| Motor Model / KV | 4006/ KV740 |
|---|---|
| Stator/Rotor Poles | 18N24P |
| Internal resistance | 50mΩ |
| Motor size | Motor length：18mm |
| Shaft diameter | 3.175mm |
| AWG | 20AWG 100mm |
| Motor weight(wire included) | 134g |
| Motor weight(wire excluded) | No data |
| Rated operational voltage | 3-6S |
| No-load current | 1.0A |
| Maximum continuous power | 640w |
| Maximum continuous current | 38A/30s |
| ESC recommended use | 40A |
| Propeller size recommended use | EOLO CN15*5.5 |
Specifications | 4006 | Max Continuous Current | 38A/30s |
Stator Diameter | 40mm | Max Continuous Power | 640w |
Stator Thickness | 6mm | Weight | 134g |
No.of Stator Slots | 18 | Rotor Diameter | 43.6mm |
No.of Rotor Poles | 24 | Body Length | 18mm |
Motor Kv | 740 | Max Lipo Cell | 4S |
NO-Load Current(A/10V) | 1.0A | ESC | 40A |
Motor Resistance | 50mΩ | Recommend Prop(inch) | EOLO CN15*5.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO CN15*5.5 | 14.8 | 0.9 | 200 | 13.32 | 15.02 | 1951 |
|
2.2 | 400 | 32.56 | 12.29 | 2733 | |||
3.9 | 600 | 57.72 | 10.40 | 3334 | |||
5.9 | 800 | 87.32 | 9.16 | 3857 | |||
8.2 | 1000 | 121.36 | 8.24 | 4297 | |||
10.9 | 1200 | 161.32 | 7.44 | 4660 | |||
14.1 | 1400 | 208.68 | 6.71 | 5023 | |||
17.8 | 1600 | 263.44 | 6.07 | 5315 | |||
22.4 | 1800 | 331.52 | 5.43 | 5623 | |||
27 | 2000 | 399.6 | 5.01 | 5931 | |||
33.4 | 2300 | 494.32 | 4.65 | 6236 | |||
16.8 | 0.8 | 200 | 13.44 | 14.88 | 1962 | ||
2 | 400 | 33.6 | 11.90 | 2752 | |||
3.4 | 600 | 57.12 | 10.50 | 3336 | |||
5.2 | 800 | 87.36 | 9.16 | 3837 | |||
7.3 | 1000 | 122.64 | 8.15 | 4261 | |||
9.7 | 1200 | 162.96 | 7.36 | 4659 | |||
12.5 | 1400 | 210 | 6.67 | 5014 | |||
15.9 | 1600 | 267.12 | 5.99 | 5317 | |||
19.7 | 1800 | 330.96 | 5.44 | 5630 | |||
23.5 | 2000 | 394.8 | 5.07 | 5913 | |||
30.3 | 2250 | 509.04 | 4.42 | 6218 | |||
37.3 | 2460 | 626.64 | 3.93 | 6392 | 2min 140℃ |
