| Motor Model / KV | 4010/ KV375 |
|---|---|
| Stator/Rotor Poles | 18N24P |
| Internal resistance | 94mΩ |
| Motor size | Motor length：29.5mm |
| Shaft diameter | 3.175mm |
| AWG | 20AWG 100mm |
| Motor weight(wire included) | 154g |
| Motor weight(wire excluded) | No data |
| Rated operational voltage | 3-6S |
| No-load current | 0.7A |
| Maximum continuous power | 725w |
| Maximum continuous current | 29A/30s |
| ESC recommended use | 40A |
| Propeller size recommended use | EOLO CN16*6 |
Specifications | 4010 | Max Continuous Current | 29A/30s |
Stator Diameter | 40mm | Max Continuous Power | 725w |
Stator Thickness | 10mm | Weight | 173g |
No.of Stator Slots | 18 | Rotor Diameter | 44.7mm |
No.of Rotor Poles | 24 | Body Length | 29.5mm |
Motor Kv | 375 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 0.7A | ESC | 40A |
Motor Resistance | 94mΩ | Recommend Prop(inch) | EOLO CN16*6 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO CN16*6 | 22.2 | 1.9 | 500 | 42.18 | 11.85 | 2386 |
|
3.3 | 750 | 73.26 | 10.24 | 2927 | |||
4.9 | 1000 | 108.78 | 9.19 | 3374 | |||
6.7 | 1250 | 148.74 | 8.40 | 3751 | |||
8.8 | 1500 | 195.36 | 7.68 | 4078 | |||
11.2 | 1750 | 248.64 | 7.04 | 4385 | |||
13.9 | 2000 | 308.58 | 6.48 | 4680 | |||
16.5 | 2250 | 366.3 | 6.14 | 4944 | |||
19.7 | 2500 | 437.34 | 5.72 | 5217 | |||
23.3 | 2800 | 517.26 | 5.41 | 5469 | |||
25 | 1.7 | 500 | 42.5 | 11.76 | 2395 | ||
2.8 | 750 | 70 | 10.71 | 2916 | |||
4.2 | 1000 | 105 | 9.52 | 3370 | |||
5.9 | 1250 | 147.5 | 8.47 | 3725 | |||
7.7 | 1500 | 192.5 | 7.79 | 4081 | |||
9.8 | 1750 | 245 | 7.14 | 4380 | |||
12.2 | 2000 | 305 | 6.56 | 4690 | |||
14.9 | 2250 | 372.5 | 6.04 | 4963 | |||
17.8 | 2500 | 445 | 5.62 | 5248 | |||
23.8 | 3000 | 595 | 5.04 | 5750 | |||
28 | 3350 | 700 | 4.79 | 5979 | 112℃ |
