| Motor Model / KV | 4006/ KV380 |
|---|---|
| Stator/Rotor Poles | 18N24P |
| Internal resistance | 164mΩ |
| Motor size | Motor length：18mm |
| Shaft diameter | 3.175mm |
| AWG | 20AWG 100mm |
| Motor weight(wire included) | 134g |
| Motor weight(wire excluded) | No data |
| Rated operational voltage | 3-4S |
| No-load current | 0.6A |
| Maximum continuous power | 425w |
| Maximum continuous current | 17A/30s |
| ESC recommended use | 40A |
| Propeller size recommended use | EOLO 15*5.5 |
Specifications | 4006 | Max Continuous Current | 17A/30s |
Stator Diameter | 40mm | Max Continuous Power | 425w |
Stator Thickness | 6mm | Weight | 134g |
No.of Stator Slots | 18 | Rotor Diameter | 43.6mm |
No.of Rotor Poles | 24 | Body Length | 18mm |
Motor Kv | 380 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 0.6A | ESC | 40A |
Motor Resistance | 164mΩ | Recommend Prop(inch) | EOLO 15*5.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO CN15*5.5 | 22.2 | 0.6 | 200 | 13.32 | 15.02 | 1962 |
|
1.4 | 400 | 31.08 | 12.87 | 2750 | |||
2.5 | 600 | 55.5 | 10.81 | 3359 | |||
3.8 | 800 | 84.36 | 9.48 | 3873 | |||
5.2 | 1000 | 115.44 | 8.66 | 4295 | |||
6.9 | 1200 | 153.18 | 7.83 | 4640 | |||
8.7 | 1400 | 193.14 | 7.25 | 5021 | |||
10.6 | 1600 | 235.32 | 6.80 | 5339 | |||
13.4 | 1850 | 297.48 | 6.22 | 5707 | |||
25 | 0.6 | 200 | 15 | 13.33 | 1948 | ||
1.3 | 400 | 32.5 | 12.31 | 2770 | |||
2.3 | 600 | 57.5 | 10.43 | 3365 | |||
3.4 | 800 | 85 | 9.41 | 3830 | |||
4.7 | 1000 | 117.5 | 8.51 | 4281 | |||
6.1 | 1200 | 152.5 | 7.87 | 4636 | |||
7.7 | 1400 | 192.5 | 7.27 | 5024 | |||
9.6 | 1600 | 240 | 6.67 | 5343 | |||
11.6 | 1800 | 290 | 6.21 | 5616 | |||
13.7 | 2000 | 342.5 | 5.84 | 5877 | |||
16.1 | 2220 | 402.5 | 5.52 | 6173 | 91℃ |
