| Motor Model / KV | 4008/ KV380 |
|---|---|
| Stator/Rotor Poles | 18N24P |
| Internal resistance | 114mΩ |
| Motor size | Motor length：20mm |
| Shaft diameter | 3.175mm |
| AWG | 20AWG 100mm |
| Motor weight(wire included) | 154g |
| Motor weight(wire excluded) | No data |
| Rated operational voltage | 3-4S |
| No-load current | 0.6A |
| Maximum continuous power | 500w |
| Maximum continuous current | 20A/30s |
| ESC recommended use | 40A |
| Propeller size recommended use | EOLO CN15*5.5 |
Specifications | 4008 | Max Continuous Current | 20A/30s |
Stator Diameter | 40mm | Max Continuous Power | 500w |
Stator Thickness | 8mm | Weight | 154g |
No.of Stator Slots | 18 | Rotor Diameter | 44.3mm |
No.of Rotor Poles | 24 | Body Length | 20mm |
Motor Kv | 380 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 0.6A | ESC | 40A |
Motor Resistance | 114mΩ | Recommend Prop(inch) | EOLO CN15*5.5 |
Propeller (inch) | Voltage (V) | Current (A) | Thrust (g) | Watts (W) | Efficiency (g/W) | RPM | Load temperature in 100% throttle |
EOLO CN15*5.5 | 22.2 | 0.6 | 200 | 13.32 | 15.02 | 1950 |
|
1.4 | 400 | 31.08 | 12.87 | 2768 | |||
2.5 | 600 | 55.5 | 10.81 | 3384 | |||
3.7 | 800 | 82.14 | 9.74 | 3882 | |||
5.1 | 1000 | 113.22 | 8.83 | 4310 | |||
6.7 | 1200 | 148.74 | 8.07 | 4664 | |||
8.4 | 1400 | 186.48 | 7.51 | 5017 | |||
10.2 | 1600 | 226.44 | 7.07 | 5322 | |||
12.3 | 1800 | 273.06 | 6.59 | 5664 | |||
14.6 | 2000 | 324.12 | 6.17 | 5935 | |||
15.6 | 2120 | 346.32 | 6.12 | 6056 | |||
25 | 0.6 | 200 | 15 | 13.33 | 1938 | ||
1.3 | 400 | 32.5 | 12.31 | 2748 | |||
2.3 | 600 | 57.5 | 10.43 | 3390 | |||
3.4 | 800 | 85 | 9.41 | 3891 | |||
4.6 | 1000 | 115 | 8.70 | 4294 | |||
5.9 | 1200 | 147.5 | 8.14 | 4667 | |||
7.5 | 1400 | 187.5 | 7.47 | 5038 | |||
9.2 | 1600 | 230 | 6.96 | 5334 | |||
10.9 | 1800 | 272.5 | 6.61 | 5670 | |||
12.9 | 2000 | 322.5 | 6.20 | 5932 | |||
15.7 | 2250 | 392.5 | 5.73 | 6252 | |||
19.2 | 2560 | 480 | 5.33 | 6594 | 90℃ |
