| Motor Model / KV | 5206/ KV340 |
|---|---|
| Stator/Rotor Poles | 18N24P |
| Internal resistance | 44mΩ |
| Motor size | Motor length：21mm |
| Shaft diameter | 3.175mm |
| AWG | 20AWG 100mm |
| Motor weight(wire included) | 209g |
| Motor weight(wire excluded) | No data |
| Rated operational voltage | 3-4S |
| No-load current | 0.8A |
| Maximum continuous power | 538w |
| Maximum continuous current | 32A/30s |
| ESC recommended use | 40A |
| Propeller size recommended use | EOLO C18*6.5 |
Specifications | 5206 | Max Continuous Current | 32A/30s |
Stator Diameter | 52mm | Max Continuous Power | 538w |
Stator Thickness | 6mm | Weight | 209g |
No.of Stator Slots | 24 | Rotor Diameter | 59mm |
No.of Rotor Poles | 28 | Body Length | 21mm |
Motor Kv | 340 | Max Lipo Cell | 6S |
NO-Load Current(A/10V) | 0.8A | ESC | 40A |
Motor Resistance | 44mΩ | Recommend Prop(inch) | EOLO C18*6.5 |
|
Propeller (inch) |
Voltage (V) |
Current (A) |
Thrust (g) |
Watts (W) |
Efficiency (g/W) |
RPM |
Load temperature in 100% throttle |
|
EOLO C18*6.5 |
22.2 |
1.6 |
500 |
35.5 |
14.08 |
2166 |
|
|
2.7 |
750 |
59.9 |
12.51 |
2673 |
|||
|
4.1 |
1000 |
91.0 |
10.99 |
3046 |
|||
|
5.6 |
1250 |
124.3 |
10.05 |
3419 |
|||
|
7.2 |
1500 |
159.8 |
9.38 |
3746 |
|||
|
9 |
1750 |
199.8 |
8.76 |
4042 |
|||
|
11.1 |
2000 |
246.4 |
8.12 |
4329 |
|||
|
13.3 |
2250 |
295.3 |
7.62 |
4527 |
|||
|
15.6 |
2500 |
346.3 |
7.22 |
4820 |
|||
|
20.6 |
3000 |
457.3 |
6.56 |
5218 |
|||
|
24.5 |
3370 |
543.9 |
6.20 |
5532 |
|||
|
25 |
1.5 |
500 |
37.5 |
13.33 |
2185 |
||
|
2.5 |
750 |
62.5 |
12.00 |
2687 |
|||
|
3.7 |
1000 |
92.5 |
10.81 |
3067 |
|||
|
5 |
1250 |
125 |
10.00 |
3441 |
|||
|
6.5 |
1500 |
162.5 |
9.23 |
3762 |
|||
|
8.2 |
1750 |
205 |
8.54 |
4047 |
|||
|
10 |
2000 |
250 |
8.00 |
4340 |
|||
|
12 |
2250 |
300 |
7.50 |
4581 |
|||
|
14.1 |
2500 |
352.5 |
7.09 |
4868 |
|||
|
18.6 |
3000 |
465 |
6.45 |
5293 |
|||
|
23.9 |
3500 |
597.5 |
5.86 |
5684 |
|||
|
29.2 |
4050 |
730 |
5.55 |
6015 |
130℃ |
