | 7.77 | 3237 | |||
17.7 | 6000 | 849.6 | 7.06 | 3537 | |||
22.2 | 7000 | 1065.6 | 6.57 | 3819 | |||
26.4 | 7900 | 1267.2 | 6.23 | 4021 | 3min30s 140℃ | ||
CN28*9.5 | 44.4 | 1.4 | 1000 | 62.2 | 16.09 | 1320 |
|
2.4 | 1500 | 106.6 | 14.08 | 1610 | |||
3.7 | 2000 | 164.3 | 12.17 | 1851 | |||
5 | 2500 | 222.0 | 11.26 | 2090 | |||
6.6 | 3000 | 293.0 | 10.24 | 2298 | |||
8.3 | 3500 | 368.5 | 9.50 | 2460 | |||
10.1 | 4000 | 448.4 | 8.92 | 2639 | |||
13.9 | 5000 | 617.2 | 8.10 | 2922 | |||
18.7 | 6000 | 830.3 | 7.23 | 3192 | |||
24.1 | 7000 | 1070.0 | 6.54 | 3431 | |||
29 | 8000 | 1287.6 | 6.21 | 3615 | |||
48 | 1.3 | 1000 | 62.4 | 16.03 | 1325 | ||
2.2 | 1500 | 105.6 | 14.20 | 1603 | |||
3.4 | 2000 | 163.2 | 12.25 | 1856 | |||
4.7 | 2500 | 225.6 | 11.08 | 2084 | |||
6.1 | 3000 | 292.8 | 10.25 | 2293 | |||
7.6 | 3500 | 364.8 | 9.59 | 2476 | |||
9.3 | 4000 | 446.4 | 8.96 | 2656 | |||
13.1 | 5000 | 628.8 | 7.95 | 2972 | |||
17.7 | 6000 | 849.6 | 7.06 | 3213 | |||
22.7 | 7000 | 1089.6 | 6.42 | 3460 | |||
28.5 | 8000 | 1368.0 | 5.85 | 3710 | |||
32.7 | 9000 | 1569.6 | 5.73 | 3878 | 2min 150℃ | ||
C28*9.5 | 44.4 | 1.4 | 1000 | 62.2 | 16.09 | 1287 |
|
2.4 | 1500 | 106.6 | 14.08 | 1561 | |||
3.7 | 2000 | 164.3 | 12.17 | 1819 | |||
5.1 | 2500 | 226.4 | 11.04 | 2054 | |||
6.7 | 3000 | 297.5 | 10.08 | 2268 | |||
8.4 | 3500 | 373.0 | 9.38 | 2413 | |||
10.3 | 4000 | 457.3 | 8.75 | 2590 | |||
14.3 | 5000 | 634.9 | 7.88 | 2865 | |||
19 | 6000 | 843.6 | 7.11 | 3146 | |||
24.6 | 7000 | 1092.2 | 6.41 | 3339 | |||
30.8 | 8250 | 1367.5 | 6.03 | 3589 | |||
48 | 1.3 | 1000 | 62.4 | 16.03 | 1284 | ||
2.3 | 1500 | 110.4 | 13.59 | 1562 | |||
3.5 | 2000 | 168.0 | 11.90 | 1810 | |||
4.8 | 2500 | 230.4 | 10.85 | 2027 | |||
6.2 | 3000 | 297.6 | 10.08 | 2241 | |||
7.7 | 3500 | 369.6 | 9.47 | 2423 | |||
9.6 | 4000 | 460.8 | 8.68 | 2583 | |||
13.3 | 5000 | 638.4 | 7.83 | 2856 | |||
17.7 | 6000 | 849.6 | 7.06 | 3127 | |||
22.7 | 7000 | 1089.6 | 6.42 | 3349 | |||
28.5 | 8000 | 1368.0 | 5.85 | 3580 | |||
34.7 | 9280 | 1665.6 | 5.57 | 3821 | 1min 20s 150℃ |
Specifications | 8108 | Max Continuous Current | 29A/30s |
Stator Diameter | 81mm | Max Continuous Power | 974.4W |
Stator Thickness | 8mm | Weight | 283g |
No.of Stator Slots | 36 | Rotor Diameter | 87mm |
No.of Rotor Poles | 42 | Body Length | 31mm |
Motor Kv | 115 | Max Lipo Cell | 8-12S |
NO-Load Current(A/10V) | 0.5A | ESC | 40A |
Motor Resistance | 106mΩ | Recommend Prop(inch) | EOLO27*9 28*9.5 28*9.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
C27*9 | 29.6 | 2.2 | 1000 | 65.12 | 15.36 | 1487 |
|
3.7 | 1500 | 109.52 | 13.70 | 1798 | |||
5.5 | 2000 | 162.80 | 12.29 | 2075 | |||
7.7 | 2500 | 227.92 | 10.97 | 2312 | |||
10 | 3000 | 296.00 | 10.14 | 2547 | |||
12.6 | 3500 | 372.96 | 9.38 | 2729 | |||
17.7 | 4400 | 523.92 | 8.40 | 3050 | |||
33.6 | 2 | 1000 | 67.20 | 14.88 | 1473 | ||
3.3 | 1500 | 110.88 | 13.53 | 1809 | |||
5 | 2000 | 168.00 | 11.90 | 2085 | |||
6.8 | 2500 | 228.48 | 10.94 | 2300 | |||
8.9 | 3000 | 299.04 | 10.03 | 2520 | |||
11.1 | 3500 | 372.96 | 9.38 | 2736 | |||
13.6 | 4000 | 456.96 | 8.75 | 2913 | |||
21.4 | 5400 | 719.04 | 7.51 | 3376 | 8min 141℃ | ||
CN28*9.5 | 29.6 | 2 | 1000 | 59.20 | 16.89 | 1317 |
|
3.6 | 1500 | 106.56 | 14.08 | 1615 | |||
5.4 | 2000 | 159.84 | 12.51 | 1880 | |||
7.4 | 2500 | 219.04 | 11.41 | 2073 | |||
9.7 | 3000 | 287.12 | 10.45 | 2290 | |||
12.2 | 3500 | 361.12 | 9.69 | 2458 | |||
15 | 4000 | 444.00 | 9.01 | 2642 | |||
21.6 | 5100 | 639.36 | 7.98 | 2942 | |||
33.6 | 1.8 | 1000 | 60.48 | 16.53 | 1342 | ||
3.2 | 1500 | 107.52 | 13.95 | 1601 | |||
4.8 | 2000 | 161.28 | 12.40 | 1881 | |||
6.7 | 2500 | 225.12 | 11.11 | 2075 | |||
8.6 | 3000 | 288.96 | 10.38 | 2284 | |||
10.8 | 3500 | 362.88 | 9.65 | 2457 | |||
13.5 | 4000 | 453.60 | 8.82 | 2645 | |||
18.9 | 5000 | 635.04 | 7.87 | 2956 | |||
26 | 6200 | 873.60 | 7.10 | 3255 | 6min 145℃ | ||
C28*9.5 | 29.6 | 2.1 | 1000 | 62.16 | 16.09 | 1290 |
|
3.6 | 1500 | 106.56 | 14.08 | 1593 | |||
5.5 | 2000 | 162.80 | 12.29 | 1818 | |||
7.6 | 2500 | 224.96 | 11.11 | 2034 | |||
9.9 | 3000 | 293.04 | 10.24 | 2228 | |||
12.5 | 3500 | 370.00 | 9.46 | 2396 | |||
15.3 | 4000 | 452.88 | 8.83 | 2563 | |||
23 | 5300 | 680.80 | 7.78 | 2893 | |||
33 | 1.9 | 1000 | 63.84 | 15.66 | 1292 | ||
3.3 | 1500 | 110.88 | 13.53 | 1581 | |||
4.9 | 2000 | 164.64 | 12.15 | 1810 | |||
6.7 | 2500 | 225.12 | 11.11 | 2031 | |||
8.8 | 3000 | 295.68 | 10.15 | 2218 | |||
11.2 | 3500 | 376.32 | 9.30 | 2397 | |||
13.4 | 4000 | 450.24 | 8.88 | 2579 | |||
18.9 | 5000 | 635.04 | 7.87 | 2877 | |||
28.1 | 6480 | 944.16 | 6.86 | 3186 | 5min 150℃ |
Specifications | 8108 | Max Continuous Current | 42A/30s |
Stator Diameter | 81mm | Max Continuous Power | 1414W |
Stator Thickness | 8mm | Weight | 283g |
No.of Stator Slots | 36 | Rotor Diameter | 87mm |
No.of Rotor Poles | 42 | Body Length | 31mm |
Motor Kv | 135 | Max Lipo Cell | 6-8S |
NO-Load Current(A/10V) | 0.6A | ESC | 40-60A |
Motor Resistance | 76mΩ | Recommend Prop(inch) | EOLO27*9 28*9.5 28*9.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
C27*9 | 29.6 | 2.3 | 1000 | 68.08 | 14.69 | 1466 |
|
3.9 | 1500 | 115.44 | 12.99 | 1784 | |||
5.7 | 2000 | 168.72 | 11.85 | 2082 | |||
7.9 | 2500 | 233.84 | 10.69 | 2301 | |||
10.2 | 3000 | 301.92 | 9.94 | 2545 | |||
12.9 | 3500 | 381.84 | 9.17 | 2698 | |||
15.6 | 4000 | 461.76 | 8.66 | 2895 | |||
28.1 | 5800 | 831.76 | 6.97 | 3460 | |||
33.6 | 2.1 | 1000 | 70.56 | 14.17 | 1468 | ||
3.5 | 1500 | 117.60 | 12.76 | 1805 | |||
5.2 | 2000 | 174.72 | 11.45 | 2068 | |||
7.1 | 2500 | 238.56 | 10.48 | 2318 | |||
9.1 | 3000 | 305.76 | 9.81 | 2530 | |||
11.5 | 3500 | 386.40 | 9.06 | 2732 | |||
14 | 4000 | 470.40 | 8.50 | 2907 | |||
19.5 | 5000 | 655.20 | 7.63 | 3252 | |||
25.7 | 6000 | 863.52 | 6.95 | 3559 | |||
33.2 | 7000 | 1115.52 | 6.28 | 3809 | 7min 13s 135℃ | ||
CN28*9.5 | 29.6 | 2.2 | 1000 | 65.12 | 15.36 | 1318 |
|
3.7 | 1500 | 109.52 | 13.70 | 1609 | |||
5.6 | 2000 | 165.76 | 12.07 | 1888 | |||
7.6 | 2500 | 224.96 | 11.11 | 2098 | |||
10.1 | 3000 | 298.96 | 10.03 | 2287 | |||
12.6 | 3500 | 372.96 | 9.38 | 2459 | |||
15.7 | 4000 | 464.72 | 8.61 | 2681 | |||
21.8 | 5000 | 645.28 | 7.75 | 2970 | |||
32.6 | 6400 | 964.96 | 6.63 | 3303 | |||
33.6 | 1.9 | 1000 | 63.84 | 15.66 | 1312 | ||
3.3 | 1500 | 110.88 | 13.53 | 1605 | |||
4.9 | 2000 | 164.64 | 12.15 | 1862 | |||
6.8 | 2500 | 228.48 | 10.94 | 2094 | |||
8.9 | 3000 | 299.04 | 10.03 | 2272 | |||
11.4 | 3500 | 383.04 | 9.14 | 2468 | |||
13.8 | 4000 | 463.68 | 8.63 | 2644 | |||
19.3 | 5000 | 648.48 | 7.71 | 2961 | |||
26.2 | 6000 | 880.32 | 6.82 | 3240 | |||
39.6 | 7980 | 1330.56 | 6.00 | 3619 | 1min 45S 150℃ | ||
C28*9.5 | 29.6 | 2.2 | 1000 | 65.12 | 15.36 | 1279 |
|
3.8 | 1500 | 112.48 | 13.34 | 1570 | |||
5.6 | 2000 | 165.76 | 12.07 | 1822 | |||
7.8 | 2500 | 230.88 | 10.83 | 2042 | |||
10.2 | 3000 | 301.92 | 9.94 | 2213 | |||
12.8 | 3500 | 378.88 | 9.24 | 2382 | |||
15.6 | 4000 | 461.76 | 8.66 | 2564 | |||
22.1 | 5000 | 654.16 | 7.64 | 2870 | |||
34.9 | 6800 | 1033.04 | 6.58 | 3250 | |||
33.6 | 2 | 1000 | 67.20 | 14.88 | 1265 | ||
3.4 | 1500 | 114.24 | 13.13 | 1573 | |||
5.1 | 2000 | 171.36 | 11.67 | 1798 | |||
7 | 2500 | 235.20 | 10.63 | 2024 | |||
9 | 3000 | 302.40 | 9.92 | 2234 | |||
11.5 | 3500 | 386.40 | 9.06 | 2379 | |||
14 | 4000 | 470.40 | 8.50 | 2556 | |||
19.6 | 5000 | 658.56 | 7.59 | 2886 | |||
26.4 | 6000 | 887.04 | 6.76 | 3154 | |||
33.8 | 7000 | 1135.68 | 6.16 | 3386 | |||
42 | 8200 | 1411.20 | 5.81 | 3592 | 1min30s 150℃ |
Specifications | 8108 | Max Continuous Current | 34A/30s |
Stator Diameter | 81mm | Max Continuous Power | 850W |
Stator Thickness | 8mm | Weight | 283g |
No.of Stator Slots | 36 | Rotor Diameter | 87mm |
No.of Rotor Poles | 42 | Body Length | 31mm |
Motor Kv | 150 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 0.69A | ESC | 40A |
Motor Resistance | 63mΩ | Recommend Prop(inch) | EOLO27*9 28*9.5 28*9.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
C27*9 | 22.2 | 3.2 | 1000 | 71.04 | 14.08 | 1455 |
|
5.2 | 1500 | 115.44 | 12.99 | 1789 | |||
7.6 | 2000 | 168.72 | 11.85 | 2060 | |||
10.5 | 2500 | 233.10 | 10.73 | 2295 | |||
13.8 | 3000 | 306.36 | 9.79 | 2512 | |||
17.3 | 3500 | 384.06 | 9.11 | 2716 | |||
21.9 | 4100 | 486.18 | 8.43 | 2932 | |||
25 | 2.8 | 1000 | 70.00 | 14.29 | 1471 | ||
4.7 | 1500 | 117.50 | 12.77 | 1781 | |||
7 | 2000 | 175.00 | 11.43 | 2077 | |||
9.4 | 2500 | 235.00 | 10.64 | 2294 | |||
12.2 | 3000 | 305.00 | 9.84 | 2528 | |||
15.3 | 3500 | 382.50 | 9.15 | 2709 | |||
18.9 | 4000 | 472.50 | 8.47 | 2916 | |||
26.2 | 5000 | 655.00 | 7.63 | 3225 | 81℃ | ||
CN28*9.5 | 22.2 | 3 | 1000 | 66.60 | 15.02 | 1337 |
|
5.1 | 1500 | 113.22 | 13.25 | 1597 | |||
7.5 | 2000 | 166.50 | 12.01 | 1850 | |||
10.3 | 2500 | 228.66 | 10.93 | 2084 | |||
13.6 | 3000 | 301.92 | 9.94 | 2285 | |||
17.1 | 3500 | 379.62 | 9.22 | 2453 | |||
26.7 | 4720 | 592.74 | 7.96 | 2823 | |||
25 | 2.6 | 1000 | 65.00 | 15.38 | 1335 | ||
4.5 | 1500 | 112.50 | 13.33 | 1606 | |||
6.6 | 2000 | 165.00 | 12.12 | 1878 | |||
9.2 | 2500 | 230.00 | 10.87 | 2087 | |||
12.1 | 3000 | 302.50 | 9.92 | 2284 | |||
15.1 | 3500 | 377.50 | 9.27 | 2461 | |||
18.7 | 4000 | 467.50 | 8.56 | 2650 | |||
31.8 | 5700 | 795.00 | 7.17 | 3098 | 105℃ | ||
C28*9.5 | 22.2 | 3 | 1000 | 66.60 | 15.02 | 1288 |
|
5.1 | 1500 | 113.22 | 13.25 | 1560 | |||
7.6 | 2000 | 168.72 | 11.85 | 1811 | |||
10.5 | 2500 | 233.10 | 10.73 | 2003 | |||
13.6 | 3000 | 301.92 | 9.94 | 2213 | |||
17.1 | 3500 | 379.62 | 9.22 | 2380 | |||
21.2 | 4000 | 470.64 | 8.50 | 2549 | |||
28.3 | 4910 | 628.26 | 7.82 | 2776 | |||
25 | 2.7 | 1000 | 67.50 | 14.81 | 1273 | ||
4.6 | 1500 | 115.00 | 13.04 | 1568 | |||
6.9 | 2000 | 172.50 | 11.59 | 1795 | |||
9.3 | 2500 | 232.50 | 10.75 | 2011 | |||
12.3 | 3000 | 307.50 | 9.76 | 2228 | |||
15.4 | 3500 | 385.00 | 9.09 | 2401 | |||
18.9 | 4000 | 472.50 | 8.47 | 2573 | |||
26.3 | 5000 | 657.50 | 7.60 | 2845 | |||
33.4 | 5900 | 835.00 | 7.07 | 3042 | 110℃ |
Specifications | 8108 | Max Continuous Current | 58A/30s |
Stator Diameter | 81mm | Max Continuous Power | 1450W |
Stator Thickness | 8mm | Weight | 283g |
No.of Stator Slots | 36 | Rotor Diameter | 87mm |
No.of Rotor Poles | 42 | Body Length | 31mm |
Motor Kv | 190 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 0.95A | ESC | 60-80A |
Motor Resistance | 42mΩ | Recommend Prop(inch) | EOLO27*9 28*9.5 28*9.5 |
|
Propeller (inch) |
Voltage (V) |
Current (A) |
Thrust (g) |
Watts (W) |
Efficiency (g/W) |
RPM |
Load temperature in 100% throttle |
|
C27*9 |
22.2 |
3 |
1000 |
66.60 |
15.02 |
1446 |
|
|
5.1 |
1500 |
113.22 |
13.25 |
1764 |
|||
|
7.6 |
2000 |
168.72 |
11.85 |
2042 |
|||
|
10.4 |
2500 |
230.88 |
10.83 |
2286 |
|||
|
13.5 |
3000 |
299.70 |
10.01 |
2490 |
|||
|
16.9 |
3500 |
375.18 |
9.33 |
2682 |
|||
|
20.7 |
4000 |
459.54 |
8.70 |
2867 |
|||
|
29.4 |
5000 |
652.68 |
7.66 |
3206 |
|||
|
38.2 |
6000 |
848.04 |
7.08 |
3485 |
|||
|
25 |
2.8 |
1000 |
70.00 |
14.29 |
1477 |
||
|
4.7 |
1500 |
117.50 |
12.77 |
1780 |
|||
|
6.9 |
2000 |
172.50 |
11.59 |
2066 |
|||
|
9.4 |
2500 |
235.00 |
10.64 |
2299 |
|||
|
11.9 |
3000 |
297.50 |
10.08 |
2511 |
|||
|
15.1 |
3500 |
377.50 |
9.27 |
2684 |
|||
|
18.5 |
4000 |
462.50 |
8.65 |
2917 |
|||
|
26 |
5000 |
650.00 |
7.69 |
3201 |
|||
|
35.1 |
6000 |
877.50 |
6.84 |
3509 |
|||
|
45.4 |
7100 |
1135.00 |
6.26 |
3817 |
5min 141℃ |
||
|
CN28*9.5 |
22.2 |
2.9 |
1000 |
64.38 |
15.53 |
1320 |
|
|
5 |
1500 |
111.00 |
13.51 |
1621 |
|||
|
7.5 |
2000 |
166.50 |
12.01 |
1869 |
|||
|
10.3 |
2500 |
228.66 |
10.93 |
2102 |
|||
|
13.5 |
3000 |
299.70 |
10.01 |
2280 |
|||
|
17.2 |
3500 |
381.84 |
9.17 |
2488 |
|||
|
21.1 |
4000 |
468.42 |
8.54 |
2651 |
|||
|
30.1 |
5000 |
668.22 |
7.48 |
3004 |
|||
|
45.8 |
6600 |
1016.76 |
6.49 |
3327 |
|||
|
25 |
2.6 |
1000 |
65.00 |
15.38 |
1340 |
||
|
4.5 |
1500 |
112.50 |
13.33 |
1637 |
|||
|
6.7 |
2000 |
167.50 |
11.94 |
1889 |
|||
|
9.3 |
2500 |
232.50 |
10.75 |
2088 |
|||
|
12.2 |
3000 |
305.00 |
9.84 |
2292 |
|||
|
15.5 |
3500 |
387.50 |
9.03 |
2508 |
|||
|
18.7 |
4000 |
467.50 |
8.56 |
2648 |
|||
|
27 |
5000 |
675.00 |
7.41 |
2989 |
|||
|
36.4 |
6000 |
910.00 |
6.59 |
3270 |
|||
|
54.5 |
7800 |
1362.50 |
5.72 |
3636 |
2min 50s 145℃ |
||
|
C28*9.5 |
22.2 |
2.9 |
1000 |
64.38 |
15.53 |
1302 |
|
|
5 |
1500 |
111.00 |
13.51 |
1576 |
|||
|
7.7 |
2000 |
170.94 |
11.70 |
1845 |
|||
|
10.5 |
2500 |
233.10 |
10.73 |
2043 |
|||
|
13.7 |
3000 |
304.14 |
9.86 |
2252 |
|||
|
17.5 |
3500 |
388.50 |
9.01 |
2413 |
|||
|
21.4 |
4000 |
475.08 |
8.42 |
2574 |
|||
|
30.5 |
5000 |
677.10 |
7.38 |
2862 |
|||
|
48.4 |
6850 |
1074.48 |
6.38 |
3278 |
|||
|
25 |
2.6 |
1000 |
65.00 |
15.38 |
1327 |
||
|
4.6 |
1500 |
115.00 |
13.04 |
1582 |
|||
|
6.9 |
2000 |
172.50 |
11.59 |
1832 |
|||
|
9.5 |
2500 |
237.50 |
10.53 |
2039 |
|||
|
12.3 |
3000 |
307.50 |
9.76 |
2247 |
|||
|
15.7 |
3500 |
392.50 |
8.92 |
2423 |
|||
|
19.1 |
4000 |
477.50 |
8.38 |
2563 |
|||
|
27.2 |
5000 |
680.00 |
7.35 |
2878 |
|||
|
36.8 |
6000 |
920.00 |
6.52 |
3147 |
|||
|
48.1 |
7000 |
1202.50 |
5.82 |
3393 |
|||
|
57.2 |
8000 |
1430.00 |
5.59 |
3570 |
2min 40s 150℃ |
